Summary of Contents for Rosewill RNX-AC750RT
- Page 1 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual...
-
Page 2: Fcc Statement
FCC STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. -
Page 3: Ce Mark Warning
CE Mark Warning This is a class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. National Restrictions This device is intended for home and office use in all EU countries (and other countries following the EU directive 1999/5/EC) without any limitation except for the countries mentioned below: Country Restriction... -
Page 4: Table Of Contents
CONTENTS Package Contents ..................... 1 Chapter 1. Introduction ..................2 1.1 Overview of the Router ....................2 1.2 Conventions ........................3 1.3 Main Features ....................... 3 1.4 Panel Layout ......................... 4 1.4.1 The Front Panel ....................4 1.4.2 The Rear Panel ....................5 Chapter 2. - Page 5 4.7.1 Basic Settings ....................50 4.7.2 WPS ........................ 53 4.7.3 Wireless Security .................... 55 4.7.4 Wireless MAC Filtering ................... 59 4.7.5 Wireless Advanced ..................61 4.7.6 Wireless Statistics ................... 62 4.8 Guest Network ......................63 4.9 DHCP .......................... 65 4.9.1 DHCP Settings ....................65 4.9.2 DHCP Clients List ...................
- Page 6 4.16.2 System Routing Table ................... 102 4.17 Bandwidth Control ....................103 4.18 IP & MAC Binding ..................... 104 4.18.1 Binding Settings .................... 104 4.18.2 ARP List ......................106 4.19 Dynamic DNS ......................106 4.19.1 No-ip.com DDNS ..................107 4.19.2 Comexe.cn DDNS..................107 4.19.3 Dyndns.com DDNS ..................
-
Page 7: Package Contents
The following items should be found in your package: RNX-AC750RT AC750 Wireless Dual Band Gigabit Router DC Power Adapter for RNX-AC750RT AC750 Wireless Dual Band Gigabit Router Quick Installation Guide Resource CD for RNX-AC750RT AC750 Wireless Dual Band Gigabit Router, including: ... -
Page 8: Chapter 1. Introduction
Incredible Speed AccessontroInstallation The RNX-AC750RT AC750 Wireless Dual Band Gigabit Router provides up to 750Mbps wireless connection with other wireless clients. The incredible speed makes it ideal for handling multiple data streams at the same time, which ensures your network stable and smooth. The performance of this 802.11ac wireless router will give you the unexpected networking experience at speed much faster... -
Page 9: Conventions
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Conventions The router or RNX-AC750RT mentioned in this guide stands for RNX-AC750RT AC750 Wireless Dual Band Gigabit Router without any explanation. Main Features Complies with IEEE 802.11ac. One 10/100/1000M Auto-Negotiation RJ45 WAN port, four 10/100/1000M Auto-Negotiation RJ45 LAN ports, supporting Auto MDI/MDIX. -
Page 10: Panel Layout
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Panel Layout 1.4.1 The Front Panel Figure 1-1 LEDs on the front panel The router’s LEDs are located on the front panel (View from left to right). Name Status Indication Power is off. -
Page 11: The Rear Panel
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual 1.4.2 The Rear Panel Figure 1-2 Rear Panel sketch The following parts are located on the rear panel (View from left to right). WPS/Reset: Pressing this button for less than 5 seconds enables the WPS function. If your client devices,... - Page 12 ON/OFF: The switch for the power. POWER: The Power socket is where you will connect the power adapter. Please use the power adapter provided with this RNX-AC750RT AC750 Wireless Dual Band Gigabit Router. Wireless antenna: To receive and transmit the wireless data.
-
Page 13: Chapter 2. Connecting The Router
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Chapter 2. Connecting the router System Requirements Broadband Internet Access Service (DSL/Cable/Ethernet) One DSL/Cable Modem that has an RJ45 connector (which is not necessary if the router is connected directly to the Ethernet) PCs with a working Ethernet Adapter and an Ethernet cable with RJ45 connectors ... - Page 14 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual the router, please make sure your computer is NOT connected to any other wireless network.) Figure 2-1 Hardware Installation Figure 2-2 USB Installation Note: If you want to use the router to share files, plug the USB storage device to the USB port.
-
Page 15: Chapter 3. Quick Installation Guide
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Chapter 3. Quick Installation Guide This chapter will show you how to configure the basic functions of your AC750 Wireless Dual Band Gigabit Router using Quick Setup Wizard within minutes. TCP/IP Configuration The default IP address of the router is 192.168.1.1 and the default Subnet Mask is 255.255.255.0. -
Page 16: Quick Installation Guide
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Figure 3-2 Failure result of Ping command Please check the connection following these steps: Is the connection between your PC and the router correct? Note: The Ethernet LED on the router and LEDs on your PC's adapter should be lit. - Page 17 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Figure 3-4 Login Windows Note: If the above screen does not pop up, it means that your Web-browser has been set to a proxy. Go to Tools menu>Internet Options>Connections>LAN Settings, in the screen that appears, cancel the Using Proxy checkbox, and click OK to finish it.
- Page 18 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Figure 3-6 WAN Connection Type The router provides Auto-Detect function and supports five types of WAN connection: Dynamic IP, Static IP, PPPoE, L2TP, and PPTP. It’s recommended that you make use of the Auto-Detect function.
- Page 19 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Figure 3-7 Quick Setup – MAC Clone 2) If the connection type detected is Static IP, the next screen will appear as shown in Figure 3-8. Configure the following parameters and then click Next to continue.
- Page 20 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Secondary DNS Server-（Optional） If your ISP provides another DNS server, enter it into this field. 3) If the connection type detected is PPPoE, the next screen will appear as shown in Figure 3-9.
- Page 21 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Username/Password - Enter the Username and Password provided by your ISP. These fields are case-sensitive. If you have difficulty with this process, please contact your ISP. Select Static IP if the IP Address/ Subnet Mask/ Gateway and DNS server address have been provided by your ISP.
- Page 22 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Username/Password - Enter the Username and Password provided by your ISP. These fields are case-sensitive. If you have difficulty with this process, please contact your ISP. Select Static IP if the IP Address/ Subnet Mask/ Gateway and DNS server address have been provided by your ISP.
- Page 23 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual 5GHz - This band is less crowded and is used for time-sensitive music, video streaming or gaming. Using this band can avoid interference with 2.4GHz networks or noisy devices like cordless phones and microwave ovens.
- Page 24 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Disable Wireless Security - The wireless security function can be enabled or disabled. If disabled, the wireless stations will be able to connect the router without encryption. The above settings are only for basic wireless parameters. For advanced settings, please check “More Advanced Wireless Settings”, and then you can set the following parameters.
- Page 25 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Figure 3-14 Quick Setup – Wireless 5GHz Wireless Network Name - Also called the SSID (Service Set Identification). Enter a value of up to 32 characters. The same name must be assigned to all wireless devices in your network.
- Page 26 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Band - This field displayed the operating frequency being configured. Mode - This field determines the wireless mode which the router works on. 11an mixed - Select if you are using both 802.11a and 802.11n wireless clients.
- Page 27 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Figure 3-15 Quick Setup - Confirm Click the Finish button to complete the Quick Setup. Figure 3-16 Quick Setup - Finish - 21 -...
-
Page 28: Chapter 4. Configuring The Router
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Chapter 4. Configuring the router This chapter will show each key function of the Web page and its configuration method. Login After your successful login, you will see the main menus on the left of the Web-based utility. On the right, there are the corresponding explanations and instructions. - Page 29 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Figure 4-1 Status - 23 -...
-
Page 30: Quick Setup
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Quick Setup Please refer to 3.2 Quick Installation Guide. Network Figure 4-2 the Network menu There are three submenus under the Network menu (shown in Figure 4-2): WAN, LAN and MAC Clone. - Page 31 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual This page displays the WAN IP parameters assigned dynamically by your ISP, including IP address, Subnet Mask, Default Gateway, etc. Click the Renew button to renew the IP parameters from your ISP. Click the Release button to release the IP parameters.
- Page 32 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Figure 4-4 WAN - Static IP IP Address - Enter the IP address in dotted-decimal notation provided by your ISP. Subnet Mask - Enter the subnet Mask in dotted-decimal notation provided by your ISP, ...
- Page 33 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Figure 4-5 WAN - PPPoE PPP Username/PPP Password - Enter the User Name and Password provided by your ISP. These fields are case-sensitive. Secondary Connection - It’s available only for PPPoE Connection. If your ISP provides an ...
- Page 34 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Dynamic IP - You can check this radio button to use Dynamic IP as the secondary connection to connect to the local area network provided by ISP. Static IP - You can check this radio button to use Static IP as the secondary connection ...
- Page 35 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual DNS/Secondary DNS - If your ISP does not automatically assign DNS addresses to the router during login, please click “Set DNS server manually” check box and enter the IP address of your ISP’s primary DNS server. If a secondary DNS server address is available, enter it as well.
- Page 36 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual MTU(Bytes)- The normal MTU (Maximum Transmission Unit) value for most Ethernet networks is 1500 Bytes. It is not recommended that you change the default MTU value unless required by your ISP.
- Page 37 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Figure 4-7 WAN - L2TP Username/Password - Enter the User Name and Password provided by your ISP. These fields are case-sensitive. Addressing Type - Choose the addressing type given by your ISP, either Dynamic IP or Static IP.
- Page 38 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Always on - In this mode, the Internet connection will be active all the time. Connect on Demand - You can configure the router to disconnect from your Internet connection after a specified period of inactivity (Max Idle Time).
- Page 39 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Figure 4-8 PPTP Settings Username/Password - Enter the User Name and Password provided by your ISP. These fields are case-sensitive. Dynamic IP/ Static IP - Choose the addressing type given by your ISP, either Dynamic IP or Static IP, and enter the ISP’s IP address or the domain name.
- Page 40 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Enable IGMP Proxy - IGMP (Internet Group Management Protocol) is used to manage multicasting on TCP/IP networks. Some ISPs use IGMP to perform remote configuration for client devices, such as the modem router. The default value is enabled, and if you are not sure, please contact your ISP or just leave it.
-
Page 41: Lan
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual The router cannot detect PPTP/L2TP/Big Pond connections with your ISP. If your ISP uses one of these protocols, then you must configure your connection manually. 4.4.2 Choose menu “Network → LAN”, you can configure the IP parameters of the LAN on the screen as below. -
Page 42: Dual Band Selection
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Figure 4-10 MAC Clone Some ISPs require that you register the MAC Address of your adapter. Changes are rarely needed here. WAN MAC Address - This field displays the current MAC address of the port. -
Page 43: Wireless 2.4Ghz
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Figure 4-11 Dual Band Selection 2.4GHz (802.11b/g/n) - Click the box, and then the router will only work in 2.4GHz frequency. You can use the 2.4GHz band to connect to many classic wireless devices like gaming consoles, laptops, DVRs, etc. - Page 44 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Figure 4-13 Wireless Settings – 2.4GHz Wireless Network Name - Also called the SSID (Service Set Identification). Enter a value of up to 32 characters. The same name must be assigned to all wireless devices in your network.
- Page 45 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Note: Limited by local law regulations, version for North America does not have region selection option. Mode - Select the desired mode. 11bg mixed - Select if you are using both 802.11b and 802.11g wireless clients.
-
Page 46: Wps
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual SSID (to be bridged) - The SSID of the AP your router is going to connect to as a client. You can also use the search function to select the SSID to join. - Page 47 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Generate New PIN - Click this button, and then you can get a new random value for the router's PIN. You can ensure the network security by generating a new PIN.
-
Page 48: Wireless Security
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Step 3: The Wi-Fi Protected Setup LED flashes for two minutes during the Wi-Fi Protected Setup process. Step 4: When the WPS LED is on, the client device has successfully connected to the router. - Page 49 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Figure 4-19 Wireless Security Disable Wireless Security - If you do not want to use wireless security, check this radio button. But it’s strongly recommended to choose one of the following modes to enable security.
- Page 50 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Encryption - When WPA-PSK or WPA is set as the Authentication Type, you can select either Automatic, or TKIP or AES as Encryption. Note: If you check the WPA/WPA2-Personal...
- Page 51 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Radius Server Password - Enter the password for the Radius server. Group Key Update Period - Specify the group key update interval in seconds. The value should be 30 or above. Enter 0 to disable the update.
-
Page 52: Wireless Mac Filtering
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual 4.6.4 Wireless MAC Filtering Choose menu “Wireless 2.4GHz → Wireless MAC Filtering”, you can control the wireless access by configuring the Wireless MAC Filtering function, shown in Figure 4-23. Figure 4-23 Wireless MAC Filtering To filter wireless users by MAC Address, click Enable. - Page 53 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Enter the appropriate MAC Address into the MAC Address field. The format of the MAC Address XX:XX:XX:XX:XX:XX hexadecimal digit). example: 00:0A:EB:B0:00:0B. Give a simple description for the wireless station in the Description field. For example: Wireless station A.
-
Page 54: Wireless Advanced
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual 4.6.5 Wireless Advanced Choose menu “Wireless 2.4GHz → Wireless Advanced”, you can configure the advanced settings of your wireless network. Figure 4-25 Wireless Advanced Transmit Power - Here you can specify the transmit power of router. You can select High, Middle or Low which you would like. -
Page 55: Wireless Statistics
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Fragmentation Threshold - This value is the maximum size determining whether packets will be fragmented. Setting the Fragmentation Threshold too low may result in poor network performance because of excessive packets. 2346 is the default setting and is recommended. -
Page 56: Wireless 5Ghz
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Sent Packets - Packets sent by the station You cannot change any of the values on this page. To update this page and to show the current connected wireless stations, click on the Refresh button. - Page 57 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Figure 4-28 Wireless Settings – 5GHz Wireless Network Name - Also called the SSID (Service Set Identification). Enter a value of up to 32 characters. The same name must be assigned to all wireless devices in your network.
- Page 58 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Note: Limited by local law regulations, version for North America does not have region selection option. Mode - Select the desired mode. 11an mixed - Select if you are using both 802.11a and 802.11n wireless clients. If you set the Mode 11an mixed, all of 802.11a and 802.11n wireless stations can connect to...
-
Page 59: Wps
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual MAC Address (to be bridged) - The BSSID of the AP your router is going to connect to as a client. You can also use the search function to select the BSSID to join. - Page 60 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Add device - You can add a new device to the existing network manually by clicking this button. If the wireless adapter supports Wi-Fi Protected Setup (WPS), you can establish a wireless connection between wireless adapter and router using either Push Button Configuration (PBC) method or PIN method.
-
Page 61: Wireless Security
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Use this method if your client device does not have the WPS button, but has a Wi-Fi Protected Setup PIN number. Step 1: Keep the default WPS status as Enabled and click the Add device button in Figure 4-30, then Figure 4-33 will appear. - Page 62 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual There are five wireless security modes supported by the router: WPA-Personal, WPA2-Personal, WPA-Enterprise, WPA2-Enterprise, and WEP. Figure 4-34 Wireless Security Disable Security - If you do not want to use wireless security, check this radio button. But it’s ...
- Page 63 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual (Pre-shared key of WPA) or WPA2-PSK (Pre-shared key of WPA) automatically based on the wireless station's capability and request. Encryption - When WPA-PSK or WPA is set as the Authentication Type, you can select either Automatic, or TKIP or AES as Encryption.
- Page 64 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Radius Server IP - Enter the IP address of the Radius server. Radius Server Port - Enter the port number of the Radius server. Radius Server Password - Enter the password for the Radius server.
-
Page 65: Wireless Mac Filtering
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual If you do not set the key, the wireless security function is still disabled even if you have selected Shared Key as Authentication Type. Be sure to click the Save button to save your settings on this page. - Page 66 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Figure 4-39 Add or Modify Wireless MAC Address Filtering entry To add or modify a MAC Address Filtering entry, follow these instructions: Enter the appropriate MAC Address into the MAC Address field. The format of the MAC...
- Page 67 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual 2. Select the radio button “Allow the entries specified by any enabled entries in the list to access” for Filtering Rules. 3. Delete all or disable all entries if there are any entries already.
-
Page 68: Wireless Advanced
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual 4.7.5 Wireless Advanced Choose menu “Wireless → Wireless Advanced”, you can configure the advanced settings of your wireless network. Figure 4-40 Wireless Advanced Transmit Power - Here you can specify the transmit power of router. You can select High, Middle or Low which you would like. -
Page 69: Wireless Statistics
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Enable WMM - WMM function can guarantee the packets with high-priority messages being transmitted preferentially. It is strongly recommended. Enable Short GI - This function is recommended for it will increase the data capacity by reducing the guard interval time ... - Page 70 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Figure 4-42 Guest Network Wireless Settings Allow Guest To Access My Local Network - If enabled, guests can communicate with hosts. Allow Guest To Access My USB Storage Sharing - If enabled, guests can access to USB...
-
Page 71: Dhcp
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual storage sharing servers. Guest Network Isolation -. If enabled, guests are isolated from each other. Guest Network Bandwidth Control - If enabled, the Guest Network Bandwidth Control rules will take effect. - Page 72 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Figure 4-44 DHCP Settings DHCP Server - Enable or Disable the DHCP server. If you disable the Server, you must have another DHCP server within your network, otherwise you must configure the computer manually.
-
Page 73: Dhcp Clients List
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual 4.9.2 DHCP Clients List Choose menu “DHCP → DHCP Clients List”, you can view the information about the clients attached to the router in the screen as shown in Figure 4-45. -
Page 74: Usb Settings
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual MAC Address - The MAC address of the PC for which you want to reserve an IP address. IP Address - The IP address reserved for the PC by the router. -
Page 75: Usb Mass Storage
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual There are six submenus under the USB Settings menu (shown in Figure 4-48): USB Mass Storage, User Accounts, Storage Sharing, FTP Server and Media Server. Click any of them, and you will be able to configure the corresponding functions. - Page 76 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Figure 4-50 User Account Management Only Administrator can use a Web browser to transfer the files from a PC to the Writable shared volume on the USB drive. To add a new user account, please follow the steps below: Choose the Index from the drop-down list.
-
Page 77: Storage Sharing
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Note: Please restart the service for the new settings to take effect. If you cannot use the new user name and password to access the shares, press Windows logo + R to open the Run dialog box and type net use \\192.168.1.1 /delete /yes and press Enter. - Page 78 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual User Access – Indicates user access of the shared folder. F stands for fully access, R stands for read-only and N stands for no-access. Status - Indicates the shared or non-shared status of the volume.
-
Page 79: Ftp Server
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Click the Apply button to make the settings take effect. 4.10.4 FTP Server Choose menu “USB Settings→FTP Server”, you can create an FTP server that can be accessed from the Internet or your local network. -
Page 80: Media Server
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual If WAN type is PPPoE/PPTP/L2TP, two connections will be available. Therefore, users can access FTP server via two connections. Users in a private LAN can access ftp server via Public Address while Internet users can access ftp server via Internet Address. - Page 81 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Figure 4-55 Media Server Setting Server Enable - Indicates the Media Server’s current status, started or stopped. You can click the Enable button to enable the Media Server and click the Disable button to disable it.
-
Page 82: Nat
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Figure 4-57 Add New Folder Share Name - You can enter a display name for the share folder. Directory - Displays the location of this folder. Browse – Click the button to select the folder to share. -
Page 83: Forwarding
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Figure 4-58 The Forwarding menu Enable NAT Control - If enabled, the NAT function and the Forwarding configuration will take effect. Disable NAT Control - If disabled, neither NAT function nor Forwarding configuration will ... - Page 84 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual when using the DHCP function. If you want the Virtual Servers configuration take effect, please make sure the NAT is enabled. Figure 4-60 Virtual Servers Service Port - The numbers of External Service Ports. You can enter a service port or a range of service ports (the format is XXX –...
-
Page 85: Port Triggering
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Figure 4-61 Add or Modify a Virtual Server Entry Note: It is possible that you have a computer or server that has more than one type of available service. If so, select another service, and type the same IP address for that computer or server. - Page 86 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Figure 4-62 Port Triggering Trigger Port - The port for outgoing traffic. An outgoing connection using this port will trigger this rule. Trigger Protocol - The protocol used for Trigger Ports, either TCP, UDP, or All (all protocols supported by the router).
-
Page 87: Dmz
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Click the Save button to save the new rule. Figure 4-63 Add or Modify a Triggering Entry To modify or delete an existing entry: Find the desired entry in the table. -
Page 88: Upnp
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual for a special-purpose service such as Internet gaming or videoconferencing. The router forwards packets of all services to the DMZ host. Any PC whose port is being forwarded must have its DHCP client function disabled and should have a new static IP Address assigned to it because its IP Address may be changed when using the DHCP function. -
Page 89: Security
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual App Description - The description about the application which initiates the UPnP request. External Port - The port which the router opened for the application. Protocol - The type of protocol which is opened. - Page 90 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Figure 4-67 Basic Security Firewall - A firewall protects your network from the outside world. Here you can enable or disable the router’s firewall. SPI Firewall - SPI (Stateful Packet Inspection, also known as dynamic packet filtering) helps to prevent cyber attacks by tracking more state per session.
-
Page 91: Advanced Security
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual L2TP Passthrough - Layer Two Tunneling Protocol (L2TP) is the method used to enable Point-to-Point sessions via the Internet on the Layer Two level. To allow L2TP tunnels to pass through the router, click Enable. - Page 92 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Figure 4-68 Advanced Security DoS Protection - Denial of Service protection. Check the Enable or Disable button to enable or disable the DoS protection function. Only when it is enabled, will the flood filters be enabled.
-
Page 93: Local Management
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual TCP-SYN-FLOOD Packets Threshold (5~3600) - The default value is 50. Enter a value between 5 ~ 3600. When the current TCP-SYN-FLOOD Packets numbers is beyond the set value, the router will startup the blocking function immediately. -
Page 94: Remote Management
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual If your PC is blocked but you want to access the router again, use a pin to press and hold the WPS/Reset button (hole) on the back panel for about 5 seconds to reset the router’s factory defaults on the router’s Web-Based Utility. - Page 95 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Figure 4-71 Parent Control Settings Parent Control - Check Enable if you want this function to take effect. - 89 -...
- Page 96 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual MAC Address of Parental PC - In this field, enter the MAC address of the controlling PC, or you can make use of the Copy to Above button below. ...
- Page 97 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual - 91 -...
-
Page 98: Access Control
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Figure 4-72 Parent Control Settings 4.15 Access Control Figure 4-73 Access Control There are four submenus under the Access Control menu: Rule, Host, Target and Schedule (as shown in Figure 4-73). Click any of them, and you will be able to configure the corresponding function. - Page 99 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Target - Here displays the target selected in the corresponding rule. Schedule - Here displays the schedule selected in the corresponding rule. Enable - Here displays the status of the rule, enabled or not. Check this option to enable a specific entry.
-
Page 100: Host
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual For example: If you desire to allow the host with MAC address 00 : 11 : 22 : 33 : 44 : AA to access www.google.com only from 18:00 to 20:00 on Saturday and Sunday, and forbid other hosts in the LAN to access the Internet, you should follow the settings below: Click the submenu Rule of Access Control in the left to return to the Rule List page. - Page 101 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Figure 4-76 Host Settings Description - Here displays the description of the host and this description is unique. Address Info - Here displays the information about the host. It can be IP or MAC.
-
Page 102: Target
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Figure 4-78 Add or Modify a Host Entry For example: If you desire to restrict the internet activities of host with MAC address 00:11:22:33:44:AA, you should first follow the settings below: Click Add New button in Figure 4-76 to enter the Add or Modify a Host Entry page. - Page 103 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Edit- To modify or delete an existing entry. To add a new entry, please follow the steps below. Click the Add New button. In Mode field, select IP Address, MAC Address or URL Address.
- Page 104 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Figure 4-82 Add or Modify an Access Target Entry In Description field, create a unique description for the target (e.g. Target_1). In Add URL Address field, enter the domain name, either the full name or the keywords (for example, google) in the blank.
-
Page 105: Schedule
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual 4.15.4 Schedule Choose menu “Access Control → Schedule”, and then you can view and set a Schedule list in the next screen as shown in Figure 4-83. The Schedule list is necessary for the Access Control Rule. -
Page 106: Advanced Routing
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Figure 4-84 Advanced Schedule Settings For example: If you desire to restrict the internet activities of host with MAC address 00:11:22:33:44:AA to access www.google.com only from 18:00 to 20:00 on Saturday and Sunday, you should first follow the settings below: Click Add New button shown in Figure 4-83 to enter the Advanced Schedule Settings page. -
Page 107: Static Route List
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual There are two submenus under the Advanced Routing menu as shown in Figure 4-85: Static Route List and System Routing Table. Click any of them, and you will be able to configure the corresponding function. -
Page 108: System Routing Table
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Select Enabled or Disabled for this entry on the Status drop-down list. Click the Save button to make the entry take effect. Other configurations for the entries: Click the Delete button to delete the entry. -
Page 109: Bandwidth Control
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual 4.17 Bandwidth Control Figure 4-89 Bandwidth Control Choose menu “Bandwidth Control”, and then you can configure the bandwidth control in the screen as shown in Figure 4-89 Bandwidth Control. You can configure the Egress Bandwidth and Ingress Bandwidth in this page. Their values you configure should be less than 100000Kbps. -
Page 110: Ip & Mac Binding
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Status - This displays the status of the rule. Edit - Click Edit to edit the rule. Click Delete to delete the rule. To add/modify a Bandwidth Control rule, follow the steps below. - Page 111 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Figure 4-92 Binding Setting MAC Address - The MAC address of the controlled computer in the LAN. IP Address - The assigned IP address of the controlled computer in the LAN.
-
Page 112: Arp List
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Click Edit or Delete as desired on the Edit column. 4.18.2 ARP List To manage the computer, you could observe the computers in the LAN by checking the relationship of MAC address and IP address on the ARP list, and you could also configure the items on the ARP list. -
Page 113: No-Ip.com Ddns
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual 4.19.1 No-ip.com DDNS If the dynamic DNS Service Provider you select is www.no-ip.com, the page will appear as shown in. Figure 4-95 Figure 4-95 No-ip.com DDNS Settings To set up for DDNS, follow these instructions: Enter the Domain Name you received from dynamic DNS service provider. -
Page 114: Dyndns.com Ddns
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Figure 4-96 Comexe.cn DDNS Settings To set up for DDNS, follow these instructions: Enter the Domain Name your dynamic DNS service provider gave. Enter the Username for your DDNS account. Enter the Password for your DDNS account. -
Page 115: Ipv6
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Figure 4-97 Dyndns.org DDNS Settings To set up for DDNS, follow these instructions: Enter the Domain Name you received from dynamic DNS service provider. Enter the Username for your DDNS account. -
Page 116: Ipv6 Status
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual There are three submenus under the IPv6 Support menu (shown in Figure 4-98): IPv6 Status, IPv6 WAN and IPv6 LAN. Click either of them, and you will be able to scan or configure the corresponding function. -
Page 117: Ipv6 Wan
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual 4.20.2 IPv6 WAN Figure 4-100 Enable/Disable IPv6 Connection Type - Choose the correct WAN connection type based on your ISP network topology. Dynamic IPv6 - Connections which use dynamic IPv6 address assignment. - Page 118 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Dynamic IPv6 Figure 4-101 Dynamic IPv6 IPv6 Address - The IPv6 address assigned by your ISP dynamically. Prefix Length - The length of IPv6 address prefix. IPv6 Gateway - Enter the default gateway provided by your ISP.
- Page 119 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Static IPv6 Figure 4-102 Static IPv6 IPv6 Address - Enter the IPv6 address provided by your ISP. Prefix Length - The length of IPv6 address prefix. IPv6 Gateway - Enter the default gateway provided by your ISP.
- Page 120 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Figure 4-103 PPPoEv6 PPP Username/Password - Enter the User Name and Password provided by your ISP. These fields are case-sensitive. Authentication Type – Choose one authentication type from AUTO-AUTH, PAP, CHAP and MS-CHAP.
-
Page 121: Ipv6 Lan
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Tunnel 6to4 Figure 4-104 Tunnel 6to4 This type is used in the situation that your WAN connection is IPv4 while LAN connection is IPv6. WAN Connection - Display the available wan connection. -
Page 122: System Tools
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual 4.21 System Tools Figure 4-106 The System Tools menu Choose menu “System Tools”, and you can see the submenus under the main menu: Time Settings, Diagnostic, Firmware Upgrade, Factory Defaults, Backup & Restore, Reboot, Password, System Log and Statistics. - Page 123 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Time Zone - Select your local time zone from this pull down list. Date - Enter your local date in MM/DD/YY into the right blanks. Time - Enter your local time in HH/MM/SS into the right blanks.
-
Page 124: Diagnostic
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Figure 4-108 Time settings Note: This setting will be used for some time-based functions such as firewall. You must specify your time zone once you login to the router successfully, otherwise, these functions will not take effect. - Page 125 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Diagnostic Tool - Check the radio button to select one diagnostic too. Ping - This diagnostic tool troubleshoots connectivity, reachability, and name resolution to a given host or gateway.
-
Page 126: Firmware Upgrade
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual 4.21.3 Firmware Upgrade Choose menu “System Tools → Firmware Upgrade”, and then you can update the latest version of firmware for the router on the following screen. Figure 4-111 Firmware Upgrade ... -
Page 127: Backup & Restore
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Figure 4-112 Restore Factory Default Click the Restore button to reset all configuration settings to their default values. The default User Name: admin The default Password: admin The default Subnet Mask: 255.255.255.0 ... -
Page 128: Reboot
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual The current configuration will be covered with the uploading configuration file. Wrong process will lead the device unmanaged. The restoring process lasts for 20 seconds and the router will restart automatically then. Keep the power of the router on during the process, in case of any damage. -
Page 129: System Log
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual It is strongly recommended that you should change the factory default user name and password of the router, because all users who try to access the router's Web-based utility or Quick Setup will be prompted for the router's default user name and password. - Page 130 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Figure 4-116 Statistics Statistics Status - Enable or Disable. The default value is disabled. To enable it, click the Enable button. If it is disabled, the function of DoS protection in Security settings will be disabled.
- Page 131 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Statistics Table: The IP and MAC address are displayed with related statistics. IP/MAC Address The total number of packets received and transmitted by the Packets router. Total The total number of bytes received and transmitted by the router.
-
Page 132: Logout
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual 4.22 Logout Choose ”Logout”, and you will be back to the login screen as shown in Figure 4-117. Figure 4-117 Logout - 126 -... -
Page 133: Appendix A: Faq
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Appendix A: FAQ How do I configure the router to access Internet by ADSL users? First, configure the ADSL Modem configured in RFC1483 bridge model. Connect the Ethernet cable from your ADSL Modem to the WAN port on the router. The telephone cord plugs into the Line port of the ADSL Modem. - Page 134 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual How do I configure the router to access Internet by Ethernet users? Login to the router, click the “Network” menu on the left of your browser, and click "WAN" submenu. On the WAN page, select “Dynamic IP” for "WAN Connection Type", finish by clicking “Save”.
- Page 135 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Figure A-4 Virtual Servers Figure A-5 Add or Modify a Virtual server Entry Note: Your opposite side should call your WAN IP, which is displayed on the “Status” page. How to enable DMZ Host: Log in to the router, click the “Forwarding” menu on the left of your browser, and click "DMZ"...
- Page 136 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual How to enable H323 ALG: Log in to the router, click the “Security” menu on the left of your browser, and click “Basic Security” submenu. On the “Basic Security” page, check the Enable radio button next to H323 ALG. Remember to click the Save button.
-
Page 137: Appendix B: Configuring The Pc
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Appendix B: Configuring the PC In this section, we’ll introduce how to install and configure the TCP/IP correctly in Windows XP. First make sure your Ethernet Adapter is working, refer to the adapter’s manual if needed. - Page 138 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual The following TCP/IP Properties window will display and the IP Address tab is open on this window by default. Select Obtain an IP address automatically and Obtain DNS server automatically, as...
-
Page 139: Appendix C: Specifications
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Appendix C: Specifications General IEEE 802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b, IEEE Standards 802.11a, IEEE 802.11e, IEEE 802.11i, IEEE 802.1X, IEEE 802.3X, IEEE 802.3, IEEE 802.3u, IEEE 802.3ab TCP/IP, PPPoE, DHCP, ICMP, NAT, SNTP, IGMPv3, L2TP, PPTP,... -
Page 140: Appendix D: Glossary
AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual Appendix D: Glossary 802.11ac - IEEE 802.11ac is a wireless computer networking standard of 802.11.This specification will enable multi-station WLAN throughput of at least 1 gigabit per second .This is accomplished by extending the air interface concepts embraced by 802.11n: wider RF bandwidth, more MIMO spatial streams, multi-user MIMO, and high-density modulation (up to 256 QAM). - Page 141 AC750 Wireless Dual Band Gigabit Router RNX-AC750RT User Manual MTU (Maximum Transmission Unit) - The size in bytes of the largest packet that can be transmitted. NAT (Network Address Translation) - NAT technology translates IP addresses of a local area ...
