Summary of Contents for AMC iA240X
- Page 1 User iA240X / iA360X Manual Power amplifier...
- Page 2 RISK OF ELECTRIC SHOCK with liquids, such as vases, shall be placed on the apparatus. DO NOT OPEN USER MANUAL iA240X/iA360X Power amplifier...
-
Page 3: Table Of Contents
Controls and connectors Introduction ..............................2 Connectors ................................8 Features ................................2 Cable wiring examples .........................8-9 Block diagram ...............................10 Operation Specifications Front panel ................................3 Rear panel................................4 General specifications ..........................11 Front panel operation ..........................5 Rear panel operation ..........................6 Output terminal .............................7 USER MANUAL iA240X/iA360X Power amplifier... -
Page 4: Introduction
Used in a medium and large public address or voice evacuation systems. FEATURES • Balanced XLR inputs • Phoenix output connectors • HPF filter • DC 24V external power supply input • Input gain control • DC 24V link connector • LINK output • Power, signal, protect and temp indicators • Ground lift USER MANUAL iA240X/iA360X Power amplifier... -
Page 5: Operation
Operation Front Panel 1. Power switch | 2. Power indicator | 3. Protect indicator | 4. Temp indicator 5. Signal indicator 6. Cooling vent USER MANUAL iA240X/iA360X Power amplifier... -
Page 6: Rear Panel
Operation Rear Panel 1. Cooling vent 2. Ground lift switch | 3. Input gain control 4. HP filter switch | 5. Balanced XLR input | 6. Link output 7. Link for DC 24V power supply | 8. Input for DC 24V power supply 9. Amplifiers output 10. AC fuse holder 11. Main power connector USER MANUAL iA240X/iA360X Power amplifier... -
Page 7: Front Panel Operation
Cool air is pulled in through the front panel fan filters and eliminated through This LED lights up for a few seconds after the iA240X or iA360X is powered on the rear panel vents. and then turns off if the amplifier is not damaged. It is normal for the protection LED to fade slowly when the amplifier is powered off. USER MANUAL iA240X/iA360X Power amplifier... -
Page 8: Rear Panel Operation
Cool air is pulled in through the front panel fan filters and eliminated through AC FUSE HOLDER the rear panel vents. Please use 3,15A, 250V fuse for amplifier iA240X and 4A, 250V fuse for amplifier iA360X BALANCED XLR INPUT Connect audio signal to electronically balanced XLR. Please note that the MAIN POWER CONNECTOR iA240X iA360X needs at least 0 dBu to achieve maximum power. Power connector is designed for main powers connecting to amplifier. This connector is combined with fuse holder. USER MANUAL iA240X/iA360X Power amplifier... -
Page 9: Output Terminal
Operation Output terminal Amplifiers output can run only one configuration at the same time. Operating amplifiers using 4 Ω and 70 or 100 volt concurrently may cause damage to the amplifier or connected speakers. USER MANUAL iA240X/iA360X Power amplifier... -
Page 10: Connectors
Cable to unbalanced input from balanced output. TRS and TS connectors. TRS connector Cable to balanced input from unbalanced output. TS and TRS connectors. XLR male connector RCA connector Cable to unbalanced input from unbalanced output. TS connectors. XLR female connector USER MANUAL iA240X/iA360X Power amplifier... - Page 11 Cable to unbalanced input from RCA output. RCA and TS connectors. Cable to unbalanced input from balanced output. XLR and TS connectors. Cable to balanced input from RCA output. RCA and XLR connectors. Cable to balanced input from unbalanced output. TS and XLR connectors. Cable to balanced input from RCA output. RCA and TRS connectors. Cable to balanced input from balanced output. TRS and XLR connectors. Cable to RCA input from balanced output. RCA and XLR connectors. RCA cable. Cable to RCA input from balanced output. RCA and TRS connectors. USER MANUAL iA240X/iA360X Power amplifier...
-
Page 12: Block Diagram
Controls and connections Block diagram USER MANUAL iA240X/iA360X Power amplifier... -
Page 13: General Specifications
60 Hz – 20 kHz Dimensions 88 mm (H) x 482 mm (W) x 377 mm (D) HP filter 3dB at 100Hz The specifications are correct at the time of printing this manual. For improvement purposes, all specifications for this unit, including design and appearance, are subject to change without prior notice. USER MANUAL iA240X/iA360X Power amplifier...
