STRENGTH 9000 SERIES TRAINING EQUIPMENT
SU35 Rear Deltoid/Pectoral Fly
Stop Kit
SK50-S0028-0000
Pull Pin Kit
SK50-S0001-0000
Plastic Tube
0017-00042-0947
1 1/4" Security Nut (inside arm)
0017-00103-0235
Rubber Grip
0017-00042-0995
Grip Ring (2)
0K50-P0316-2000
Grip Cap (2)
0K50-P0315-2000
Set Screw
0017-00101-1406
Black Pad Set
SU35-FEA02-OP01
Seat Pad
Black pad set
0K50-US007-0000
SU35-FEA02-OP01
Back Pad
0K50-US002-0000
Wear Cover
0K50-UE004-0000
(Seat Post Assembly
S/N 64972-Above
See Next Page)
Old Style Seat
AK50-S0001-0000
Foot Pad (2) - 3"x4"
0017-00042-1019
Foot Pad (1) - 3"x5.5"
0017-00042-1020
Label (2)
0K50-01001-0000
Weight Stickers
M051-00262-A000 (15-300 lbs)
M051-00265-A000 (7-140 KG)
1
Black Cap(8)
0017-00042-0969
Bumpers (2)
0017-00042-0942
Axle (2)
0K50-P0314-0000
Vertical Arm
SK50-S0109-0000
6.5 Pulley
0017-00009-0978
Floating Pulley Housing
AK50-S0006-0000
Weight Stack Shield
0K50-E0004-0000
Decal
M051-00270-A000
Warning Label
M051-00260-A000
Add-On Weight
0K50-P0343-0000
Selector Pin
0K50-A1102-0000
Lanyard Cord
0017-00009-0938
7.5 lbs
Advertisement
Related Manuals for Life Fitness SU35
Summary of Contents for Life Fitness SU35
- Page 1 STRENGTH 9000 SERIES TRAINING EQUIPMENT SU35 Rear Deltoid/Pectoral Fly Stop Kit SK50-S0028-0000 Pull Pin Kit SK50-S0001-0000 Plastic Tube 0017-00042-0947 1 1/4" Security Nut (inside arm) 0017-00103-0235 Rubber Grip 0017-00042-0995 Grip Ring (2) 0K50-P0316-2000 Grip Cap (2) 0K50-P0315-2000 Set Screw 0017-00101-1406...
- Page 2 STRENGTH 9000 SERIES TRAINING EQUIPMENT SU35 Rear Deltoid/Pectoral Fly Horizontal Shaft (RT/LT) SU35-S0006-0000 Placard SU35-PL000-0001 Pull Pin Kit SK50-S0001-0000 Aluminum Cap (2) 0K50-RM001-0000 Plastic Insert 0017-00042-0998 End Cap 0017-00042-0947 Pull Pin Kit SK50-S0001-0000 Pulley (2) Cable (156”-no ends) 0017-00009-0977 0017-00033-0823...
- Page 3 STRENGTH 9000 SERIES TRAINING EQUIPMENT SU35 Rear Deltoid/Pectoral Fly Cable Retainer Bolts 0017-00101-1431 Pull Pin SK50-S0008-0000 Warning Label M051-00335-A0000 Stop Kit (2 stops) SK50-S0028-0000 Placard SU35-PL000-0001 Black Cap 0K50-P0521-0000...
- Page 4 STRENGTH 9000 SERIES TRAINING EQUIPMENT SU35 Rear Deltoid/Pectoral Fly Right Cam SU35-S0005-0000 Right Selector SU35-S0008-0000 Left Cam SU35-S0004-0000 Axle - 0K50-P0314-0000 Bolt - 0017-00101-1523 Nut - 0017-00103-0232 Washer Arm (Upgrade kit 0017-00104-0352 for older units) Bushing 3/4 SK50-S0052-0000 0017-00009-0929 Left Selector...
-
Page 5: Seat Post Assembly
STRENGTH 9000 SERIES TRAINING EQUIPMENT SU35 Seat Post Assembly - S/N 64972-Above 2-3/16” Item No. Qty. Part Number AK50-S0028-0000 0K50-P0547-0000 0K50-P0548-0000 0017-00101-1655 0017-00009-1079 Seat Post Assembly NOTE: The Seat Guide is welded to the frame. Shown separately for illustration purposes only.
