- Page 1 SL11E & S1500E CONSTRUCTION HEATERS Rev: 4.3; January 11, 2013 SERVICE AND MAINTENANCE MANUAL No. 974-9307 PLEASE RETAIN FOR FUTURE REFERENCE PRODUCTS A DIVISION OF HAUL-ALL EQUIPMENT LTD. 4115 - 18 Avenue North Lethbridge, Alberta T1H 5G1 www.sureflame.com...
- Page 2 WARNING Not for home or recreational vehicle use Page 2 P/N:974-9307 SL11E & S1500E Manual Rev: 4.3...
- Page 3 Your local authority can advise you about these. FOR YOUR SAFETY DO NOT USE THIS HEATER IN A SPACE WHERE GASOLINE OR OTHER LIQUIDS HAVING FLAMMABLE VAPOURS ARE STORED OR USED. SL11E & S1500E Manual Rev: 4.3 P/N:974-9307 Page 3...
-
Page 4: Table Of Contents
On-Site Hazards ..................10 Preventive Maintenance ................ 11 Troubleshooting ..................12 Replacement Parts ................20 SL11E Connection Wiring Diagram ............22 SL11E Ladder Wiring Diagram .............. 23 S1500E Connection Wiring Diagram ............. 24 S1500E Ladder Wiring Diagram ............25 Two-Stage Thermostat Wiring Diagram ..........26 LPG - Propane Fuel Vaporization Rate .......... -
Page 5: Specifications
(Minimum inlet pressure is for purpose of input adjustment) Gas Supply: S1500E Inlet Pressure Manifold Pressure Max.WC(Pa) Min.WC(Pa) Max.WC(Pa) Min.WC(Pa) Propane 14” (3500) 8” (2000) 2.7” (670) 0.75” (190) Natural 14” (3500) 8” (2000) 7.2” (1800) 2.0” (500) SL11E & S1500E Manual Rev: 4.3 P/N:974-9307 Page 5... -
Page 6: Installation
Installation The Sure Flame Models SL11E & S1500E are direct fired gas heaters intended to be used primarily for the temporary heating of buildings under construction, alteration, or repair. Since all the products of combustion are released into the area being heated, it is imperative that adequate ventilation be provided. -
Page 7: Installation Using A Propane Supply Tank
The installation of this heater to a natural gas supply must conform with all applicable local codes or, in the absence of local codes, with the CAN/ CGA-B149.1 Natural Gas Installation Code. SL11E & S1500E Manual Rev: 4.3 P/N:974-9307 Page 7... -
Page 8: Operating Instructions
6. Push START Button. After a short delay, the heater will start. Note: The SL11E, if equipped with a thermostat, will cycle between on and off as required. Note: The S1500E will cycle between high flame, low flame, and off as required. -
Page 9: Common Installation And Operational Problems
Safety Controls Servicing of Sure Flame Construction Heaters normally involves one of several built-in safety features. The Models SL11E & S1500E incorporate devices to detect the following: 1 LOSS OF FLAME Gas supply is shut off if flame is lost to prevent raw gas from leaving the heater. -
Page 10: Design Related Additional Safety Features
Sure Flame Heaters are designed to have a low skin temperature. This provides added safety in the workplace. 3 DURABLE CONSTRUCTION The Models SL11E & S1500E use a stainless steel burner for long life and consistent performance. In order to maintain the highly efficient combustion of the Sure Flame Heater, the combustion chamber must remain as manufactured. -
Page 11: Preventive Maintenance
Also check that all electrical connections are snug and tight. D. MOTOR The electric motor on the SL11E & S1500E Heaters is fitted with sealed bearings and no oiling is required. Keep the motor clean by blowing or wiping off dust or dirt in order to prevent it from over heating. -
Page 12: Troubleshooting
Chart C – Heater does not start, fan starts, spark, no flame Chart D – Heater starts, flame lights but goes out after a few seconds Chart E – Heater starts, but fails during operation Chart F – Other problems Page 12 P/N:974-9307 SL11E & S1500E Manual Rev: 4.3... - Page 13 SL11E & S1500E Manual Rev: 4.3 P/N:974-9307 Page 13...
- Page 14 Page 14 P/N:974-9307 SL11E & S1500E Manual Rev: 4.3...
- Page 15 SL11E & S1500E Manual Rev: 4.3 P/N:974-9307 Page 15...
- Page 16 Page 16 P/N:974-9307 SL11E & S1500E Manual Rev: 4.3...
- Page 17 SL11E & S1500E Manual Rev: 4.3 P/N:974-9307 Page 17...
- Page 18 Page 18 P/N:974-9307 SL11E & S1500E Manual Rev: 4.3...
- Page 19 SL11E & S1500E Manual Rev: 4.3 P/N:974-9307 Page 19...
-
Page 20: Replacement Parts
Page 20 P/N:974-9307 SL11E & S1500E Manual Rev: 4.3... - Page 21 SL11E & S1500E Manual Rev: 4.3 P/N:974-9307 Page 21...
-
Page 22: Sl11E Connection Wiring Diagram
SL11E Connection Wiring Diagram Page 22 P/N:974-9307 SL11E & S1500E Manual Rev: 4.3... -
Page 23: Sl11E Ladder Wiring Diagram
120 VAC Input (Hot) Gas Light (L6) Valve Neutral 120 VAC Neutral Stop Button Light (Error Light) Alarm Flame Rod Remote Flame Sensor Burner Ground Burner Ground High Voltage Output Spark Plug SL11E & S1500E Manual Rev: 4.3 P/N:974-9307 Page 23... -
Page 24: S1500E Connection Wiring Diagram
S1500E Connection Wiring Diagram Page 24 P/N:974-9307 SL11E & S1500E Manual Rev: 4.3... -
Page 25: S1500E Ladder Wiring Diagram
2nd Stage Valve Thermostat 2nd Stage Contact (NO) 120 VAC Neutral Stop Button Light (Error Light) Alarm Flame Rod Remote Flame Sensor Burner Ground Burner Ground High Voltage Output Spark Plug SL11E & S1500E Manual Rev: 4.3 P/N:974-9307 Page 25... -
Page 26: Two-Stage Thermostat Wiring Diagram
Two-Stage Thermostat Wiring Diagram (S1500-714) 1- BLACK 4 - WHITE 120VAC STAGE I I PLUG PINS 3 - BROWN 2 -BLUE NEUTRAL STAGE I Page 26 P/N:974-9307 SL11E & S1500E Manual Rev: 4.3... -
Page 27: Lpg - Propane Fuel Vaporization Rate
1 lb./sq. in. (psig) = 27.71" W.C. = 0.0689 bar 1" Mercury = 0.49 psig = 33.86 millibar 1 Std. Cubic Ft./Hr. = 2,500 BTU/Hr. = 0.02832 cu. m/hr. 1 BTU/Hr. = 0.2931 Watts SL11E & S1500E Manual Rev: 4.3 P/N:974-9307 Page 27...
