Check Engine Compression

An accurate periodic engine compression check documents engine wear and condition. For engine compression
check procedures and special tools required, see the VICTORY Service Manual or contact an authorized VICTORY
dealer.

Check Exhaust System

Check the exhaust system for stains from leaking exhaust gasses. Replace exhaust gaskets if necessary (see the
VICTORY Service Manual or an authorized VICTORY dealer). Check all exhaust system fasteners.
1. Tighten exhaust header flange nuts.
Torque: 12 ft-lbs (16 Nm)
2. Tighten muffler clamps.
Torque: 45 ft-lbs (61 Nm)
3. Tighten muffler mounting screws.
Torque: 11 ft-lbs (15 Nm)
4. Tighten muffler bracket screws.
Torque: 11 ft-lbs (15 Nm)
3
4
2
3
1. Header Flange Nut
2. Muffler Clamp
MAINTENANCE
1
2
3. Muffler Mounting Screw
4. Muffler Bracket Screw
1
