OKIPAGE 10ex
LED Page Printer
Maintenance Manual
ODA / OEL / INT
Rev.5 99. 11. 30
1 / 197
40718401TH Rev.5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OKIPAGE 10ex and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Oki OKIPAGE 10ex

  • Page 1 OKIPAGE 10ex LED Page Printer Maintenance Manual ODA / OEL / INT Rev.5 99. 11. 30 1 / 197 40718401TH Rev.5...
  • Page 2: Table Of Contents

    CONTENTS 1. CONFIGURATION ....................5 1.1 System Configuration ..................5 1.2 Printer Configuration ..................7 1.3 Optional Configuration ..................8 1.4 Specification ....................10 1.5 Safety Standards .................... 12 1.5.1 Certification Label ....................12 1.5.2 Warning Label ......................12 1.5.3 Warning/Caution Marking ..................
  • Page 3 4. ADJUSTMENT ......................76 4.1 Maintenance Modes and Functions ..............76 4.1.1 User Maintenance Mode ..................76 4.1.2 System Maintenance Mode ..................76 4.1.3 Engine Maintenance Mode ..................77 4.1.4 EEPROM initialization .................... 78 4.2 Adjustment When Replacing a Part ..............79 4.2.1 Setting of LED Head Drive Time ................
  • Page 4 Parts Replacement Methods .................. 163 3.3.1 Link ......................164 3.3.2 Separator ....................165 3.3.3 OLEV-11-PCB ..................166 3.3.4 Pulse Motor .................... 167 3.3.5 Planet Gear .................... 168 3.3.6 Roller-A and B ..................169 TROUBLESHOOTING ..................170 Precautions Prior to the Troubleshooting ............... 170 Preparations for the Troubleshooting ..............
  • Page 5: Configuration

    CONFIGURATION System Configuration OKIPAGE 10ex consists of control and engine blocks in the standard configuration, as shown in Figure 1-1. In addition, the options marked with asterisk(*) are available. 40718401TH Rev.5...
  • Page 6 Operator Panel Engine Unit Paper Cassette Face Up Stacker *High Capacity Second Paper Paper Feeding Mechanism Feeder (First Tray Unit) Face *Multi Purpose Down Feeder Stacker Electrophotographic Processing Unit Power Supply and Sensor Board Centronics Main Control Board * : Optional Memory* Expansion Board 1 DRAM SIMM Socket...
  • Page 7: Printer Configuration

    Printer Configuration The printer unit consists of the following hardware components: • Electrophotographic Processor • Paper Feeder • Controller • Operator Panel • Power Supply Unit The printer unit configuration is shown in Figure 1-2. Upper cover Operator panel assy Toner-cartridge(Type 5) (consumable) Stacker assy...
  • Page 8: Optional Configuration

    Optional Configuration The options shown below are available for use with OKIPAGE 10ex. These are available separately from the printer unit. (1) High Capacity Second Paper Feeder (2) Multi Purpose Feeder (3) 1MB Memory Expausion Board 40718401TH Rev.5...
  • Page 9 (4) RS-232C Serial Interface Board (5) DRAM SIMM Memory DRAM SIMM memory is available with memory of 1MB (min.) to 32MB (max.). The access time of SIMM memories are 60ns, 70ns, 80ns, and 100ns. (6) Flash SIMM Flash SIMM is available with memory of 4MB and 8MB. 40718401TH Rev.5...
  • Page 10: Specification

    Specification (1) Type Desktop (2) External dimensions Height 7.9” (200 mm) Width 13.0” (330 mm) Depth 15.6” (395 mm) (3) Weight Approx. 10 kg (4) Developing method Dry electrophotography Exposing method LED stationary head (5) Paper used <Type> • Standard paper –...
  • Page 11 (8) Paper delivery method Face down/face up (9) Resolution 600 x 600 dots/inch 600 x 1200 dots/inch (10) Power input 120 VAC + 5.5%, -15% 230 VAC ± 10% (11) Power consumption Peak: Approx. 460W Typical operation: Approx. 215W Idle: Approx.
  • Page 12: Safety Standards

    Safety Standards 1.5.1 Certification Label The safety certification label is affixed to the printer in the position described below. INT AC : 230V model ODA AC : 120V model ODA AC : 230V model 1.5.2 Warning Label The warning labels are affixed to the sections which may cause bodily injury. Follow the instructions on warning labels during maintenance.
  • Page 13: Warning/Caution Marking

    1.5.3 Warning/Caution Marking The following warning and caution markings are made on the power supply/sensor board. WARNING AVERTISSEMENT ADVERTENCIA CAUTION HEATSINK AND TRANSFORMER ATTENTION ATENCÃO PRESENT RISK OF ELECTRIC SHOCK CUIDADO CUIDÃDO TEST BEFORE TOUCHING * No fuse is mounted here for 200V series ENGLISH Heatsink and transformer core present risk of electric shock.
  • Page 14: Operation Description

    OPERATION DESCRIPTION OKIPAGE 10ex consists of a main control board, a power supply/sensor board, an operator panel, an electrophotographic process mechanism, and revision for illumination of LED head. The main control board receives data via the host I/F, it then decodes, edits and stores the data in memory.
  • Page 15: Main Control Board

    Paper sensor Toner supply roller Outlet sensor Cleaning roller Thermistor Paper out sensor Fusing temperature control circuit Heater drive Toner low sensor Heater circuit transformer Filter circuit AC IN Figure 2-1 OKIPAGE 10ex Block Diagram 15 / 40718401TH Rev.5...
  • Page 16: Main Control Board

    Main Control Board The main control board consists of a single chip CPU, two program/font ROMs, four DRAMs, an EEPROM, a host interface circuit, and a mechanism driving circuit. (1) Single chip CPU The single chip CPU is a custom CPU (32-bit internal bus, 32-bit external bus, 28.24-MHz clock, with input frequency from a 7.06-MHz clock) which incorporates the RISC CPU and its peripheral devices, and has the following functions: Built-in device...
  • Page 17: Power Supply/Sensor Board

    Power Supply/Sensor Board The power supply/sensor board consists of an AC filter circuit, a low voltage power supply circuit, a high voltage power supply circuit, heater drive circuit, and photosensors. (1) Low Voltage Power Supply Circuit This circuit generates the following voltages. Output voltage +5 V Logic circuit supply voltage...
  • Page 18 The sensor layout diagram is shown in Figure 2-2. Exit roller Outlet sensor Heat roller Transfer roller Paper sensor Toner Inlet sensor sensor 2 Registration roller Paper end sensor Hopping roller Inlet sensor 1 Figure 2-2 Sensor Function Sensing state Inlet sensor 1 Detects the leading part of the paper and gives the monitor timing ON: Paper exists.
  • Page 19: Electrophotographic Process

    Electrophotographic Process 2.3.1 Electrophotographic Process Mechanism This mechanism actuates the printing of image data supplied by the main control board on the paper by electrophotographic process. The layout of the electrophotographic process mechanism is shown in Figure 2-3. 19 / 40718401TH Rev.5...
  • Page 20 Figure 2-3 20 / 40718401TH Rev.5...
  • Page 21 (1) Image Drum Unit The image drum unit consists of a sensitive drum, a charger, and a developer. The unit forms a toner image on the sensitive drum, using a electrostatic latent image formed by the LED head. (2) Registration Motor The registration motor is a pulse motor of 48 steps/rotation with two-phase excitement by the signal from the main control board.
  • Page 22: Electrophotographic Process

    2.3.2 Electrophotographic Process The electrophotographic processing is outlined below. The electrophotographic printing process is shown in Figure 2-4. 1 Charging The surface of the image drum is charged uniformly with a negative charge by applying the negative voltage to the charge roller. 2 Exposure Light emitted from the LED head irradiates the negatively charged surface of the image drum.
  • Page 23 Figure 2-4 23 / 40718401TH Rev.5...
  • Page 24 Figure 2-5 24 / 40718401TH Rev.5...
  • Page 25: Process Operation Descriptions

    2.3.3 Process Operation Descriptions (1) Hopping and Feeding Hopping and feeding motions are actuated by a single registration motor in the mechanism as shown below: Registration motor Idle gear Registration roller Hopping roller Motor gear Registration gear Hopping gear The registration motor turning in direction "a" drives the hopping roller. The registration motor turning in direction "b"...
  • Page 26 Hopping 1 For hopping, the registration motor turns in direction "a" (clockwise direction) and drives the hopping roller to advance the paper until the inlet sensor turns on (in this case, the registration gear also turns, but the registration roller is prevented from turning by the one- way bearing).
  • Page 27 (2) Charging Charging is actuated by the application of the DC voltage to the charge roller that is in contact with the image drum surface. Power Charge roller supply Image drum The charge roller is composed of two layers, a conductive layer and a surface protective layer, both having elasticity to secure good contact with the image drum.
  • Page 28 (3) Exposure Light emitted by the LED head irradiates the image drum surface with a negative charge. The surface potential of the irradiated portion of the image drum drops, forming an electrostatic latent image associated with the image signal. LED head LED head Charge roller Power...
  • Page 29 The image roller surface is charged to about –750 V by the contact charge of the charge roller. When the light from the LED head irradiates the image drum surface, the light energy generates positive and negative carriers in the CGL. The positive carriers are moved to the CTL by an electrical field acting on the image drum.
  • Page 30 (4) Developing Toner is attracted to the electrostatic latent image on the image drum surface, converting it into a visible toner image. Developing takes place through the contact between the image drum and the developing roller. 1 As the toner supply roller rotates while rubbing on the developing roller, a friction charge is generated between the developing roller and the toner, allowing the toner to be attracted to the developing roller (the developing roller surface is charged positive and the toner, negative).
  • Page 31 Note: The bias voltage required during the developing process is supplied to the toner supply roller and the developing roller, as shown below. –500 VDC is supplied to the toner supply roller, –265 VDC to the developing roller. Connected and bias supplied when the cover is closed.
  • Page 32 (5) Transfer The transfer roller is composed of conductive sponge material, and is designed to get the image drum surface and the paper in a close contact. Paper is placed over the image drum surface, and the positive charge, opposite in polarity to that of the toner, is applied to the paper from the reverse side.
  • Page 33 (6) Fusing When the transfer is completed, the toner image is fused to the paper by heat and pressure as the paper with unfused toner image passes between the heater roller and the back-up roller. The heater roller with Teflon coating incorporates a 400W heater (Halogen lamp), which generates heat. A thermistor which is in contact with the heater roller regulates the temperature of the heater roller to a designated temperature in the menu, depending on the thickness of the paper (tray 1&2: light=165°C, medium light=170°C, medium=175°C, medium heavy and heavy=195°C/manual...
  • Page 34 (7) Cleaning When the transfer is completed, the residual toner left on the image drum is attracted to the cleaning roller temporarily by static electricity, and the image drum surface is cleaned. Image drum Cleaning roller Power supply Transfer roller (8) Cleaning of rollers The charge, transfer and cleaning rollers are cleaned for the following cases: •...
  • Page 35: Revision Of Led Head Illumination

    2.3.4 Revision of LED Head Illumination An LED correcting head, which is capable of correcting the illumination of the LED for each dot, is being used in this printer. LED illumination correction function of 16 steps is carried out by using an EEPROM which is installed in the LSI that maintains the LED illumination correction values, and an LED correction drivers (MSM6731BWAF or MSM6732BWAF) together as a pair.
  • Page 36 The printing operation timing chart is shown below. Normal Mode Printing Timing Chart CLOCKI LOADI DATAI3~0 STRB1I-N STRB2I-N STRB3I-N STRB4I-N First line printing data sent Second line printing data sent First line printing The printing operation is carried out in normal mode. Under ordinary circumstances such as when the power is turned on or when LOADI signal level is low, the normal mode is enabled.
  • Page 37 The mode setting timing chart during illumination correction is shown below. Illumination Correction Mode Setting Timing Chart 50ns 50ns 100ns min 200ns min 100ns min CLOCKI LOADI DATAI0 D4 D3 D2 D1 D0 STRB1I-N STRB2I-N STRB3I-N STRB4I-N Mode setting Mode enabled Mode set The mode setting is carried out in the following manner.
  • Page 38 The LED driver (MSM6731BWAF) corrects the LED illumination by controlling the LED current. The LED illumination can be set in 16 steps, with 7 steps in the direction of illumination increase in relation to the standard value, and 8 steps in the direction of decrease. For this reason, the LED correction data is a 4-bit data for each dot.
  • Page 39: Paper Jam Detection

    Paper Jam Detection The paper jam detection function monitors the paper condition when the power is turned on and during printing. When any of the following conditions arises, this function interrupts the printing process. If any of the following errors is encountered, printing can be recovered by removing the jammed paper (by opening the upper cover, removing the jammed paper and closing the upper cover).
  • Page 40 Paper Feed Check List Error Type of error Monitor Standard value Plus Minus Paper feed error Hopping start In sensor on 72.0 36.0 – Paper feed jam In sensor on Write sensor on 20.0 22.0 – Paper feed jam Write sensor on Out sensor on 140.5 25.0...
  • Page 41: Cover Open

    Cover Open When the stacker cover is opened, the cover open microswitch on the power supply/sensor board is turned off to cut +5V supply to the high voltage power supply circuit. This results in the interruption of all high-voltage outputs. At the same time, the CVOPN signal is sent to the main control board to notify that the microswitch is off, and the main control board carries out the cover open process.
  • Page 42: Toner Low Detection

    Toner Low Detection • Device The Toner Low Detection device consists of a stirring gear which rotates at a constant rate, a stirring bar and a magnet on the stirring bar. The stirring bar rotation is driven by the link to the gouged portion in the stirring gear.
  • Page 43: Toner Full State

    TONER FULL state 160 ms < t1 < 0.8 sec TNRSNS-N 2.63 sec. TONER LOW state t1 > 0.8 sec. TNRSNS-N 2.63 sec. • When the Toner Low state is detected 2 times consecutively, Toner Low is established. • When the Toner Full state is detected 2 times consecutively, Toner Low is cancelled. •...
  • Page 44: Parts Replacement

    PARTS REPLACEMENT The section explains the procedures for replacement of parts, assemblies, and units in the field. Only the disassembly procedures are explained here. For reassembly, reverse the disassembly procedure. Precautions for Parts Replacement (1) Before starting to replace parts, remove the AC cord and interface cable. Remove the AC cord in the following sequence: Turn off (“o”) the power switch of the printer Disconnect the AC inlet plug of the AC cord from the AC receptacle.
  • Page 45 [Service Tools] The tools required for field replacement of printed circuit boards, assemblies and units are listed in Table 3-1. Table 3-1 Service Tools Service Tools Q' ty Application Remarks No. 1-100 Philips screwdriver 2~2.5 mm screws No. 2-100 Philips screwdriver 3~5 mm screws No.
  • Page 46: Parts Layout

    Parts Layout This section explains the layout of main components of the equipment. [Lower base unit] Pulse motor Stacker cover assy (main/drum) Eject roller assy View A Back-up roller Pulse motor Transfer roller (registration) Diselectrification bar Registration roller Spacer bearing R Fusing unit Spacer bearing L Lower base unit...
  • Page 47 [Upper cover unit] Upper cover Figure 3-2 47 / 40718401TH Rev.5...
  • Page 48 [Base unit] Operator panel assy Power supply/ sensor board Transformer Face up stacker assy DC fan assy Main control board Cassette guide (R) Cassette guide(L) Paper cassette Figure 3-3 48 / 40718401TH Rev.5...
  • Page 49: How To Change Parts

    How to Change Parts This section explains how to change parts and assemblies listed in the disassembly diagram below. In the parts replacement procedure, those parts marked with the part number inside with white letters are RSPL parts. Printer unit Upper cover assy Operator panel assy Face up stacker assy...
  • Page 50: Upper Cover Assy

    3.3.1 Upper Cover Assy (1) With the power switch turned off, unplug the AC power cord from the outlet. (2) Disconnect the interface cable 1. (3) Press the knobs 2 on left and right sides and open the stacker cover assy 3. (4) Take out the image drum unit 4.
  • Page 51: Ic Card Cover

    3.3.2 IC Card Cover (1) Open the IC card cover 1, press it from both sides at the hinges in the directions of arrows shown below and remove it. 51 / 40718401TH Rev.5...
  • Page 52: Led Head

    3.3.3 LED Head (1) Press the knobs on left and right sides and open the stacker cover assy 1. (2) Open the hook section on the left side of the stacker cover and remove the LED head 2. Note: • Be sure not to touch directly or push on the SLA part of the LED head.
  • Page 53: Operator Panel Assy

    3.3.4 Operator Panel Assy (1) Unlock two latches on the upper cover from the rear side, lift the operator panel assy 1 from the back and remove it. (2) Remove the Sumi card (operator panel) 2 from the connector (CN1) 3. Note : You can remove the operator panel assy while the upper cover installed on the unit.
  • Page 54: Lower Base Unit

    3.3.5 Lower Base Unit (1) Remove the upper cover assy (see 3.3.1). (2) Remove the operator panel assy (see 3.3.4). (3) Remove the face up stacker assy (see 3.3.8). (4) Remove the connecting cables 2 and 3 of the pulse motors from the connectors (DM, RM) of the M5B-PCB 1.
  • Page 55: Pulse Motor (Main/Drum)

    3.3.6 Pulse Motor (Main/Drum) (1) Remove the upper cover assy (see 3.3.1). (2) Remove the lower base unit (see 3.3.5). (3) Remove two screws 1 and remove the pulse motor (main/drum) 2 from the motor bracket 3. View A View A 55 / 40718401TH Rev.5...
  • Page 56: Pulse Motor (Registration)

    3.3.7 Pulse Motor (Registration) (1) Remove the upper cover assy (see 3.3.1). (2) Remove the lower base unit (see 3.3.5). (3) Remove two screws 1 and remove the pluse motor (registration) 2 from the motor bracket 3. View A View A 56 / 40718401TH Rev.5...
  • Page 57: Face Up Stacker Assy

    3.3.8 Face Up Stacker Assy (1) Remove the upper cover assy (see 3.3.1). (2) Remove the operator panel assy (see 3.3.4). (3) Remove the screw 1 and remove the Sumi card (operator panel cable) 2 off the latch section of face up stacker 4.
  • Page 58: Eject Roller Assy

    3.3.9 Eject Roller Assy (1) Remove the upper cover assy (see 3.3.1). (2) Remove the operator panel assy (see 3.3.4). (3) Remove the face up stacker assy (see 3.3.8). (4) Remove the lower base unit (see 3.3.5). (5) Disengage the eject roller assy 1 from the lower base 2 by pressing the latch section of the eject roller assy 1 in the direction of the arrow shown below, and remove the eject roller assy 1.
  • Page 59: 3.3.10 Motor Assy

    3.3.10 Motor Assy (1) Remove the upper cover assy (see 3.3.1). (2) Remove the operator panel assy (see 3.3.4). (3) Remove the face up stacker assy (see 3.3.8). (4) Remove the lower base unit (see 3.3.5). (5) Stand the lower base unit on its side as shown, and unlock two latches, then remove the motor assy 59 / 40718401TH Rev.5...
  • Page 60: Hopping Roller Shaft Assy

    3.3.11 Hopping Roller Shaft Assy (1) Remove the upper cover (see 3.3.1). (2) Remove the operator panel assy (see 3.3.4). (3) Remove the face up stacker assy (see 3.3.8). (4) Remove the lower base unit (see 3.3.5). (5) Remove the motor assy (see 3.3.10). (6) With the lower base unit 1 standing on its side, remove the one-way clutch gear 2 and the bearing (A) 3.
  • Page 61: 3.3.12 Stacker Cover Assy

    3.3.12 Stacker Cover Assy (1) Remove the upper cover assy (see 3.3.1). (2) Remove the operator panel assy (see 3.3.4). (3) Remove the face up stacker assy (see 3.3.8). (4) Remove the reset lever R 1. (5) Detach the reset spring 2 from the lower base unit 3, turn the reset lever L 4 in the direction of arrow until it stops, and remove it in the direction of arrow (6) Unlock two latches of the lower base unit 3, then remove the stacker cover assy 5.
  • Page 62: Registration Roller

    3.3.13 Registration Roller (1) Remove the upper cover (see 3.3.1). (2) Remove the operator panel assy (see 3.3.4). (3) Remove the face up stacker assy (see 3.3.8). (4) Remove the lower base unit (see 3.3.5). (5) Remove the motor assy (see 3.3.10). (6) With the lower base unit standing on its side, remove the one-way clutch gear 1.
  • Page 63: 3.3.14 Roller Transfer Assy

    3.3.14 Roller Transfer Assy (1) With the power switch turned off, unplug the AC cord from the outlet. (2) Open the stacker cover. (3) Release the roller transfer assy 1 by unlocking the latch of the main unit (never apply excessive force when unlocking the latch).
  • Page 64: 3.3.15 Fusing Unit

    3.3.15 Fusing Unit (1) Remove the upper cover (see 3.3.1). (2) Remove the operator panel assy (see 3.3.4). (3) Remove the face up stacker assy (see 3.3.8). (4) Remove the stacker cover assy (see 3.3.12). (5) Remove four screws 1, lift and remove the fusing unit 2. Caution: Fusing unit may be hot.
  • Page 65: 3.3.16 Back-Up Roller

    3.3.16 Back-up Roller (1) Remove the fusing unit assy (see 3.3.15). (2) Lift the left side of the back-up roller 1, and pull it out to the left side (at this time, two bushings (back- up) 2 and the bias springs (back-up) 3 will also come off). 65 / 40718401TH Rev.5...
  • Page 66: Sensor Plate (Inlet)

    3.3.17 Sensor Plate (Inlet) (1) Remove the upper cover (see 3.3.1). (2) Remove the operator panel assy (see 3.3.4). (3) Remove the face up stacker assy (see 3.3.8). (4) Remove the lower base unit (see 3.3.5). (5) Press the clamps of three sensor plates (inlet and paper) 1, and remove them by pressing them upward from the bottom.
  • Page 67: Sensor Plate (Outlet)

    3.3.18 Sensor Plate (Outlet) (1) Remove the upper cover assy (see 3.3.1). (2) Remove the operator panel assy (see 3.3.4). (3) Remove the eject roller assy (see 3.3.9). (4) Remove the face up stacker assy (see 3.3.8). (5) Remove the lower base unit (see 3.3.5). (6) Remove the fusing unit assy (see 3.3.15).
  • Page 68: 3.3.19 Manual Feed Guide Assy

    3.3.19 Manual Feed Guide Assy (1) Remove the upper cover assy (see 3.3.1). (2) Open the manual feed guide assy 1, and release the engagement on both sides with the main unit by carefully bending the manual feed guide assy 1. Note : When remounting, verify the proper the engagements as shown in the diagram.
  • Page 69: Sensor Plate (Paper Supply)

    3.3.20 Sensor Plate (Paper Supply) (1) Remove the upper cover assy (see 3.3.1). (2) Remove the operator panel assy (see 3.3.4). (3) Remove the face up stacker assy (see 3.3.8). (4) Remove the lower base unit (see 3.3.5). (5) Press the clamps of the sensor plate (paper supply) 1 to unlock the latch, and remove it from the base plate 2.
  • Page 70: M5B-Pcb

    3.3.21 M5B-PCB (1) Remove the upper cover assy (see 3.3.1). (2) Remove the operator panel assy (see 3.3.4). (3) Remove the face up stacker assy (see 3.3.8). (4) Remove the lower base unit (see 3.3.5). (5) Remove the connector (2NDTRAY) 6. (6) Remove three screws 1.
  • Page 71: 3.3.22 Transformer

    3.3.22 Transformer (1) Remove the upper cover assy (see 3.3.1). (2) Remove the operator panel assy (see 3.3.4). (3) Remove the face up stacker assy (see 3.3.8). (4) Remove the connectors (CN1 and CN2). (5) Remove two screws 1, and remove the transformer 2. Note : When reinstalling the transformer, be sure to lay the AC and transformer’s primary side cables under the divider (see view A diagram below).
  • Page 72: 3.3.23 Power Supply/Sensor Board And Contact Assy

    3.3.23 Power Supply/Sensor Board and Contact Assy (1) Remove the upper cover assy (see 3.3.1). (2) Remove the lower base unit (see 3.3.5). (3) Remove the M5B-PCB (See 3.3.21). (4) Remove the transformer (see 3.3.22). (5) Remove the AC inlet 1 from the base plate 2. (6) Remove the screw 3 and remove the grounding (earth) wire 4.
  • Page 73: 3.3.24 Cassette Guide L Assy

    3.3.24 Cassette Guide L Assy (1) Remove the paper cassette. (2) Remove the upper cover assy (see 3.3.1). (3) Remove the lower base unit (see 3.3.5). (4) Remove the M5B-PCB (see 3.3.21). (5) Remove the transformer (see 3.3.22). (6) Remove the power supply/sensor board (see 3.3.23). (7) Remove two screws 1, and remove the guide rails 2.
  • Page 74: 3.3.25 Cassette Guide R Assy

    3.3.25 Cassette Guide R Assy (1) Remove the paper cassette. (2) Remove the upper cover assy (see 3.3.1). (3) Remove the lower base unit (see 3.3.5). (4) Remove the M5B-PCB (see 3.3.21). (5) Remove two screws 1, and remove the guide rails 2. (6) Remove the screw 3, and remove the cassette guide R 4 by shifting it in the direction of arrow.
  • Page 75: Spacer Bearing (L/R)

    3.3.26 Spacer Bearing (L/R) (1) Remove the back-up roller (see 3.3.16). (2) Remove spacer bearing (L/R) with a tip of screw driver. Spacer bearing L Spacer bearing R 75 / 40718401TH Rev.5...
  • Page 76: Adjustment

    ADJUSTMENT This chapter provides explanations concerning the adjustment necessary when replacing a part. The adjustment is made by changing the parameter value set in EEPROM on the main control board. The parameter can be set by the key operation from the operator panel. This printer has three kinds of maintenance modes, and it is necessary to select one of the modes when replacing any parts.
  • Page 77: Engine Maintenance Mode

    4.1.3 Engine Maintenance Mode Note: This mode is used only by maintenance personnel, and it should not be released to the end users. (1) To enter into the engine maintenance mode, turn the power on while holding ENTER and FORM FEED keys down.
  • Page 78: Eeprom Initialization

    4.1.4 EEPROM initialization The corresponding are of the EEPROM is initialized for each event as shown Table 4-1. Talbe 4-1 EEPROM Initial Setting Range EEPROM area No Event User maintenance menu reset System main- tenance EEPROM reset Engine maintenance Note2) Note2) engine reset Firm revision check error at power-on...
  • Page 79: Adjustment When Replacing A Part

    Adjustment When Replacing a Part Adjustment is necessary when replacing any of the following parts. Part Replaced Adjustment LED Head Set the LED head drive time. Image Drum Cartridge Reset the image drum counter (refer to User's manual). Main Control Board EEPROM data Upload / Download 4.2.1 Setting of LED Head Drive Time...
  • Page 80 • Setting of LED Head Drive Time Drive time of the LED head is set by setting the parameter of drive time of EEPROM according to the luminous intensity marking on the LED head. a. Corresponding table of luminous intensity marking and drive time parameter Luminous intensity Luminous intensity Drive time parameter...
  • Page 81 c. Setting Example: Method for setting the parameter to 19 (for a case where the previous parameter setting was 8). Operation LCD display after operation Turn the POWER switch ENG MNT on while holding the FORM FEED and ENTER keys down. LED HEAD Displays previous Press the MENU key...
  • Page 82: Uploading/Downloading Eeprom Data

    4.2.2 Uploading/Downloading EEPROM data When the controller printed circuit board is replaced, the contents of the old EEPROM shall be copied to the new EEPROM on the new board to preserve customer settings. For the purpose, use the EEPROM operation on the Option of the Maintenance Utility. To copy follow the steps below. (1) Be sure to confirm that the printer and the PC are connected with a centronics I/F cable.
  • Page 83: Periodical Maintenance

    PERIODICAL MAINTENANCE Periodical Replacement Parts The parts are to be replaced periodically as specified below: Part name Condition for replacement Cleaning Remarks • Toner cartridge(Type 5) About 2,000 sheets of paper have been printed. • LED head Consumables • Image drum cartridge About 20,000 sheets of paper have been printed.
  • Page 84 (1) Set the LED head cleaner to the LED lens array as shown in the figure, then slide the cleaner back and forth horizontally several times to clean the head. Note: Gently press the LED head cleaner onto the LED lens array. LED head clean pad LED lens array (2) Throw the cleaner pad away.
  • Page 85: Cleaning

    5.2.2 Cleaning Page Function There is a charge roller cleaning function with this printer, which can be executed by the user. (1) While the printer is in off-line mode, press both keys simultaneously for at least 2 seconds. The printer enters the cleaning mode. (2) The LCD displays "CLEANING"...
  • Page 86: Troubleshooting Procedures

    TROUBLESHOOTING PROCEDURES Troubleshooting Tips (1) Check the troubleshooting section in the Printer Handbook. (2) Gather as much information about the situation as possible. (3) Inspect the equipment under the conditions close to those in which the problem had occurred. Points to Check before Correcting Image Problems (1) Is the printer being run in proper ambient conditions? (2) Are supplies (toner) and routine replacement part (image drum cartridge) being replaced properly? (3) Is the printing paper normal (acceptable quality)?
  • Page 87: Preparation For Troubleshooting

    Preparation for Troubleshooting (1) Operator panel display The failure status of the printer is displayed by the liquid crystal display (LCD) of the operator panel. Take proper corrective action as directed by messages which are being displayed on the LCD. <For ODA>...
  • Page 88: Troubleshooting Flow

    Troubleshooting Flow Should there be a problem with the printer, carry out troubleshooting according to the following procedure flow: Problems Carry out a detailed Problems Troubleshoot from the LCD troubleshooting with the indicated by LCD status message list. troubleshooting chart. message See Section 6.5.1.
  • Page 89 89 / 40718401TH Rev.5...
  • Page 90 90 / 40718401TH Rev.5...
  • Page 91 91 / 40718401TH Rev.5...
  • Page 92 92 / 40718401TH Rev.5...
  • Page 93 93 / 40718401TH Rev.5...
  • Page 94 94 / 40718401TH Rev.5...
  • Page 95 95 / 40718401TH Rev.5...
  • Page 96 96 / 40718401TH Rev.5...
  • Page 97 97 / 40718401TH Rev.5...
  • Page 98: Lcd Message Troubleshooting

    6.5.2 LCD Message Troubleshooting If the problems cannot be corrected by using the LCD status message/problem list, follow the troubleshooting flowcharts given here to deal with them. Trouble Flowchart number The printer does not work normally after the power is turned on. Jam alarm Paper input jam Paper feed jam...
  • Page 99: The Printer Does Not Work Normally After The Power Is Turned On

    The printer does not work normally after the power is turned on. • Turn the power off, then back on. • Is all black message being displayed by the LCD display? • No Is the AC cord being connected properly? •...
  • Page 100 • Take the measurement of the following voltage readings at connector CN2 on the power supply/ sensor board: Voltage between Pins 1 and 3: ... about 40 V AC Voltage between Pins 5 and 6: ... about 9.2 V AC Are the voltages within the normal range? •...
  • Page 101: Paper Input Jam

    [JAM error] Paper input jam • Does the JAM error occur when the power is turned on? • Yes Is the paper at the inlet sensor? • Yes Remove the paper. • No Is the operation of the inlet sensor plate normal (moves freely when it is touched)? •...
  • Page 102: Paper Feed Jam

    [JAM error] Paper feed jam • Does the paper feed jam occur when the power is turned on? • Yes Is the paper on the paper sensor plate? • Yes Remove the paper. • No Is the operation of the paper sensor plate normal (moves freely when it is touched)? •...
  • Page 103: Paper Exit Jam

    2-2-a • No Check the gears (transfer roller gear, idle gear and reduction gear). • Yes Is the fusing unit being installed properly? • No Install the fusing unit properly. • Yes Is the image drum cartridge being set properly? •...
  • Page 104: Paper Size Error

    Paper size error • Is paper of the specified size being used? • No Use paper of the specified size. • Yes Are inlet sensor plates 1 and 2 operating properly (moves freely when they are touched)? • No Replace the inlet sensor plate or clean the inlet sensor on the power supply/sensor board.
  • Page 105: Fusing Unit Error

    Fusing unit error (ERROR 71) (ERROR 72) (ERROR 73) • Turn the power off, then back on again. • Yes Is the thermistor open or shorted? Measure the resistance between thermistor contacts (heater contacts 120V/3Ω or 240V/10Ω, and thermistor contacts 220KΩ at room temperature) (see Figure 6-2 or Section 7.3).
  • Page 106: Fan Error

    Synchronous serial I/O error (ERROR 74) or I/F timeout between printer and op- tional tray (ERROR 81) • Is an option tray (High Capacity Second Paper Feeder or Power Envelope Feeder) being used? • Yes Is the cable between the main control board and the optional tray being connected properly? •...
  • Page 107: Image Troubleshooting

    6.5.3 Image Troubleshooting Procedures for troubleshooting for abnormal image printouts are explained below. Figure 6-3 below shows typical abnormal images. Problem Flowchart number Images are light or blurred entirely (Figure 6-3 Dark background density (Figure 6-3 Blank paper is output (Figure 6-3 Black vertical belts or stripes (Figure 6-3 Cyclical defect (Figure 6-3 Prints voids...
  • Page 108: Images Are Light Or Blurred Entirely

    Images are light or blurred entirely. • Is toner low (is the TONER LOW message displayed)? • Yes Supply toner. • No Is paper of the specified grade being used? • No Use paper of the specified grade. • Yes Is the lens surface of the LED head dirty? •...
  • Page 109: Dark Background Density (Figure 6-3 B )

    Dark background density • Has the image drum been exposed to external light? • Yes Install the image drum in the printer and wait about 30 minutes. • No Perform the cleaning page function (see Section 5.2.2). • Has the problem been solved? •...
  • Page 110: Blank Paper Is Output (Figure 6-3 C )

    Blank paper is output. • Is the LED head being connected properly (check the HEAD1 and HEAD2 connectors on the main control board and PC connector on the LED head)? • No Connect the LED head properly or replace the head cable(s). •...
  • Page 111: Black Vertical Belts Or Stripes (Figure 6-3 D )

    Black vertical belts or stripes • Perform the cleaning page function (see Section 5.2.2). • Has the problem been solved? • Yes End. • No Replace the image drum cartridge. • Has the problem been solved? • Yes Note: After replacing the image drum cartridge, set the printer to the user mainte- nance mode by turning the power on while pressing the MENU key, and reset the drum counter (see Printer Handbook).
  • Page 112: Cyclical Defect

    Cyclical defect Frequency Remedy Image drum 3.71" (94.2mm) Replace or clean the image drum cartridge. Developing roller 1.86" (47.12mm) Replace the image drum cartridge. Toner supply roller 2.96" (75.27mm) Replace the image drum cartridge. Charging roller 1.21" (30.63mm) Replace the image drum cartridge. Cleaning roller 0.93"...
  • Page 113: Prints Voids

    Prints voids • Is the contact plate of the transfer roller in proper contact with the power supply/sensor board (see Figure 6-5)? • No Adjust the contact plate so that it touches the power supply/sensor board and the shaft of the transfer roller properly. •...
  • Page 114: Poor Fusing

    Poor fusing (images are blurred or peels off when the printed characters and im- ages on the paper are touched by hand) • Is paper of the specified grade being used? • No Use paper of the specified grade. • Yes Is the tension between the back-up roller (7.52kg) and the surface of back-up roller normal? •...
  • Page 115: White Vertical Belts Or Streaks

    White vertical belts or streaks • Are the LED lens dirty? • Yes Clean the LED lens. • No Is the contact plate of the transfer roller in proper contact with the power supply/sensor board (see Figure 6-5)? • No Adjust the contact plate to make a proper contact with the power supply/sensor board.
  • Page 116: Figure

    Figure 6-4 116 / 40718401TH Rev.5...
  • Page 117 Contact plate for transfer roller Power supply/sensor board Contact Figure 6-5 117 / 40718401TH Rev.5...
  • Page 118: Wiring Diagram

    WIRING DIAGRAM Interconnect Signal Diagram 118 / 40718401TH Rev.5...
  • Page 119: Pcb Layout And Connector Signal List

    PCB Layout and Connector Signal List (1) Main Control Board (M5B-PCB) Printer front side OPTION HEAD1 HEAD2 OPTION CENT LED Head Operator panel Printer front side Contact face Contact face Printer front side 6 – 1 14 – 1 12 – 1 119 / 40718401TH Rev.5...
  • Page 120 (2) Power Supply/Sensor Board TR OUT * In case of 200V series, there is no F2 on the power supply/sensor board. 120 / 40718401TH Rev.5...
  • Page 121 • FAN Connector Pin Assignment (To fan motor) PIN NO. I/O* Signal Description FANPOW Power supply for fan driving Opening Ground FANALM-N Fan alarm • DM Connector Pin Assignment (To main/drum motor) PIN NO. I/O* Signal Description DMPH1-P Coil 1-N DMPH1-N Coil 1-P DMPH2-P...
  • Page 122 • RM Connector Pin Assignment (To registration motor) PIN NO. I/O* Signal Description RMPH1-P Coil 1-N RMPH1-N Coil 1-P RMPH2-P Coil 2-P RMPH2-N Coil 2-N * I: In O: Out Excitation sequence Step No. PIN NO. Line Color Yellow Black Orange Brown Rotary direction...
  • Page 123 • HEAD1 Connector Pin Assignment (To LED head) PIN NO. I/O* Signal Description HDSTB4-N Strobe 4 HDSTB3-N Strobe3 HDSTB2-N Strobe 2 HDSTB1-N Strobe 1 HDDLD-P Load +3.3V +3.3V power supply for LED driving HDD1-P Data 1 HDD0-P Data 0 OVLED Ground for LED HDD3-P Data 3...
  • Page 124 • PANEL Connector Pin Assignment (To operator panel) PIN NO. I/O* Signal Description PLD-N Load Logic groud PDATAOUT-P Data output PDATAIN-P Data input +5V power supply PSCLK-N Clock * I: In O: Out C: Common • ENVELOPE Connector Pin Assignment (To option feeder I/F) PIN NO.
  • Page 125 125 / 40718401TH Rev.5...
  • Page 126 126 / 40718401TH Rev.5...
  • Page 127 • OPTION Connector Pin Assignment (To option RAM or RS232C board) Pin No. I/O* Signal Description Pin No. I/O* Signal Description OR write enable Data bit 16 Logic ground Data bit 0 Address bit 1 Data bit 17 Address bit 2 Data bit 1 RSDTR0-N RS232C Data terminal ready...
  • Page 128: Resistance Check

    Resistance Check 128 / 40718401TH Rev.5...
  • Page 129 129 / 40718401TH Rev.5...
  • Page 130: Short Plug Setting

    Short Plug Setting (1) Main Control Board (M5B-PCB) • Short plug settings Short plug Plug setting Description Factory setting Provided Debug mode Not provided Not provided Normal 2-3 Short +5 V is supplied to Pin 18 of Centronics parallel I/F connector. 2-3 Short 1-2 Short +5 V is not supplied to Pin 18 Centronics parallel I/F connector.
  • Page 131: Parts List

    PARTS LIST Figure 8-1 Lower Base Unit 131 / 40718401TH Rev.5...
  • Page 132 Table 8-1 Lower Base Unit (1/2) Name/Rating Part No. Remarks ODA Part No. Hopping roller shaft 3PP4083-6020P001 51112601 Bearing 4PP4083-6022P002 51607402 Hopping roller one-way clutch gear 4PB4083-6024P001 51228901 Registration roller 3PB4083-6030P001 53342401 Bearing (registration) 4PP4083-6031P001 51607501 Roller-Transfer B Assy 40437801 Bearing TR 40438001 Back-up roller...
  • Page 133 Table 8-1 Lower Base Unit (2/2) Name/Rating Part No. Remarks ODA Part No. FG plate (O.P.) 4PP4083-7663P001 Hopping roller rubber 4PB4122-1280P001 Diselectritication Film 3PB4083-6089P001 LED Contact 4PP4083-6173P001 Washer C 4PP4120-1210P001 Washer B 4PP4120-1209P001 Spacer-Bearing R 40392801 Spacer-Bearing L 40392901 Bias spring A 4PP4083-6065P001 Special parts for envelope * Sensor wire Assembly...
  • Page 134 Figure 8-2 Upper cover unit 134 / 40718401TH Rev.5...
  • Page 135 Table 8-2 Upper cover unit Name/Rating Part No. Remarks ODA Part No. Upper cover 1PP4128-1133P001 53070301 IC card cover 2PP4128-1155P001 53069301 Cover-Lid 40104801 135 / 40718401TH Rev.5...
  • Page 136 Figure 8-3 Base unit 136 / 40718401TH Rev.5...
  • Page 137 Table 8-3 Base unit Name/Rating Part No. Remarks ODA Part No. Base plate (adhension) 2PP4083-7672G001 809A3000001~ 51012901 810AXXXXXXX Plate Assy-Base 40919401 811AXXXXXXX~ Cassette guide (L) assy 3PP4083-7670G001 51011201 Cassette guide (R) assy 3PP4083-7671G001 51011301 Sensor plate (paper supply) 4PP4083-7667P001 51011401 Insulator 3PB4083-6144P001 51709401...
  • Page 138: Appendix A Rs-232C Serial Interface (Option)

    Appendix A RS-232C SERIAL INTERFACE (option) 1) Connector • Printer side 25-pin receptacle Type DB-25S (made by Canon) or equivalent • Cable side 25-pin plug Type DB-25S (made by Canon) Shell Type DB-C8-J10-F2-1 (made by Nihon Kouku Denshi) or equivalent Note: Plug shall be fixable with a lock screw.
  • Page 139 4) Signal Level • MARK polarity : -3V to -15V (LOGIC = 1) • SPACE polarity : +3V to +15V (LOGIC = 0) 5) Interface Circuit Receiving Circuit 75188 or equivalent OUTPUT INPUT +12V -12V INPUT Sending Circuit 75188 or equivalent OUTPUT INPUT OUTPUT...
  • Page 140 8) Interface Parameter Setting The following settings are possible by pressing the ENTER key, after selecting the display contents of the LCD of the operator panel by using the keys. Settings are retained even when the printer power is turned off. By pressing the ON LINE key, menu setting mode is completed and the printer returns to on- line state.
  • Page 141 Press the MENU key. Item Baud Rate Contents of Display Function 300 baud 600 baud BAUDRATE Ready 1200 1200 baud Contens 2400 2400 baud 4800 4800 baud 9600 9600 baud 19200 19200 baud Factory Setting: 9600 baud Press the MENU key. Item Bit Length DATABITS...
  • Page 142 Press the MENU key. Item Minimum BUSY Time MIN BUSY Contents of Display Function Ready 200 m SEC 200 ms Contents 1 SEC 1 sec (1000 ms) Factory Setting: 200 m SEC (PCL only) Press the ON LINE key. Setting completed. ON-LINE Ready XXX : PCL, AUTO, HEX DUMP, PRR or FX...
  • Page 143: Appendix B Centronics Parallel Interface

    2) Cable • Cable length 6 ft (1.8 m) max. (A Shielded cable composed of twisted pair wires is recommended for noise prevention.) Note: Cable is not supplied with the printer, and is not available from Oki. 143 / 40718401TH Rev.5...
  • Page 144 3) Table of Parallel I/F Signals Pin No. Signal name Signal direction Functions DATA STROBE Parallel data sampling strobe DATA BIT - 1 DATA BIT - 2 DATA BIT - 3 DATA BIT - 4 PR Parallel input and output data DATA BIT - 5 DATA BIT - 6 DATA BIT - 7...
  • Page 145 4) Signal Level • LOW 0 V to +0.8 V • HIGH +2.4 V to 5.0 V 5) Specifications Item Description Mode Compatibility mode, Nibble mode, ECP mode Data bit length 8 bits (in the compatibility mode) Input prime Valid/Invalid Receive buffer 8K, 20K, 50K, 100K, 1M Bytes Control...
  • Page 146 On-line → off-line switching timing by ON-LINE SW ON-LINE SW BUSY SELECT 100 ms max. Off-line → on-line switching timing by ON-LINE SW ON-LINE SW BUSY SELECT 0 min. ACKNOWLEDGE 100 ms max. 0.5 µs to 10 µs INPUT PRIME timing (when set to the effective INPUT PRIME signal) 50 µs min.
  • Page 147 7) Interface Parameter Setting The following settings are possible by pressing the ENTER key, after selecting the display contents of the LCD of the operator panel by using the keys. Settings are retained even when the printer power is turned off. By pressing the ON LINE key, menu setting mode is completed and the printer returns to on- line state.
  • Page 148 Press the MENU key. Item Direction of Data Transfer BI–DIRCT Contents of Display Function Ready Contents Bi-directional data transmission ENABLE Uni-directional data transmission DISABLE Factory Setting: ENABLE Press the MENU key. Item I-PRIME I–PRIME Contents of Display Function Ready Contents I-PRIME signal ignored I-PRIME signal effective Factory Setting: OFF...
  • Page 149: Appendix C Loop Test (Rs-232C Interface)

    Appendix C LOOP TEST (RS-232C INTERFACE) 1) Connect the test connector DB-25S made by Cannon or equivalent Test Connector Connection Diagram 2) Select "LOOP Test" in the system maintenance mode. The codes transmitted from the TD signals are comparatively checked with the data received from the RD signals.
  • Page 150: Appendix D Diagnostics Test

    Appendix D DIAGNOSTICS TEST Maintenance Modes • The maintenance modes consist of the user maintenance mode which are released to the user, and the system and engine maintenance modes in the maintenance personnel level not released to the user. • Press the MENU key to update each category.
  • Page 151 (5) Operator Panel Menu Disable • This function is for enabling and disabling the operation panel menu functions (Menu 1, Menu 2, Tray Select, Copies and Paper Size). LCD display USER MNT Press the After the completion MENU key. Press the of processing ENTER key.
  • Page 152 System Maintenance Mode To enter the system maintenance mode, turn the power on while keeping the Recover key pressed • down. • This mode adopts the menu for function selection. • The system maintenance mode provides the following functions: (1) Page Count Display •...
  • Page 153 • The following items are excluded: Head drive time setting Fine adjustment of printing start position Standard tray paper feed amount setting • Transition to the operation mode occurs upon completion of resetting. • Press the MENU key to update each category. The operation returns to the first category after updating the last category, in a loop.
  • Page 154 Engine Maintenance Mode • The engine maintenance mode is activated when the power is turned ON while keeping the FORM FEED key and ENTER key pressed down. • This mode adopts the menu for function selection. • The method for exit from this mode depends on the setting. •...
  • Page 155: Engine Maintenance Mode Menu System

    • Engine maintenance mode menu system LCD display ENG MNT Writing into the EEPROM is performed after No. 1 Press the pressing the ENTER key. Press the ON LINE key No. 4 key. LED HEAD if you wish to get out of this mode. No.
  • Page 156 0 mm * Press the + 1 mm key. Do not change the default setting. T2 POS + 7 mm 0 mm* - 8 mm Press the - 1 mm MENU key. Press the key. Do not change the default setting. T2 TBL No.
  • Page 157 User Factory Set Operation The desired destination can be set by turning the power on while depressing two keys corresponding to the destination according to the following table. This function shall not be open for users. Destination Keys to be Depressed MENU MENU INT A (A4)
  • Page 158: Appendix E Multi Purpose Feeder Maintenance

    APPENDIX E MULTI PURPOSE FEEDER MAINTENANCE OUTLINE Functions This Multi-Purpose Feeder is installed on the front section of the printer, and it supplies paper automatically through the operation of pulse motor, which is driven by signals sent from the printer. The main functions are the followings: •...
  • Page 159: Mechanism Description

    MECHANISM DESCRIPTION General Mechanism The Multi-Purpose Feeder feeds the envelopes and paper into the printer by receiving the signal from the printer, which drives the pulse motor inside the Multi-Purpose Feeder, and this motion is transmitted to rotate roller-A and B. The envelope or paper is delivered from the separator into the printer. Once delivered into the printer, the envelope or paper is then controlled and fed through by pulse motor (registration) of the printer.
  • Page 160: Parts Replacement

    PARTS REPLACEMENT This section covers the procedures for the disassembly, reassembly and installations in the field. This section describes the disassembly procedures, and for reassembly procedures, basically proceed with the disassembly procedures in the reverse order. Precautions Concerning Parts Replacement (1) Parts replacements must be carried out, by first turning the printer power switch off “O”...
  • Page 161 [Service Tools] Table 3-1 shows the tools required for the replacement of printed circuit boards, assemblies and units in the field. Table 3-1 Service Tools Service Tools Q'ty Application Remarks No. 1-100 Philips 2 ~ 2.5 mm screws screwdriver No. 2-100 Philips 3 ~ 5 mm screws screwdriver No.
  • Page 162: Parts Layout

    Parts Layout This section describes the layout of the main components. Upper Frame Pulse Motor Link Roller-A Roller-B OLEV-11-PCB Separator Figure 3-1 162 / 40718401TH Rev.5...
  • Page 163: Parts Replacement Methods

    Parts Replacement Methods This section describes the parts replacement methods for the components listed in the disassembly order diagram below. Multi-Purpose Feeder Link (3.3.1) Separator (3.3.2) OLEV-11-PCB (3.3.3) Pulse motor (3.3.4) Planet gear (3.3.5) Roller-A (3.3.6) 163 / 40718401TH Rev.5...
  • Page 164: Link

    3.3.1 Link (1) Open paper feed cover 1, and disengage the paper feed cover 1 and link 3, while lifting the paper hold 2. (2) Remove the paper hold 2 off the arm 4. (3) Disengage the link 3 from the arm 4, and remove it. * Be careful not to deform the link and arm.
  • Page 165: Separator

    3.3.2 Separator (1) Turn the power switch off “O” and remove the connector cable. (2) Disengage the link and paper feeder cover (see 3.3.1). (3) Remove 2 screws 1, disengage the locks at 2 locations on the upper frame 2 with a screwdriver, and remove the upper frame 2.
  • Page 166: Olev-11-Pcb

    3.3.3 OLEV-11-PCB (1) Remove the upper frame [ see 3.3.2 steps (1) through (3) ]. (2) Remove the connector 1. (3) Remove 2 screws 2, and remove the OLEV-11 PCB 3. When reinstalling the printed circuit board, be careful to make sure that the sensor plate is being set correctly.
  • Page 167: Pulse Motor

    3.3.4 Pulse Motor (1) Remove the upper frame [ see 3.3.2 steps (1) through (3) ]. (2) Remove the OLEV-11-PCB (see 3.3.3). (3) Remove 2 screws 1, and remove the pulse motor 2. 167 / 40718401TH Rev.5...
  • Page 168: Planet Gear

    3.3.5 Planet Gear (1) Remove the upper frame [ see 3.3.2 steps (1) through (3) ]. (2) Remove the OLEV-11-PCB (see 3.3.3). (3) Remove 2 screws 1, and remove the motor bracket assembly 2 and planet gear 3. 168 / 40718401TH Rev.5...
  • Page 169: Roller-A And B

    3.3.6 Roller-A and B While only the removal procedure for roller-A is described here, the removal procedure for roller-B is basically same. When removing roller-B, however, be careful not to deform the sensor plate. (1) Remove the upper frame [ see 3.3.2 steps (1) through (3) ]. (2) Remove the separator assembly (see 3.3.2).
  • Page 170: Troubleshooting

    TROUBLESHOOTING Precautions Prior to the Troubleshooting (1) Go through the basic checking items provided in the Printer Handbook. (2) Obtain detailed information concerning the problem from the user. (3) Go through checking in the conditions similar to that in which the problem occurred. Preparations for the Troubleshooting (1) Display on the operator panel The status of the problem is displayed on the LCD (Liquid Crystal Display) on the operator panel.
  • Page 171: Troubleshooting Method

    Troubleshooting Method When a problem occurs, go through the troubleshooting according to the following procedure. Problem occurs Problem displayed by Troubleshooting Carry out detailed the LCD message according to the LCD troubleshooting Status Message List according to the (see 4.3.1) Troubleshooting Flow (see 4.3.1) 4.3.1...
  • Page 172 • ( JAM error ) Paper Inlet Jam • Does paper jam at the inlet when the power is turned on? • YES Is the paper located above the sensor plate (inlet)? • YES Remove the paper. • NO Is the sensor plate (inlet) operating normally? •...
  • Page 173: Connection Diagram

    CONNECTION DIAGRAM Interconnection Diagram Pulse motor 2 M-T3 1 M-T4 4 M-T1 3 M-T2 OLEV - 11-PCB To the Printer or High Capacity Second Paper Feeder 173 / 40718401TH Rev.5...
  • Page 174: Pcb Layout

    PCB Layout OLEV-11-PCB SEN2 174 / 40718401TH Rev.5...
  • Page 175: Parts List

    PARTS LIST Figure 6-1 Multi-Purpose Feeder 175 / 40718401TH Rev.5...
  • Page 176 Table 6-1 Multi-Purpose Feeder Description OKI-J Part No. ODA Part No. Q'ty Remark Roller-A 3PB4083-5514P001 Roller-B 3PB4083-5524P001 Planet gear 4PP4083-5520P001 Link 3PP4083-5540P001 Separator 4PP4083-5544G001 Pulse motor 4PB4083-6075P001 Same as printer unit. OLEV-11-PCB 4YA4121-1014G011 Connector cable 3YS4011-3141P003 For ODA 3YS4011-3141P001 For OEL/INT...
  • Page 177: Appendix F High Capacity Second Paper Feeder

    APPENDIX F HIGH CAPACITY SECOND PAPER FEEDER OUTLINE Functions The printer is mounted on top of this High Capacity Second Paper Feeder. The High Capacity Second Paper Feeder supplies paper automatically through the operation of pulse motor (hopping), which is driven by signals sent from the printer.
  • Page 178: Mechanism Description

    MECHANISM DESCRIPTION General Mechanism The High Capacity Second Paper Feeder feeds the paper into the printer by receiving the signal from the printer, which drives the pulse motor inside the High Capacity Second Paper Feeder, and this motion is transmitted to rotate the one-way clutch of the hopping frame assembly. The paper is delivered from the hopper into the printer through the turning of the hopping roller and feed roller.
  • Page 179: Parts Replacement

    PARTS REPLACEMENT This section covers the procedures for the disassembly, reassembly and installations in the field. This section describes the disassembly procedures, and for reassembly procedures, basically proceed with the disassembly procedures in the reverse order. Precautions Concerning Parts Replacement (1) Parts replacements must be carried out, by first turning the printer power switch off “O”...
  • Page 180 [Service Tools] Table 3-1 shows the tools required for the replacement of printed circuit boards, assemblies and units in the field. Table 3-1 Service Tools Service Tools Q'ty Application Remarks No. 1-100 Philips 2 ~ 2.5 mm screws screwdriver No. 2-100 Philips 3 ~ 5 mm screws screwdriver No.
  • Page 181: Parts Layout

    Parts Layout This section describes the layout of the main components. Cassette Assy Upper Plate Hopping Roller Assy Guide R (2nd) Assy (includes stepping motor and TQSB-2 PCB) One-way Clutch Gear Hopping Frame Assy Stepping Motor Guide L (2nd) Assy Figure 3-1 181 / 40718401TH Rev.5...
  • Page 182: Parts Replacement Methods

    Parts Replacement Methods This section describes the parts replacement methods for the components listed in the disassembly order diagram below. High Capacity Paper Feeder Stepping motor (hopping) (3.3.1) TQSB-2 PCB (3.3.2) Hopping roller shaft assy and One-way clutch gear (3.3.3) 182 / 40718401TH Rev.5...
  • Page 183: Stepping Motor (Hopping)

    3.3.1 Stepping Motor (Hopping) (1) Turn the printer power switch off, pull out the AC cord from the outlet. Remove the printer off High Capacity Second Paper Feeder. (2) Take the paper cassette assy 1 out of High Capacity Second Paper Feeder. (3) Remove six screws 2 and remove the upper plate 3.
  • Page 184 (6) Remove three screws 9 which are holding the guide R (2nd) assy 0 to the bottom plate A. Remove the screw B which is keeping the rear cover C and guide R (2nd) assy 0. Remove the guide R (2nd) assy 0. (7) Remove the protect (M) D, guide bracket E, planet gears F and planet gear bracket G.
  • Page 185: Tqsb-2 Pcb

    3.3.2 TQSB-2 PCB (1) Remove the pulse motor (see 3.3.1). (2) Remove the connector O from the TQSB-2 PCB P. (3) Remove the screw Q and remove the TQSB-2 PCB P. Note : Refer to Detall A in the previous page. 3.3.3 Hopping Roller Shaft Assy and One-way Clutch Gear (1) Follow up to step (3) of 3.3.1 and remove the hopping frame assy.
  • Page 186: Troubleshooting

    TROUBLESHOOTING Precautions Prior to the Troubleshooting (1) Go through the basic checking items provided in the Printer Handbook. (2) Obtain detailed information concerning the problem from the user. (3) Go through checking in the conditions similar to that in which the problem occurred. Preparations for the Troubleshooting (1) Display on the Operator panel The status of the problem is displayed on the LCD (Liquid Crystal Display) on the Operator panel.
  • Page 187: Troubleshooting Method

    Troubleshooting Method When a problem occurs, go through the troubleshooting according to the following procedure. Problem occurs Problem displayed by Troubleshooting Carry out detailed the LCD message according to the LCD troubleshooting Status Message List according to the (see 4.3.1) Troubleshooting Flow (see 4.3.1) 4.3.1...
  • Page 188 • ( JAM error ) Paper Inlet Jam • Does paper jam at the inlet when the power is turned on? • YES Is the paper located above the sensor plate (inlet)? • YES Remove the paper. • NO Is the sensor plate (inlet) operating normally? •...
  • Page 189: Connection Diagram

    CONNECTION DIAGRAM Interconnection Diagram Stepping motor 2 M-T3 1 M-T4 "MOTOR" 4 M-T1 3 M-T2 TQSB-2 PCB "PU" To Printer 189 / 40718401TH Rev.5...
  • Page 190: Pcb Layout

    PCB Layout TQSB-2 PCB MOTOR MOTOR CONTROLLER DRIVER SEN2 190 / 40718401TH Rev.5...
  • Page 191: Parts List

    PARTS LIST Figure 6-1 High Capacity Second Paper Feeder 191 / 40718401TH Rev.5...
  • Page 192 Table 6-1 High Capacity Paper Feeder Description OKI-J Part No. Q'ty Remark Hopping roller shaft assy 3PA4122-1367G001 One-way clutch gear 4PB4122-1382P001 Stepping motor 3PB4122-1399P001 TQSB-2 PCB 4YA4046-1651G002 Cassette assy (2nd tray) 1PA4122-1362G004 192 / 40718401TH Rev.5...
  • Page 193 2nd Tray ASSEMBLY SECTION1 CABINET & CASSETTE ASSEMBLY SECTION2 MECHANICAL ASSEMBLY SECTION1 CABINET & CASSETTE ASSEMBLY 193 / 40718401TH Rev.5...
  • Page 194 SECTION1 CABINET & CASSETTE ASSEMBLY 194 / 40718401TH Rev.5...
  • Page 195 SECTION2 MECHANICAL ASSEMBLY 195 / 40718401TH Rev.5...
  • Page 196 Table 6-2 2nd Tray Parts List Description OKI Parts No. Q'ty/U 1000 Plate, upper 1PP4122-1401P001 Sheet guide assembly 3PA4122-1370G001 Front cover assembly 1PA4122-1369G001* Inner guide assembly 3PA4122-1371G001 Cassette assembly (2nd tray) 1PA4122-1362G004*** Separation frame assembly 4PP4120-1009G001 Cover, rear 1PA4122-1323P001 Stick finger...
  • Page 197 *** For the rev. no. of the Parts List for the Cassette assembly (2nd tray) should be applied No.10. The No.10 includes a change of cassette and Tale Guide. Addition of projection part Addition of notch Addition of groove Addition of latch Tale Guide Cassette Note : Cassette and Tale Guide need concurrent replacing.
  • Page 198 OKIPAGE 10ex LED Page Printer Troubleshooting Manual with Component Parts List ODA/OEL/INT 1999. 1. 18 Rev.1 1 / 143 40990901TH Rev.1...
  • Page 199 CONTENTS OUTLINE......................3 TOOLS ......................3 CIRCUIT DESCRIPTION ................4 TROUBLESHOOTING ..................35 CIRCUIT DIAGRAM ..................61 COMPONENT PARTS LIST .................96 40990901TH Rev.1...
  • Page 200: Outline

    OUTLINE This manual has been written to provide guidance for troubleshooting of the OKIPAGE 10ex Printer (primarily for its printed circuit boards), based on the assumption that the reader has a thorough knowledge concerning the printer. Read the maintenance manual for this printer, if necessary.
  • Page 201: Circuit Description

    Its block diagram is shown in Fig. 3-1 . (1) Reception control The OKIPAGE 10ex Printer can be equipped with one I/F port by adding an RS232C I/F option board in addition to the Centronics I/F on the main control board.
  • Page 202 1MB Memory Board RS232C Interface Board (Option) (Option) Main Control Board For optional board Multi-Purpose Feeder (Option) Program & Font ROM Resident RAM 6MB Mask ROM 512K x 8 bit DRAM High Capacity DATA (2MB) Second Paper Feeder (Option) (32bit) EEPROM Operation Panel Centronics...
  • Page 203 A2 to A23 D0 to D31 PD2, 3 CAS0 to CAS3 RAS2 RAS3, 4 RAS2 to RAS4 ORE, RD, CS3, EEPCS, EECLK EEPDAT IOS1 Figure 3-2 Memory Expansion Board Block Diagram (Option) 40990901TH Rev.1...
  • Page 204 A2 to A23 D0 to D31 PD2, 3 CAS0 to CAS3 RAS3, 4 RAS2 to RAS4 ORE, RD, CS3, EEPCS, EEPCLK EEPDAT IOS1 RS-232C CONNECTOR TXD, RST, DTR Figure 3-3 RS-232C Serial Interface Board Block Diagram (Option) 40990901TH Rev.1...
  • Page 205 CPU and Memory (1) CPU (MHM2029-004K) CPU core RISC CPU (MIPS R3000 compatible) CPU clock 7.067 MHz Internal CPU CLK 28.268 MHz (2) Program and Font ROMs ROM capacity 6M bytes (24M bit mask ROM two pieces) ROM type 24M bits (1.5M x 16 bits) Access time 100 ns (3) Resident RAM...
  • Page 206 D00 to D32 Option board IC2, IC3 Mask ROM A00 to A25 (1.5M x 16 bits) 2 pieces <Program> RAS0 RAS1 RAS2 RAS3 RAS4 RAS5 IC4, IC5, IC6, IC7 RAS0 CAS0 DRAM CAS1 (512 k x 8 bits) CAS2 4 pieces CAS3 RD/WR Main...
  • Page 207 Figure 3-5 Timing Chart of CPU & Memory Circuit 10 / 40990901TH Rev.1...
  • Page 208: Reset Control

    Reset Control When power is turned on, a CLRST-N signal is generated by the rising sequence of +38V and +8V power supply. +38V +8V (15V) – IC10 To Option Board Power OFF Power ON +38V +38V IC10-11 IC10-10 Q10 Input CLRST-N 11 / 40990901TH Rev.1...
  • Page 209 EEPROM Control The 93LC46A is an electrical erasable/programmable ROM of 64-bit x 16-bit configuration. Data input to and output from the ROM are bidirectionally transferred in units of 16 bits through a serial I/O port (SSTXD-P) in serial transmission synchronized with a clock signal from the CPU. The EEPROM operates in the following instruction modes SSTXD-P EEPRMCS0-P...
  • Page 210: Centronics Parallel Interface

    Centronics Parallel Interface The CPU sets a BUSY-P signal to ON at the same time when it reads the parallel data (PDATA1- P to PDATA 8-P) from the parallel port at the fall of PSTB-N signal. Furthermore, it makes the store processing of received data into a receive buffer terminate within a certain fixed time and outputs an ACK-N signal, setting the BUSY-P signal to OFF.
  • Page 211 Operator Panel Control The operator panel consists of the following circuits. OLCC-2 Main control board PANEL BU6152S SSTXD-P 44780 DB4~DB7 SSRXD-P Control Driver SSCLK-N SSLD-N Zebra Rubber Flexible Cable (1) BU6152S (LSI) This LSI is connected to a clock synchronous serial port of the CPU. It controls switch data input, LED data output and LCD data input/output according to the commands given by the CPU.
  • Page 212 LED Head Control An LED correcting head, which is capable of correcting the illumination of the LED for each dot, is being used in this printer. LED illumination correction function of 16 steps is carried out by using an EEPROM which is installed in the LSI that maintains the LED illumination correction values, and an LED correction drivers (MSM6731BWAF or MSM6732BWAF) together as a pair.
  • Page 213 Normal Mode Printing Timing Chart CLOCKI LOADI DATAI3~0 STRB1I-N STRB2I-N STRB3I-N STRB4I-N First line printing data sent Second line printing data sent First line printing The printing operation is carried out in the following sequence. First, the printing data DATAI3 through DATAI0 are stored, sequentially shifted, in the shift registers of the LED drivers, by the printing data synchronous clock, CLOCKI.
  • Page 214: Motor Control

    Motor Control (1) Registration and main (drum) motors A registration motor and a drum motor are driven by means of control signals from the CPU and a driver IC. Main Control Board +38V A2918SW DMPH1-P DMPH1-N 1 Main (Drum) Motor DMPH2-P DMPH1-P 2 DMPH2-N 3...
  • Page 215 (3) Registration motor RMON-N RMPH1-P RMPH2-P Stop Forward rotation Reverse rotation Rotation Hopping drive Registration roller drive Operation at normal speed: T0 to T3 = 1.016 ms (4) Drive control Time T0 to T3 determines the motor speed, while the difference of phase direction between phase signals DMPH1-P and DMPH2-P (RMPH1-P and RMPH2-P) determines the rotation direction.
  • Page 216: Fuser Temperature Control

    Fuser Temperature Control For the temperature control by heater control, the variation in the resistance of the thermistor is A/D converted in IC2 and the resultant digital value is read and transferred to the CPU. The CPU turns on or off the HEATON-N signal according to the value of the signal received from IC2 to keep the temperature at a constant level.
  • Page 217 The temperature control is described below. Temperature ˚C HEATON-N 176˚C * The values V1 and V2 vary according to setting mode. 175˚C (Standard temperature) When Vt rises to V2 or more, the heater is turned off (by setting HEATON-N signal to LOW). When Vt drops to V1 or less, the heater is turned on (by setting HEATON-N signal to HIGH).
  • Page 218 For heater breakdown detection, the heater must first be turned on. When a temperature rise which corresponds to the switching on of the heater does not occur, then a heater breakdown is detected. To shorten the breakdown detection time, the following circuit is used. Immediately after the power is turned on, the thermistor is checked and THERM-CMP signal is turned on to turn the resistor Q44 on.
  • Page 219: Fan Motor Control

    3.10 Fan Motor Control The stop/rotation of the fan motor is controlled by FANON1-P and FANON2-N signals. When the fan motor rotates normally, FANALM-P signal generated in the hole element built in the fan motor is input to the CPU. TR503 R554 TR504...
  • Page 220 3.11 Cover Open When the cover is opened, a cover open microswitch is opened. This makes a CVOPN-N signal low, thereby the CPU detects the open state. Furthermore, opening the cover stops applying a +5V power to the high voltage power supply unit, resulting in stopping all high voltage outputs. Main Control Board Power Supply Board High...
  • Page 221 3.12 Power Supply Board (1) Low voltage power supply An AC power from an inlet is input to a transformer via fuses, AC switch and noise filter and then lowered to a 32 VAC power and a 10 VAC power. The 32 VAC power is converted to a +38 VDC output through a rectifying/smoothing circuit.
  • Page 222 (3) Sensor control Power Supply Board Main Control Board PSOUT-N WRSNS-N PAPER-N PSIN1-N TNRSNS-N PSIN2-N Sensor signal Shield Transparent 25 / 40990901TH Rev.1...
  • Page 223 (4) High-voltage power supply circuit This high-voltage power supply circuit receives the high-voltage generation timing control command that is transmitted in serial through the power supply interface from the control section. It decodes this command by LSI (IC2) and outputs high-frequency pulses to the corresponding high-voltage generating circuits through pins 11, 12, 13, 14 and 15 of LSI (IC2).
  • Page 224 3.13 Option Tray Control The kinds of option trays, High capacity Second Paper Feeder and Multi purpose Feeder can be connected to the printer. The trays are distinguished by two digit ID numbers. The option trays and the printer communicate with each other through bi-directional clock synchoronized serial interface.
  • Page 225 TQSB-2 (Option) Main Control board 2ND TRAY 65-43 OPTSD-P OPTSCLK-N OPTSDR-N OPTSIN-N MS4646 270Ω 560Ω High capacity Second Paper Feeder SEN1 SEN2 OLEV-(Option) (Paper) (Cover Open) 0C 13 ENVELOPE 65-43 OPTSD-P OPTSCLK-N OPTSDR-N OPTPSIN-N MS4646 1, 2 3, 4 SEN2 (Paper) Multi purpose Feeder Option Tray Connection and Block Diagram...
  • Page 226 Option Tray Control Serial Interface Time Chart Command (CPU→Tray) Reply (Tray→CPU) Next Command (CPU→Tray) OPTSD-P b7 b6 b5 b4 b3 b2 b1 b0 b6 b5 b4 b3 b2 b1 b7 b6 b5 b4 b3 b2 b1 b0 OPTSCLK-N OPTSDR-N 1.5µS Min.
  • Page 227 Motor Control Time Chart Motor on (C2) Phase change (C1, C0) Paper sensor (OPTPSIN-N) # of Phase changes after paper sensor detection is downloaded by CPU Triggered by CPU Automatically stops Option Tray Motor Control Time Chart...
  • Page 228 3.14 Memory Expansion Option Board A2 to A23 D0 to D31 PD2, 3 CAS0 to CAS3 RAS2 RAS3, 4 RAS2 to RAS4 ORE, RD, CS3, EEPCS, EEPCLK EEPDAT IOS1 Memory Expansion Board Block Diagram (Option) The Memory Expansion Option Board is provided with two DRAM chips and two SIMM slots. The SIMM1 slot is used for installation of a DRAM SIMM.
  • Page 229 3.15 RS-232C Serial Interface Option Board A2 to A23 D0 to D31 PD2, 3 CAS0 to CAS3 RAS3, 4 RAS2 to RAS4 ORE, RD, CS3, EEPCS, EEPCLK EEPDAT IOS1 RS-232C CONNECTOR TXD, RST, DTR RS-232C Serial Interface Board Block Diagram (Option) The RS-232C Serial Interface Option Board is provided with a RS-232C I/F and two SIMM slots.
  • Page 230 (1) RS-232C Interface The serial data RXD from the host system, whose line voltage is clamped at the TTL level by D4/D512, are received by the CPU built-in serial controller. DSR and CTS signals are terminated through 5.6kΩ resistors. Send signals TXD, RTS and DTR are put out from the CPU and are sent to lines through a line driver IC (75188).
  • Page 231 (2) SIMM Memory Module The board is provided with two Slots for a 72-pin DRAM SIMM Memory Module and Flash SIMM. The SIMM1 slot is used for installation of a 72-pin DRAM SIMM Memory Module. Up to 6 types of SIMM Memory Module can be installed. 1M byte, 2M bytes, 4M bytes, 8M bytes, 16M bytes and 32M bytes.
  • Page 232: Troubleshooting

    TROUBLESHOOTING Troubleshooting Table (A) Power Supply Board (OL1- or OL2-PCB) Note: The malfunction of the power supply is not repaired by an agency. The abnormality to be treated here is that of sensors only. Flowchart Failure LCD Message Paper input jam occurs frequently. A - 1 #: TRAY1, TRAY2, FEEDER, MANUAL I N P U T J A M...
  • Page 233 Main Control Board (1/2) Flowchart Failure LCD Message Abnormal message display on the LCD B - 1 (no display, unclear display, display with some dot not lit). Program ROM error. B - 2 E R R O R Font ROM error. B - 3 E R R O R Resident RAM error.
  • Page 234 Main Control Board (2/2) Flowchart Failure LCD Message Processor error. B - 13 E R R O R Print overrun occurs frequently. B - 14 P R I N T O V E R R U N Error host I/F occurs frequently. B - 15 H O S T I / F...
  • Page 235 Operator Panel Board (OLCC-2-PCB) Flowchart Failure LCD Message Abnormal message display on the LCD C - 1 (no display, unclear display, display with some dot not lit, etc.) The key switch operation on the operator C - 2 panel is disabled. The LCD does not display any message.
  • Page 236 Multi purpose feeder (OLEV) Flowchart Failure LCD Message Paper input jams occur frequently. E - 1 F E E D E R I N P U T J A M Paper out occurs even if the papers are in E - 2 F E E D E R cassette or a tray.
  • Page 237 Troubleshooting Flowchart Paper input jam occurs frequently. • Is PS3 (Inlet Sensor 1) operating normally? • No Replace PS3. • Yes Is PS5 (Inlet Sensor 2) operating normally? • No Replace PS5. • Yes Replace IC2 (LC26023A). Paper feed jam occurs frequently. •...
  • Page 238 Paper size error occurs frequently. • Is PS3 (Inlet Sensor 1) operating normally? • No Replace PS3. • Yes Is PS5 (Inlet Sensor 2) operating normally? • No Replace PS5. • Yes Replace IC2 (LC26023A). The message “TRAY PAPEROUT” remains displayed on the LCD •...
  • Page 239 The printer does not function at all, and the LCD does not display any messages. • Is fuse F1 open? • Yes Replace F1. • No Is the voltage waveform between Pins 1 and 3 of the connector (CN2) same as the waveform shown below? CH1 + CH1: DC 20V/div.
  • Page 240 • No Replace the transistor Q1. • Has the problem been solved? • Yes End. • No Replace the transistor Q2. • Has the problem been solved? • No Replace IC1 (FA7617P-1). • Yes Check the connection between the power supply board and main control board.
  • Page 241 A-11 Serial interface does not connect to the host device. • Is the voltage waveform between Pins 5 and 6 of the connector (CN2) same as the waveform shown below? CH1 + CH1: DC 5V/div. Normal 5ms/div. • No Replace the transformer T1. •...
  • Page 242 Abnormal message display on the LCD. • Replace IC2, IC3. • Has the problem been solbed? • Yes End. • No Is the 7.067-MHz clock signal being sent to Pin 3 of OSC1? • No Replace OSC1 (CST 7.067MTW). Is the output at Pin 13 (CLRST-N) of IC10 (NJM2901 or µPC339G2) normal •...
  • Page 243 Option RAM error (ERROR 60). • The MENU PRINT memory capacity does not increase even when an expansion memory board is installed. • Are negative pulses being sent to Pin 83 (DRAS2-N), Pin 84 (DRAS3-N), Pin 85 (DRAS4-N), Pin 86 (DRAS5-N) of the connector (OPTION)? •...
  • Page 244 B-10 Option tray I/F timeout error (ERROR 81). • Is the connection at the connector (2NDTRAY) properly engaged? • No Replace the connector (2NDTRAY). • Yes Is the connection at the connector (ENVELOPE) properly engaged? • No Replace the connector (ENVELOPE). B-11 Watchdog timer timeout error occurs frequently (ERROR 90), or illegal CPU version (ERROR 91).
  • Page 245 B-14 Print overrun occurs frequently. • Is an option board mounted? • Yes Go to the flowchart B-6. • No Set DRAM SIMM Memory Module on an option board, then mount it to the printer. • Has the problem been solved? •...
  • Page 246 B-17 Paper input jam. • Is the hopping motor rotating normally? • No Are the waveforms of RMPH1-P and RMPH2-P signals as shown in Section 3.9 (2) being sent to Pins 26 and 17 of IC8 (MTD2005F) respectively? • No Failure of IC1 (MHM2029-004K).
  • Page 247 B-18 Paper feed jam occurs frequently. • Is the main (drum) motor rotaing normally? • No Are the waveforms of DMPH1-P and DMPH2-P as shown in Section 3.9 (1) being sent to Pins 13 and 8 of IC9 (A2918SW) respectively? •...
  • Page 248 B-21 Data sent through the centronics I/F cannot be received. • Is the signal at Pin 11 (BUSY-P) of the connector (CENT) low? • No Is the signal at Pin 3 (PBUSY-P) of IC11 (7407) change at data reception as shown below? ON-LINE OFF-LINE PBUSY-P...
  • Page 249 Abnormal message display on the LCD (no display, unclear display, display with some dot not lit, etc.) • Is +5V power being supplied to Pin 8 of IC1 (BU6152S)? • No Replace CN1. • Yes Is the CLOCK signal being sent to Pin 26 (OP-CLOCK-N) of IC1 (BU6152S)? •...
  • Page 250 The key switch operation on the operator panel is disabled. • Do the signals at Pins, 3, 7, 10, 18, 23, 31 of IC1 (BU6152S) change from high to low level by key switch pushing? • No Replace SW1 to SW8. •...
  • Page 251 Display on the LCD with some dot not lit. • Are 4.15V, 3.3V, 2.46V, 1.61V, and 0.77V powers being supplied respectively to Pins 26, 27, 28, 29 and 30 of IC2 (HD44780)? • No Replace R5 through R10. (OLCC-PCB) • Yes Is the COM signal being sent to Pins 47 through 62 (COM01 to COM16) of IC2 (HD44780)? •...
  • Page 252 Paper input jams occur frequently. • Has the fuse F1 opened? • No Is the high voltage (around 38V being sent to Pin 2 of D1 and Pin 2 of D2? • No Replace D1 or D2. • Yes Is the signal level at Pin 22 of IC2 at low level? •...
  • Page 253 The printer does not recognize High capacity Second Paper Feeder. • Do signal levels at Pin 2 (OPTSCLK-N) and 3 (OPTSD-P) PU alter at power-up time? • No Replace Cable. • No Replace D1 or D2. • Yes Do signal levels at Pin 4, 7, and 9 of IC2 alter at power-up time? •...
  • Page 254 Paper input jams occur frequently. • Is the motor rotating? • No Has the fuse F1 opened? • No Is the high voltage (around 38V) being sent to Pin 2 of D1 and Pin 2 of D2? • No Replace D1 or D2. •...
  • Page 255 The printer does not recognize Multi Purpose Feeder. • Do signal levels at Pin 2 (OPTSCLK-N) and 3 (OPTSD-P) CN1 alter at power-up time? • No Replace Option Tray Cable. • Yes Do signal levels at Pin 4, 7, and 9 of IC2 alter at power-up time? •...
  • Page 256 Option RAM error (ERROR 60) • Remove the DRAM SIMM. Has the problem been solved? • Yes Failure of DRAM SIMM. • Are negative pulses being sent to Pin 83 (DRAS2-N), Pin 84 (DRAS3-N), Pin 85 (DRAS4-N), Pin 86 (DRAS5-N) of the connector (CN1)? •...
  • Page 257 Error host I/F occurs frequently. • Is the connection at the connector (CN2) properly engaged? • No Replace the connector (CN2). • Yes Is the voltage at Pin 14 of Q11 (75188) about +8V and the voltage at Pin 1 of Q11 (75188) about -8V? •...
  • Page 258: Circuit Diagram

    5. CIRCUIT DIAGRAM 61 / 40990901TH Rev.1...
  • Page 259 CIRCUIT DIAGRAM Figure 5-1(1/11~11/11) Main Control Board (M5B-PCB, Rev.5) (40217002) Figure 5-2(1/1) Operator Panel Board (OLCC-2-PCB, Rev.4) (4YA4130-1001G002) Figure 5-3(1/4~4/4) Power Supply Board (OL1-PCB, Rev.6) (40217701) Figure 5-4(1/4~4/4) Power Supply Board (OL2-PCB, Rev.6) (40217702) Figure 5-5(1/1) High Capacity Second (TQSB-2-PCB, Rev.1) (4YA4046-1651G002) Paper Feeder Board Figure 5-6(1/2~2/2) Multi Purpose Feeder...
  • Page 260 Figure 5-1 Main Control Board (M5B-PCB, Rev.5) (1/11) 63 / 40990901TH Rev.1...
  • Page 261 Figure 5-1 Main Control Board (M5B-PCB, Rev.5) (2/11) 64 / 40990901TH Rev.1...
  • Page 262 Figure 5-1 Main Control Board (M5B-PCB, Rev.5) (3/11) 65 / 40990901TH Rev.1...
  • Page 263 Figure 5-1 Main Control Board (M5B-PCB, Rev.5) (4/11) 66 / 40990901TH Rev.1...
  • Page 264 Figure 5-1 Main Control Board (M5B-PCB, Rev.5) (5/11) 67 / 40990901TH Rev.1...
  • Page 265 Figure 5-1 Main Control Board (M5B-PCB, Rev.5) (6/11) 68 / 40990901TH Rev.1...
  • Page 266 Figure 5-1 Main Control Board (M5B-PCB, Rev.5) (7/11) 69 / 40990901TH Rev.1...
  • Page 267 Figure 5-1 Main Control Board (M5B-PCB, Rev.5) (8/11) 70 / 40990901TH Rev.1...
  • Page 268 Figure 5-1 Main Control Board (M5B-PCB, Rev.5) (9/11) 71 / 40990901TH Rev.1...
  • Page 269 Figure 5-1 Main Control Board (M5B-PCB, Rev.5) (10/11) 72 / 40990901TH Rev.1...
  • Page 270 Figure 5-1 Main Control Board (M5B-PCB, Rev.5) (11/11) 73 / 40990901TH Rev.1...
  • Page 271 Figure 5-2 Operator Panel Board (OLCC-2-PCB, Rev.4) (1/1) 74 / 40990901TH Rev.1...
  • Page 272 Figure 5-3 Power Supply Board (OL1-PCB, Rev.6) (1/4) 75 / 40990901TH Rev.1...
  • Page 273 Figure 5-3 Power Supply Board (OL1-PCB, Rev.6) (2/4) 76 / 40990901TH Rev.1...
  • Page 274 Figure 5-3 Power Supply Board (OL1-PCB, Rev.6) (3/4) 77 / 40990901TH Rev.1...
  • Page 275 Figure 5-3 Power Supply Board (OL1-PCB, Rev.6) (4/4) 78 / 40990901TH Rev.1...
  • Page 276 Figure 5-4 Power Supply Board (OL2-PCB, Rev.6) (1/4) 79 / 40990901TH Rev.1...
  • Page 277 Figure 5-4 Power Supply Board (OL2-PCB, Rev.6) (2/4) 80 / 40990901TH Rev.1...
  • Page 278 Figure 5-4 Power Supply Board (OL2-PCB, Rev.6) (3/4) 81 / 40990901TH Rev.1...
  • Page 279 Figure 5-4 Power Supply Board (OL2-PCB, Rev.6) (4/4) 82 / 40990901TH Rev.1...
  • Page 280 Figure 5-5 High Capacity Second Paper Feeder Board (TQSB-2-PCB, Rev.1) (1/1) 83 / 40990901TH Rev.1...
  • Page 281 Figure 5-6 Multi Purpose Feeder Board (OLEV-PCB, Rev.4) (1/2) 84 / 40990901TH Rev.1...
  • Page 282 Figure 5-6 Multi Purpose Feeder Board (OLEV-PCB, Rev.4) (2/2) 85 / 40990901TH Rev.1...
  • Page 283 Figure 5-7 Memory Expansion Bord (MM6-PCB, Rev.4) (1/5) 86 / 40990901TH Rev.1...
  • Page 284 Figure 5-7 Memory Expansion Bord (MM6-PCB, Rev.4) (2/5) 87 / 40990901TH Rev.1...
  • Page 285 Figure 5-7 Memory Expansion Bord (MM6-PCB, Rev.4) (3/5) 88 / 40990901TH Rev.1...
  • Page 286 Figure 5-7 Memory Expansion Bord (MM6-PCB, Rev.4) (4/5) 89 / 40990901TH Rev.1...
  • Page 287 Figure 5-7 Memory Expansion Bord (MM6-PCB, Rev.4) (5/5) 90 / 40990901TH Rev.1...
  • Page 288 Figure 5-8 RS-232C Interface Board (SMIF-PCB, Rev.4) (1/5) 91 / 40990901TH Rev.1...
  • Page 289 Figure 5-8 RS-232C Interface Board (SMIF-PCB, Rev.4) (2/5) 92 / 40990901TH Rev.1...
  • Page 290 Figure 5-8 RS-232C Interface Board (SMIF-PCB, Rev.4) (3/5) 93 / 40990901TH Rev.1...
  • Page 291 Figure 5-8 RS-232C Interface Board (SMIF-PCB, Rev.4) (4/5) 94 / 40990901TH Rev.1...
  • Page 292 Figure 5-8 RS-232C Interface Board (SMIF-PCB, Rev.4) (5/5) 95 / 40990901TH Rev.1...
  • Page 293: Component Parts List

    6. COMPONENT PARTS LIST 96 / 40990901TH Rev.1...
  • Page 294 DRAWING LIST Main Control Board (M5B-PCB, Rev. 5) 40217002 Operator Panel Board (OLCC-2-PCB, Rev. 4) 4YA4130-1001G002 Power Supply Board (OL1-PCB, Rev. 6) 40217701 Power Supply Board (OL2-PCB, Rev. 6) 40217702 High Capacity Second (TQSB-2-PCB, Rev. 1) 4YA4046-1651G002 Paper Feeder Board Multi Purpose Feeder Board (OLEV-PCB, Rev.
  • Page 295 ENVELOPE 1 DM 4 1 RM 4 BF11 ICI2 REF. PANEL SYMBOL TYPE/NAME PART NO. Q'TY REMARKS 2ND TRAY EM10 EM12 EM14 EM16 EM18 EM20 2- 122 EM11 EM13 EM15 EM17 EM19 EM21 2- 123 IC13 IC10 A13(26) B13(25) B1(2) A1(1) POWER M5B-PCB Assy.
  • Page 296 M5B-PCB Assy. (Main Control Board) Rev. 5 (40217002-2/9) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS SB05-05CP 610A0332N0001 D-Rectifying D4, D503 SS100MA80VACP 611A0000N0001 D-Signal D501 SS100MA80VKCP 611A0000N0002 D-Signal RD15M-B2 613A0233M0222B D-Zener RD10F-B 613A2232L0182 D-Zener RM73B2A121F 323A5003F0121 RES-MET RN RM73B2A201F 323A5003F0201 RES-MET RN R549 RM73B2A202F 323A5003F0202...
  • Page 297 M5B-PCB Assy. (Main Control Board) Rev. 5 (40217002-3/9) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS R68~R75, R512, R513 RM73B2A100J 323A5003J0100 RES-MET RN R6~R8 RM73B2A101J 323A5003J0101 RES-MET RN R9~R14, R502, R510, RM73B2A102J 323A5003J0102 R521, R569, R570 RES-MET RN R15, R17, R507, R509, RM73B2A103J 323A5003J0103 R544, R562...
  • Page 298 M5B-PCB Assy. (Main Control Board) Rev. 5 (40217002-4/9) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS 323A5003J0241 R37~R45 RM73B2A241J RES-MET RN 323A5003J0242 RM73B2A242J RES-MET RN 323A5003J0270 R532 RM73B2A270J RES-MET RN 323A5003J0272 R47~R49 RM73B2A272J RES-MET RN R50~R57 RM73B2A331J 323A5003J0331 RES-MET RN R59, R543 RM73B2A332J 323A5003J0332 RES-MET RN...
  • Page 299 M5B-PCB Assy. (Main Control Board) Rev. 5 (40217002-5/9) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS 5:J-12YJ750 323A5019J0750 RES-MET RN R82, R83 MSF1/2B2ohmJ 324A1001J0209 RES-MET OX R84, R85 MSF1/2B0.5ohmJ 324A1001J0518 RES-MET OX RM9~RM16 MNR14ABJ101 334A5012J0101 RES-Block RM27 MNR14ABJ151 334A5012J0151 RES-Block RM17~RM21, RM24 CN1J4/EXBV8V22ohmJ 3345003J0220 RES-Block...
  • Page 300 M5B-PCB Assy. (Main Control Board) Rev. 5 (40217002-6/9) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS C19, C20, C31, C522, CK2012F1C105Z 303A6008Z1105 C530, C534, C542, CAP-Ceramic 1µF C557, C560, C567, C568 C21~C23, C25, C501, CK2012F1E104Z 303A6008Z2104 C506, C510, C537, CAP-Ceramic C538 CK2012F1H103Z 303A6008Z3103 CAP-Ceramic...
  • Page 301 M5B-PCB Assy. (Main Control Board) Rev. 5 (40217002-7/9) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS IC4~IC7 MSM514807C-70JS 8020024N2626 Memory-MOSDRAM-S IC12 93C46LDP-NW 8160303M0000 Memory-MOSEEPR MHM2029-004K-29 8510440N0001 CPU-MOS MX23C2410MC-10-101 8174627N0012 Memory-MOSMROM 8174627N0014 MX23C2410MC-10-107 Memory-MOSMROM 8174627N0016 MX23C2410MC-10-110 Memory-MOSMROM MX23C2410MC-10-100 8174627N0011 Memory-MOSMROM 8174627N0013 MX23C2410MC-10-106 Memory-MOSMROM 8174627N0015 MX23C2410MC-10-109...
  • Page 302 M5B-PCB Assy. (Main Control Board) Rev. 5 (40217002-8/9) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS TR501, TR503 DTC123YK 602A1035N0019 TR-NPN/H-FREQ 2SD1623S 603A1132N0001S TR-NPN/L-FREQ CENT 57RE-40360-830F-D29 2201001P0360 Connector-SQR ENVELOPE MD-S8000B-70 2211001P0080 Connector-RND POWER 128A-026P2B-L14N 224A3222P0261 Connector-PCB 00-8263-0412-00-000 224A3357P0040 Connector-PCB 00-8263-0412-00-003 224A3357P0041 Connector-PCB OPTION PQ100A2FA...
  • Page 303 M5B-PCB Assy. (Main Control Board) Rev. 5 (40217002-9/9) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS OSC1 CST7.06MTW040-TF01 3811000B0001 OSC-Ceramic 251-001 540A2208S1102 FUSE- 251-002 540A2218S1202 FUSE- S3, BF3, BF7, BF9, LINK WIRE 0.65 P=2.5 KH-31036-25 BF11 EM3, EM5~EM8 SHORT WIRE (U TYPE) KH-31036-50 POWER BAR LH-31313-5...
  • Page 304 REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS OLCC-2-Printed Circuit Board (Operator Panel Board) Rev. 4 (4YA4130-1001G002-1/3) 107 / 40990901TH Rev.1...
  • Page 305 OLCC-2-Printed Circuit Board (Operator Panel Board) Rev. 4 (4YA4130-1001G002-2/3) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS SEL3910D-YZ 650A0229M0018 C2~C5 CC2012CH1H101J 303A3007C0101 CC Capacitor (CP) C6, C7 CK2012F1E104Z 303A6008Z2104 CK Capacitor (CP) RM73B2A181J 323A5003J0181 RN Resistor (CP) R2~R4 RM73B2A201J 323A5003J0201 RN Resistor (CP) RM73B2A682J 323A5003J0682 RN Resistor (CP)
  • Page 306 OLCC-2-Printed Circuit Board (Operator Panel Board) Rev. 4 (4YA4130-1001G002-3/3) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS SW1~SW8 SOR-113HS 205A1165P1000 Push-button Switch ZC-106 224A3591P0060 PC Connector 109 / 40990901TH Rev.1...
  • Page 307 REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS OL1-PCB Assy. (Power Supply Board) Rev. 6 (40217701-1/9) 110 / 40990901TH Rev.1...
  • Page 308 OL1-PCB Assy. (Power Supply Board) Rev. 6 (40217701-2/9) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS TF341M 620A0026M0002 THY-Gate RBV-402/D3SBA20 610A1003M0001 D-Rectifying D7~D10 OR-D-Rectifying 40401401 D101~D104, D106~ EU02A/RL105F-F 6100003M0001 D109, D112, D113, D-Rectifying D119, D126 FML-12S 610A2226M0016 D-Rectifying D51, D114, D122, D123 1S953/1S2075K/1S2473 611A0003L0001 D-Signal...
  • Page 309 OL1-PCB Assy. (Power Supply Board) Rev. 6 (40217701-3/9) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS R26, R28, R63, R64, RD16U/VTJ1Kohm 3213420J0102 RES-Carbon flm RD16UJ1.8Kohm 3213420J0182 RES-Carbon flm R124, R125 RD16UJ1.5Kohm 3213420J0152 RES-Carbon flm R61, R62 SN15K2CU 33KohmF 3233020F0333 RES-MET RN SN15K2CU 30KohmF 3233020F0303 RES-MET RN...
  • Page 310 OL1-PCB Assy. (Power Supply Board) Rev. 6 (40217701-4/9) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS RD1/4Y16KohmJ 321A1421J0163 RES-Carbon flm R51, R102, R108, RD1/4Y1MohmJ 321A1421J0105 R120~R122 RES-Carbon flm R116, R119 RD1/4Y330ohmJ 321A1421J0331 RES-Carbon flm R32, R67, R68, R115, RD1/4Y5.1KohmJ 321A1421J0512 R118 RES-Carbon flm R101 RD1/4Y51KohmJ...
  • Page 311 OL1-PCB Assy. (Power Supply Board) Rev. 6 (40217701-5/9) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS RNL1/4C3F1.0Kohm 323A1222F0102 RES-MET RN R85~R87 RNL1/4C3F47Kohm 323A1222F0473 RES-MET RN R112 RNF1/4W/RN26K2E360KF 3234003F0364 RES-MET RN RD1/2Y1MohmJ 321A1431J0105 RES-Carbon flm R2, R3 FMR1/2-100ohmJ 327A1001J0101 RES-Fuse R105, R123 HV-22-30MK 3263120K0306 RES-MET solid...
  • Page 312 OL1-PCB Assy. (Power Supply Board) Rev. 6 (40217701-6/9) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS C5, C12, C16, C21, C51, MLRD/FK16Y5V1H104Z 3034003Z3104 C52, C57, C58, C60, CAP-Ceramic C68~C70, C71, C109, C110, C118~C120 UMA/50MS5-1M 3041103H1109 CAP-Alum (CE) 1µF C13, C54, C55 HLY5P/DD05-500V-331K 3024003K6331 CAP-Ceramic...
  • Page 313 OL1-PCB Assy. (Power Supply Board) Rev. 6 (40217701-7/9) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS KME50VB-47 304A1115H1470 CAP-Alum (CE) 47µF 2SB1351 601A1226M0002 TR-PNP/L-FREQ 2SD1590 603A1223M0022 TR-NPN/L-FREQ Q3, Q109, Q111 2SC1740S 602A1035M0002 TR-NPN/H-FREQ Q2, Q6, Q7, Q58~Q62, DTD114ESTP 6021035M0001 Q110 TR-NPN/H-FREQ 2SA608SP/2SA933S 600A1003M0001 TR-PNP/H FREQ...
  • Page 314 OL1-PCB Assy. (Power Supply Board) Rev. 6 (40217701-8/9) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS 324P 720A0000M0002 Analog-BIPLIN 358P 720A0000M0033 Analog-BIPLIN SI-3033C (LF1101) 720A1029M8002 Analog-BIPLIN PST592D-2 720A4037M0015 Analog-BIPLIN OSC1 CST10.0MTW 381A1045B0014 OSC-Ceramic SU10V07040/FUS325020 350A0223P0402 Coil-Choke SN8S-300/SF-T8-30S 350A0221P1001 Coil-Choke SK-24BS075-350 350A2512P0351 Coil-Choke L101 SU16VD-40020...
  • Page 315 OL1-PCB Assy. (Power Supply Board) Rev. 6 (40217701-9/9) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS 51MS063L 540A2076N0632 FUSE- 51MS016L 540A2076N0162 FUSE- GGS3.15 540A2036M1322 FUSE- F220 2423000P0001 Holder-Fuse OSH-1025-MP 161A1233P0001 Heat sink- SJ-W2P4A-03BB2 2003200P2000 Switch-Toggle SM-05S-04A-9 207A2020P0001 Switch-Micro INLET SPECIAL CORD YS4011-2894P001 Screw PSWW3-8C...
  • Page 316 REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS OL2-PCB Assy. (Power Supply Board) Rev. 6 (40217702-1/10) 119 / 40990901TH Rev.1...
  • Page 317 OL2-PCB Assy. (Power Supply Board) Rev. 6 (40217702-2/10) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS TF341M 620A0026M0002 THY-Gate RBV-402/D3SBA20 610A1003M0001 D-Rectifying D7~D10 OR-D-Rectifying-Q 40401401 D101~D104, EUO2A/RL105F-F 6100003M0001 D106~D109, D112, D-Rectifying D113, D119, D126 FML-12S 610A2226M0016 D-Rectifying D51, D114, D122, D123 1S953/1S2075K/1S2473 611A0003L0001 D-Signal...
  • Page 318 OL2-PCB Assy. (Power Supply Board) Rev. 6 (40217702-3/10) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS R26, R28, R63,R64, R66 RD16U/VTJ1kohm 3213420J0102 RES-Carbon flm RD16UJ1.8Korm 3213420J0182 RES-Carbon flm R124, R125 RD16UJ1.5Kohm 3213420J0152 RES-Carbon flm R61, R62 SN15K2CU 33KohmF 3233020F0333 RES-MET RN SN15K2CU 30KohmF 3233020F0303 RES-MET RN...
  • Page 319 OL2-PCB Assy. (Power Supply Board) Rev. 6 (40217702-4/10) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS RD1/4Y16KohmJ 321A1421J0163 RES-Carbon flm R51, R102, R108, RD1/4Y1MohmJ 321A1421J0105 R120~122 RES-Carbon flm R116, R119 RD1/4Y330ohmJ 321A1421J0331 RES-Carbon flm R32,R67, R68, R115, RD1/4Y5.1KohmJ 321A1421J0512 R118 RES-Carbon flm R101 RD1/4Y51KohmJ 321A1421J0513...
  • Page 320 OL2-PCB Assy. (Power Supply Board) Rev. 6 (40217702-5/10) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS RNL1/4C3F1.0Kohm 323A1222F0102 RES-MET RN R85~R87 RNL1/4C3F47Kohm 323A1222F0473 RES-MET RN R112 RNF1/4W/RN26K2E360KF 3234003F0364 RES-MET RN RD1/2Y1MohmJ 321A1431J0105 RES-Carbon f1mn R2, R3 FMR1/2-100ohmJ 327A1001J0101 RES-Fuse R105, R123 HV-22-30MK 3263120K0306 RES-MET solid...
  • Page 321 OL2-PCB Assy. (Power Supply Board) Rev. 6 (40217702-6/10) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS C5, C12, C16,C21, C51, MLRD/FK16Y5V1H104Z 3034003Z3104 C52, C57,C58, C60, CAP-Ceramic C68~C71, C109, C110, C118~C120 UMA/5OMS5-1M 3041103H1109 CAP-Alum (CE) 1µF C1, C2 DE1007E222M-KH 250V 3024000M5222 CAP-Ceramic C13, C54, C55 HLY5P/DD05-500V-331K 3024003K6331...
  • Page 322 OL2-PCB Assy. (Power Supply Board) Rev. 6 (40217702-7/10) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS RD16XR/CK92C1H681 3034003M3681 CAP-Ceramic KME50VB-47 304A1115H1470 CAP-Alum (CE) 47µF 2SB1351 601A1226M0002 TR-PNP/L-FREQ 2SD1590 603A1223M0022 TR-NPN/L-FREQ Q3, Q109, Q111 2SC1740S 602A1035M0002 TR-NPN/H-FREQ Q2, Q6, Q7, Q58~Q62, DTD114ESTP 6021035M0001 Q110 TR-NPN/H-FREQ...
  • Page 323 OL2-PCB Assy. (Power Supply Board) Rev. 6 (40217702-8/10) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS LC26023A-NA5 7024633M2003 Digital IC-MOS- 324P 720A0000M0002 Analog-BIPLIN 358P 720A0000M0033 Analog-BIPLIN SI-3033C (LF1101) 720A1029M8002 Analog-BIPLIN PST592D-2 720A4037M0015 Analog-BIPLIN OSC1 CST10.0MTW 381A1045B0014 OSC-Ceramic SN8S-300/SF-T8-30S 350A0221P1001 Coil-Choke SK-24BS075-350 350A2512P0351 Coil-Choke L101...
  • Page 324 OL2-PCB Assy. (Power Supply Board) Rev. 6 (40217702-9/10) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS 215005 540A2077T0155 FUSE 21702.5 540A2221S0252 FUSE F220 2423000P0001 Holder-Fuse OSH-1025-MP 161A1233P0001 Heat Sink SJ-W2P4A-03BB2 2003200P2000 Switch-Toggle SM-05S-04A-9 207A2020P0001 Switch-Micro INLET SPECIAL CORD YS4011-2894P002 Screw PSWW3-8C 201840-23 121A1037P0001 Sleeve-...
  • Page 325 OL2-PCB Assy. (Power Supply Board) Rev. 6 (40217702-10/10) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS S80~S85, S87~S90 SHORT WIRE TA-0.6 S86, S93, S94 SHORT WIRE TA-0.6 S74, S92, S95~S97 SHORT WIRE TA-0.6 128 / 40990901TH Rev.1...
  • Page 326 REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS SEN1 C506 BF502 BF501 OSC1 R503 TQSB-2-Printed Circuit Board (High Capacity Second Paper Feeder Board) Rev. 1 (4YA4046-1651G002-1/4) 129 / 40990901TH Rev.1...
  • Page 327 TQSB-2-Printed Circuit Board (High Capacity Second Paper Feeder Board) Rev. 1 (4YA4046-1651G002-2/4) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS D1~D3 EM01Z/SM1XN02/DSM1D2 610A0003M0001 Rectifier D1 RD3.9E-B 613A1231L0082 Zener-D1 1S953/1S2075K/1S2473 611A0003L0001 Signal D1 R513, R514 RM73B2A473J 323A5003J0473 RN Resistor (CP) R1, R2 MSF1/2B0.51ΩJ 324A1001J0518 RS Resistor...
  • Page 328 TQSB-2-Printed Circuit Board (High Capacity Second Paper Feeder Board) Rev. 1 (4YA4046-1651G002-3/4) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS MRM-4-512JA 334A3266J0512 Block Resistor SXE50VB-10-4D-FC 304A1008H1100 CE Capacitor 10µF 10MS5-33M 304A1046A1330 CE Capacitor 33µF RPE122-127E334M50 303A4116M3334 CK Capacitor 0.33µF C503, C504, C507, CK2012B1H102K 303A6008K3102 C508...
  • Page 329 TQSB-2-Printed Circuit Board (High Capacity Second Paper Feeder Board) Rev. 1 (4YA4046-1651G002-4/4) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS TR1, TR2 DTA114S 600A1035M0005 PNP-HF-TR OSC1 CST4.00MGW 381A1025B0002 Ceramic Oscillator 251-001 540A2208S1102 Fuse MOTOR 00-8263-0412-00-000 224A3357P0040 PC Connector IL-S-8P-S2T2-EF 224A3052P0080 PC Connector Short Wire (U type) 0.65 5KH-31036-25 P=2.5...
  • Page 330 REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS OSC1 OLEV-Printed Circuit Board (Multi Purpose Feeder Board) Rev. 4 (4YA4121-1014G011-1/4) 133 / 40990901TH Rev.1...
  • Page 331 OLEV-Printed Circuit Board (Multi Purpose Feeder Board) Rev. 4 (4YA4121-1014G011-2/4) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS D1, D2, D5 EM01Z/SM1XN02/DSM1D2 610A0003M0001 Rectifier Diode RD3.9E-B 613A1231L0082 Zener Diode 1S953/1S2075K/1S2473 611A0003L0001 Signal Diode R15, R16 RM73B2A473J 323A5003J0473 RN Resistor (CP) R18, R19 MSF1/2B0.51ΩJ 324A1001J0518 RS Resistor...
  • Page 332 OLEV-Printed Circuit Board (Multi Purpose Feeder Board) Rev. 4 (4YA4121-1014G011-3/4) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS 10MS5-33M 304A1046A1330 CE Capacitor 33µF RPE122-127E334M50 303A4116M3334 CK Capacitor 0.33µF CC2012SL1H471J 303A3007K0471 CC Capacitor (CP) C3~C6 CK2012B1H102K 303A6008K3102 CK Capacitor (CP) C7~C9 CK2012F1E104Z 303A6008Z2104 CK Capacitor (CP) M54646AP...
  • Page 333 OLEV-Printed Circuit Board (Multi Purpose Feeder Board) Rev. 4 (4YA4121-1014G011-4/4) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS 00-8263-0412-00-000 224A3357P0040 PC Connector 136 / 40990901TH Rev.1...
  • Page 334 REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS SIMM2 SIMM1 MM6-PCB Assy. (Memory Expansion Board) Rev. 4 (40369105-1/3) 137 / 40990901TH Rev.1...
  • Page 335 MM6-PCB Assy. (Memory Expansion Board) Rev. 4 (40369105-2/3) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS R8~R11 RM73B2A220J 323A5003J0220 RES-MET RN R18~R28 RM73B2A470J 323A5003J0470 RES-MET RN R1, R2, R5, R6, R7 RM73B2A472J 323A5003J0472 RES-MET RN 2125JPW 323A5003P0001 RES-MET RN RM1~RM7 MNR14ABJ680 334A5012J0680 RES-Block C20, C21...
  • Page 336 MM6-PCB Assy. (Memory Expansion Board) Rev. 4 (40369105-3/3) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS D1, D2 514260JP-70 8020003N2601 Memory-MOSDRAM-S PQ100A2MA 224A3515P1000 Connector-PCB ZBF253D-01 377A1115P1309 Filter-PW line SIMM1, SIMM2 2-176438-7 245A1372P0720 Socket-SEMICON 11088-1 2451002P0720 Socket-SEMICON 139 / 40990901TH Rev.1...
  • Page 337 REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS SMIF-Serial Memory Interface PCB (RS232C Interface Board) Rev. 4 (0025304-1/4) 140 / 40990901TH Rev.1...
  • Page 338 SMIF-Serial Memory Interface PCB (RS232C Interface Board) Rev. 4 (0025304-2/4) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS R1, R2, R5, R6 RM73B2A472J 323A5003J0472 RN RESISTOR (CP) R8~R31 RM73B2A680J 323A5003J0680 RN RESISTOR (CP) R32~R35, R37, R38 RM73B2A220J 323A5003J0220 RN RESISTOR (CP) RM73B2A332J 323A5003J0332 RN RESISTOR (CP)
  • Page 339 SMIF-Serial Memory Interface PCB (RS232C Interface Board) Rev. 4 (0025304-3/4) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS CK2012B1H561K 303A6008K3561 CK CAPACITOR (CP) CK2012B1H102K 303A6008K3102 CK CAPACITOR (CP) C23~C29 CC2012PHIH120J 303A3007P0120 CC CAPACITOR (CP) Q4~Q8 74ACT244FP 702A2503N3244 MOS DIGITAO IC (SO) 75188NS 710A0050N0188 BIP DIGITAL IC (SO)
  • Page 340 SMIF-Serial Memory Interface PCB (RS232C Interface Board) Rev. 4 (0025304-4/4) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS ZBF253D-01 377A1115P1309 BEAD FILTER DSS306-OAFZ103N 342A1009P3103 EMI FILTER ADHESIVE BARCODE LABEL 4YC4100-1062P001 143 / 143 40990901TH Rev.1...

Table of Contents
