- Page 1 Quick Installation Guide Wireless Router RNX-EasyN400...
- Page 2 Connect the supplied power-adapter to the power inlet port and connect it to a wall outlet. Then, the router automatically enters the self-test phase. During self-test phase, RNX-EasyN400’s Power LED will blink briefly, and then will be lit continuously to indicate that this product is in normal operation.
- Page 3 Quick Installation Guide Wireless Router RNX-EasyN400 STEP 3 Connect RNX-EasyN400’s LAN port & PC/Notebook RJ45 port with network cable. STEP 4 Insert Wizard CD into your CD-ROM drive and browse it with Windows Explorer. Double Click on “Wizard.exe” to activate SMART WIZARD.
- Page 4 Quick Installation Guide Wireless Router RNX-EasyN400 Please click on Setup Wizard and follow the instruction given to complete the device initiation configuration. Internet Connection Wizard 1. Click on the Internet Connection Setup Wizard button to begin the process. 2. The Wizard requires that you configure the password, time zone, and Internet (WAN) connection.
- Page 5 Quick Installation Guide Wireless Router RNX-EasyN400 PPTP 1. Select the PPTP radio button and then click on the Next button. 2. Address Mode: PPTP can be used with a dynamic or static IP address. If you select the Dynamic IP radio button, then the IIP address in the next field is not required.
- Page 6 Quick Installation Guide Wireless Router RNX-EasyN400 4. BingPond Server: Specify the server name or IP address as specified by your ISP. 5. Click on the Next button to continue. 6. The WAN configuration is complete. Click on the Connect button to connect to the Internet.
- Page 7 Internet. For advanced configuration, refer to the User’s Manual in the CD-ROM provided. Once complete, you should be ready to surf! Thank you for supporting Rosewill. Note: 1. Please update the Wireless Adapter’s Firmware of your Notebook and PC to the...
- Page 8 Time Warner Cable Modems, will keep the modem on and connected. Due to the ADSL/Cable modem not assigning the correct DHCP information, the Rosewill Routers can not work correctly and assign a DHCP to the client computers.)
