Technical Specification - Quasimidi Technox Owner's Manual

Technische Daten
Technical Specifications
Sound Synthesis:
Front Panel
Knob:
Key:
Display:
Connector:
Rear Panel
Connector:
Power
Power Requirement: AC220V, 50 Hz
Power Consumption:11 watts maximum
Physical
Dimensions:
Weight:
MASS (Multi Algorithm Sound Synthesis)
21 voice polyphonic, 16 part multi-timbral
PARAMETER/SOUNDGROUP,
VALUE/SOUND,
Volume
Power, EDIT/OK, PART/BANK (x2),
EXIT
2x16 character LCD
Headphones (6,3 mm stereo jack)
Output L, R (6,3 mm mono jack)
Footswitch (6,3 mm mono jack)
MIDI In, Out, Thru (DIN 5p x 3)
Power Inlet (3 pin, IEC-320 standard)
484 mm (width) x 48 mm (height) x 257 mm (depth),
(width 429 mm w/o front panel)
EIA 1 rack unit size
3,5 kg
51
