Chapter 2: Setting Up an Origin200 System
46
2. Remove the module system controller (MSC) access plate, as shown in Figure 2-17
Remove the single screw that attaches the plate to the chassis.
Swing the plate out and away.
Figure 2-17 Removing the Module System Controller (MSC) Access Plate
1
2 3
4
5
6
7 8
OP
EN
