STRENGTH 9000 SERIES TRAINING EQUIPMENT
SU10 Incline Chest Press
Black Cap(18)
0017-00042-0969
Guide Rods
0017-00009-0933
Note: Get length from
Customer
Shield
SK50-S0047-0000
Selector Pin
SK50-S0151-0000
Lanyard Cord
0017-00009-0938
Weight Stickers
M051-00262-A000
(15-300 lbs)
M051-00265-A000
(7-140 KG)
Label (2)
0K50-01001-0000
Arm
SLU0-S0011-0000
End Cap (4)
0017-00042-0958
1
Bolt
0017-00101-1392
Nut
0017-00103-0228
Add-On Weight
7.5 lbs
0K50-P0343-0000
Counter Weight
0K50-P0186-0000
Heim Joint (1)
0017-00009-0960
Rubber Grip)
0017-00042-0995
Grip Cap (2)
0K50-P0315-2000
Foot Pad 3x4
0017-00042-1019
Foot Pad 1-3x5.5
0017-00042-1020
(Seat Post Assembly
S/N 65130-Above
See Next Page)
Old Style Seat
SLU0-S0002-0000
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Life Fitness SU10
Summary of Contents for Life Fitness SU10
- Page 1 STRENGTH 9000 SERIES TRAINING EQUIPMENT SU10 Incline Chest Press Black Cap(18) 0017-00042-0969 Guide Rods 0017-00009-0933 Note: Get length from Customer Shield SK50-S0047-0000 Selector Pin SK50-S0151-0000 Lanyard Cord 0017-00009-0938 Weight Stickers M051-00262-A000 (15-300 lbs) M051-00265-A000 (7-140 KG) Label (2) 0K50-01001-0000 SLU0-S0011-0000...
- Page 2 STRENGTH 9000 SERIES TRAINING EQUIPMENT SU10 Incline Chest Press Pulley (7) 0017-00009-0977 Placard SU10-PL000-0001 Warning Label M051-00335-A000 Weight Stack Shield 0K50-E0003-0000 Decal M051-00270-A000 Weight Stack (255 lbs) AK50-WS003-0000 Weight Donut (2) 0017-00042-0993 Cable AK50-CL153-0802 AK50-CL157-0002 Rubber Cruth Tip(2) 0017-00042-0986 Plastic Insert...
- Page 3 STRENGTH 9000 SERIES TRAINING EQUIPMENT SU10 Incline Chest Press Thick Nylon Washer 0017-00104-0349 Bolt 2-1/2” 0017-00101-1417 Large Teflon Bushing 0017-00009-1027 HEIM Joint Assembly Linkage 0K50-P0424-0000 Bolt Bushing 0017-00101-1431 FB31-M0045-0000 Pulley Plate 0K50-P0125-0000 Nylon Washer 0017-00104-0373 Stop SU10-S0008-0000...
- Page 4 STRENGTH 9000 SERIES TRAINING EQUIPMENT SU10 Incline Chest Press End Cap 2-1/4 x 2-1/4 0017-00042-0950 Pull Pin Stainless Tube SK50-S0001-0000 SU10-S0010-0000 Receiver Tube SU10-S0005-0000...
- Page 5 STRENGTH 9000 SERIES TRAINING EQUIPMENT SU10 Seat Post Assembly - S/N 65130-Above 2-3/16” Item No. Qty. Part Number AK50-S0028-0000 0K50-P0547-0000 0K50-P0548-0000 0017-00101-1655 0017-00009-1079 The 13 notch front/back striker plate is grey. The 14 notch front/back striker plate is black and was implemented first quarter 2001.
