Origin200 to O2, Onyx2, and IBM-Compatible (DB-9 to DB-9)

This connects an Origin200 to Silicon Graphics O2 and Onyx2 workstations, and
IBM-compatibles with a DB-9 serial port.
Table B-4 shows the cable connector pin assignments.
Table B-4 Cable Connector Pin Assignments for an Origin200 To O2, Onyx2, and
IBM-Compatible Serial Cable
Pin Number Signal
(DB-9 Female)
1 Data Carrier Detect (DCD)
2 Receive Data (RXD)
3 Transmit Data (TXD)
4 Data Terminal Ready (DTR)
5 Ground (GND)
6 Data Set Ready (DSR)
7 Request To Send (RTS)
8 Clear To Send (CTS)
9 (Not Connected)
Pin Number Signal
(DB-9 Female)
4 DTR
3 TXD
2 RXD
1 DCD
5 GND
N/C
8 CTS
7 RTS
Serial Cables
213
