Appendix; Technical Data - Amplicomms PowerTel M7000 Operating Instructions Manual

A
PPENDIX

Appendix

Technical data

Dual-Band
Additional functions
Battery
Maximum earpiece
volume
Talk time
Standby time
Dimensions
USB connection
Headset connection
SAR values
68
GSM 900 / DCS 1800
Bluetooth, torch,
emergency call function
Li-Ion, 3.7V, 900 mAh
+40 dB (distortion < 5 %)
up to 7 hours
up to 8 days
102 x 51 x 17 mm (closed)
195 x 51 x 11 mm (open)
Micro USB, EU Standard
2.5 mm jack
GSM 900 MHz 0,512 W/kg
DCS 1800 MHz 0,582 W/kg
Helpline 0844 800 6503
(See page 69 for costs and hours of operation)
