Chapter 7: Installing and Configuring Peripherals
160
2. Locate an available slot for the peripheral.
Figure 7-15 shows how the drives are numbered.
Figure 7-15 How the 3.5-inch Drives are Numbered in Origin200
3. Install the peripheral.
If there is a plastic blanking plate covering the slot, remove it as shown in
Figure 7-16.
Slide the drive forward until it is almost flush with the edge of the drive bay.
Fold the locking lever up to latch the drive in place, as shown in Figure 7-16.
Slot 6 (SCSI ID 6)
Slot 1 (SCSI ID 1)
