Overview

The VM-1021N is a high-performance distribution amplifier for composite or SDI
video signals. It provides controls to compensate for signal losses inherent in long
cable runs.
The VM-1021N is a full broadcast, state-of-the-art, 1:20 video distribution amplifier
designed for studio and other demanding applications. The unit splits a single
input source into twenty identical outputs with no discernible signal degradation.
The outputs are divided into 4 sets of five each, where each set may be
individually trimmed (level and EQ) for maximal flexibility. The machine may be
used to distribute analog or SD-SDI video signals, composite or single component.
The unit features:

High bandwidth of 350MHz (-3dB)

Grouped level (gain) and EQ (peaking) controls

Looping inputs

Selectable input signal termination

DC coupling

Standard 19" rack mount size of 1U
Figure 1
4
and Figure 2 define the unit.
