SER-7000 Series Quick Start Guide
Contents

About the SER-7000 Series

Congratulations! You have selected a very flexible point of
sale terminal designed to provide years of reliable service.
Your SAM4s/Samsung dealer will help you configure the SER-
7000 to your specific needs.
The SER-7000 Series is offered in two different versions:
SER-7000 series manuals include instructions for both models. The keyboard is the only
significant difference between the two models. All other features are the same, unless
otherwise noted.
The SER-7000 features a flat 160-position keyboard
with 107 NLU keys. (NLUs are used to
merchandise categories/departments or for individual
menu items in a restaurant environment.) Because it offers protection from spills,
this keyboard works best in restaurants, food service shops, or convenience stores
where food is served.
The SER-7040 features a 90-position keyboard with traditional raised keys. In the
standard configuration, the keyboard provides 15 NLU keys - it can be expanded
to 40 NLU keys. The SER-7040 works best in retail stores, or shops where it is
not necessary to place a large number of preset item keys on the keyboard.
1
3
4
6
6
13
14
