Summary of Contents for AMC iMIX1
- Page 2 Important Do not install this equipment in a confined space such as a book case or similar unit. The apparatus should not be dripped or splashed and no objects filled with liquids, such as vases, should not be placed on the apparatus. This unit should not be used near water (e.g.
-
Page 3: Front Panel
Front Panel 1. MIC 1 Volume Control 11. CHIME Volume Control 21. CD LED Indicator 2. MIC 2 Volume Control 12. BASS Control 22. Tuner LED Indicator 3. MIC 3 Volume Control 13. TREBLE Control 23. AUX 1 LED Indicator 4. - Page 4 CD, Aux, Tuner, and Chime Connection (Input) iMIX1 has ability to connect 3 auxiliary inputs, which may be used for connecting signal sources such as a Radio Tuner, CD or Cassette player. The Aux input sockets are standard stereo RCA connectors.
- Page 5 Power Source AC 115V/230V 50/60 Hz, DC 24V Frequency Response 20Hz ~ 20KHz Total Harmonic Distortion ≦1% @ 1KHZ Input Sensitivity MIC 1 ~5: 1mV @600Ω, Balanced (with Phantom power switch) AUX 1 ~3: 150mV @1KΩ,Unbalanced CD: 150mV @1KΩ, Unbalanced Tuner: 150mV @1KΩ,Unbalanced Chime: 1 V @10KΩ,Unbalanced Output Sensitivity...
- Page 6 AMC is a registered trademark of AMC Baltic www.amcpro.lt...
