STRENGTH 9000 SERIES TRAINING EQUIPMENT
SU31 Lateral Raise
Label (2)
0K50-01001-0000
Placard
SU31-PL000-0001
Arm and Cam
SU31-S0002-0000
Handle Bumper
0017-00042-0936
Bolt
0017-00101-1521
Washer (2)
0017-00104-0349
Nut
0017-00103-0227
Weight Stickers
M051-00261-A000
(15-300 lbs)
M051-00265-A000
(7-140 KG)
Plastic Insert
0017-00042-0998
Old Style Seat Assy
AK50-S0001-0000
Pulley (3)
0017-00009-0977
Pull Pin Kit
SK50-S0001-0000
1
Cable
AK50-CL045-0000
Note: Cable only
with no ends
Cable
AK50-CL054-0804
Add-On Weight
7.5 lbs
0K50-P0343-0000
Weight Stack Donuts (2)
0017-00042-0993
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Life Fitness SU31
Summary of Contents for Life Fitness SU31
- Page 1 STRENGTH 9000 SERIES TRAINING EQUIPMENT SU31 Lateral Raise Label (2) 0K50-01001-0000 Placard SU31-PL000-0001 Arm and Cam SU31-S0002-0000 Handle Bumper 0017-00042-0936 Bolt 0017-00101-1521 Washer (2) 0017-00104-0349 0017-00103-0227 Weight Stickers M051-00261-A000 (15-300 lbs) M051-00265-A000 (7-140 KG) Plastic Insert 0017-00042-0998 Old Style Seat Assy...
- Page 2 STRENGTH 9000 SERIES TRAINING EQUIPMENT SU31 Lateral Raise Guide Rods 0017-00009-0933 Note: Get length from Customer Pillow Block Bearings 0017-00006-0203 Rubber Crutchtips 0017-00042-0986 Handle SU31-S0003-0000 Rubber Grip 0017-00042-0995 Grip Cap (2) 0K50-P0315-2000 Grip Ring (2) 0K50-P0316-2000 Black Pad Set SU31-FEA02-0P01...
-
Page 3: Seat Post
STRENGTH 9000 SERIES TRAINING EQUIPMENT SU31 Seat Post Assembly - S/N 65056-Above 2-3/16” Item No. Qty. Part Number AK50-S0028-0000 0K50-P0547-0000 0K50-P0548-0000 0017-00101-1655 0017-00009-1079 Seat Post Assembly NOTE: The Seat Guide is welded to the frame. Shown separately for illustration purposes only.
