- Page 1 OWNER INFORMATION Pre-2DSP Preamp-processor Precision Innovation & Musicality Audio Refinement...
- Page 2 PRE-2DSP PREAMP-PROCESSOR ACKNOWLEDGMENT & TRADEMARK...
-
Page 3: Table Of Contents
UNPACKING AND INSPECTION ................ CARE USE ......................FRONT PANEL FUNCTIONS ................REAL PANEL FUNCTIONS ................. REAL PANEL CONNECTIONS ................CONNECTIONS OF PRE-2DSP ................REMOTE CONTROL .................... SPECIAL RECOMMENDATIONS AND NOTICE ITEMS ........OPERATION ......................LCD DISPLAY AND INDICATORS ............. INPUT SOURCE SELECTION .............. -
Page 4: Introduction
Do not handle your AC cord with wet hands. If liquid spills on your Pre-2dsp, unplug immediately and contact your dealer for cleaning instructions. Do not remove the top cover of your Pre-2dsp or attempt to modify any circuitry. This will void your guarantee and could result in serious injury. -
Page 5: Front Panel Functions
7. VOL/ADJUST Button 7. VOL/ADJUST Button This sensor receives a signal from the remote Increase/decrease the Volume level . Volume This button to turns ON or STANDBY Pre-2DSP . STANDBY handset. Increase/decrease the Delay times. Delay Increase/decrease the Balance level. -
Page 6: Real Panel Functions
6. D1, D2, D3 COAXIAL Digltal Inputs 6. D1, D2, D3 COAXIAL Digltal Inputs This is the main power switch for the Pre-2DSP , in the off DVD player or any video player. position, all function are disabled, including the front These three sockets all coaxial digital inputs. -
Page 7: Real Panel Connections
REAL PANEL CONNECTIONS REAL PANEL CONNECTIONS DVD/Video Player DVD/Video Player DVD/Audio Player DVD/Audio Player TV Monitor TV Monitor Video Cassette Recorder Video Cassette Recorder CD Player/Transport CD Player/Transport Composite Composite Component Component Digital Out Digital Out Composite Composite S-Video S-Video Audio Audio Audio... -
Page 8: Connections Of Pre-2Dsp
Left and Right Rear Channel Outputs Connect the Left and Right rear outputs of your Pre-2DSP to the input of the two channel amplifier or to two channels of a multi-channel amplifier that are connected to your left and right surround (LS, RS) speakers. - Page 9 Input connectors of the Pre-2DSP . Once you have connected the component video Sources to the inputs of the Pre-2DSP , you will need to assign the component video sources to any of the six Audio/ Video Inputs. Refer to the setup instructions for component video assignment procedures.
-
Page 10: Remote Control
First press this button then press vol button to set 5CH 1. POWER Button 1. POWER Button output volume. Custom set the volume setting for 6 channels Turn Pre-2dsp into ON or STANDBY status. 20. EX Button 20. EX Button 2. OSD Button 2. OSD Button Press this button to display the function on UP-GRAGE for EX 6.1 . -
Page 11: Special Recommendations And Notice Items
In the following pages, detailed explanations are given to guide you thru the proper operation of Pre- 2dsp. As you might have noticed, there is 8pcs of buttons on the front panel. The Pre-2dsp was purposely designed this way to eliminate the hassle of having too many buttons/knobs. Our engineers have designed a user-friendly remote control unit that the entire operation of Pre-2dsp will be solely based on. -
Page 12: Lcd Display And Indicators
Playing DVD, DVD Audio, CD, LD, TUNER, SAT, VCR and Games with analog outputs connected to the analog inputs (A1, A2, A3, A4,& TAPE) of Pre-2DSP , the display shows the following information. Playing DVD title with Dolby Digital (AC-3) f Dolby Digital (AC-3) ormat, the display shows the following information. -
Page 13: Remote Commands Code
Signal entering Component connector only can output from (MONITOR COMPONENT OUT) video connector. Video entering V1, V2, V3, and V4 can only output from (V OSD) MONITOR. S connector video entering S1, S2, S3, and S4 can only output from (S OSD MONITOR). The OSD display signal output from S connector is taken from VIDEO connector as background signal. -
Page 14: Osd (On-Screen Display)
Any on-screen display shown on the monitor TV will not be recorded note VIDEO 1. In some countries, Pre-2DSP allows you to select either NTSC or PAL color system as video format. If it is different from your video components, video softwares, etc., in the Power ON mode, press the... -
Page 15: Master Volume Control
MASTER VOLUME CONTROL Volume Setting Volume Setting To increase or decrease the master volume of Pre-2dsp, simply press VOL + or VOL - on the remote VOL + VOL - control. Example : Volume being decreased by 35 decibels. Adjust... -
Page 16: Test A/M Mode
When test mode is running, the display shows information in a sequence as below: SOUND FIELD PROCESSING The Pre-2dsp is equipped with a sound field processor that gives you six different field effects including Disable, Hall, Theater, Stadium, Club, and Church. By pressing Field Button on the remote, you can select among these effects. -
Page 17: Speaker Placement
SPEAKER PLACEMENT MONITOR MONITOR In order that your home theater could have the most idealistic audio effect, you can place speakers by following the directions as shown below: Placement of front speaker: Like the commonly used stereo sound speakers, the front speakers should be placed on the front right and front left positions at the same distance to the TV at the center. -
Page 18: Time Delay Adjustment On Center Channel Speaker
In this reason, the sound imaging not as sharp and stable as it could be. For audible improvement, the sound from center speaker could be delayed with the center delay time setting to synchronize the sound from the front and the center speaker and the sound from the rear speaker could be also delayed with the rear delay time setting so that the sound from the front and the rear speakers will be heard at the same time. -
Page 19: Bass Crossover Network Setting
SPEAKER MODE WITH BASS MANAGER Six LEDs on front panel of Pre-2dsp represent 6 Discrete audio channels (L, R, C, SL, SR, LFE). If a Particular channel is active, the LED will light up in green. Red color LED means that particular channel carries bass signal below (80Hz~120Hz). -
Page 20: Prologic Mode
Bass Config. 1 Bass Config. 1 With this setting, bass signal below 120Hz will be sent to subwoofer; LEDs on front panel of Pre-2dsp indicating LFE SW will be in red, and LCD will show the following information Bass Config. 2 Bass Config. -
Page 21: Saving Presets
Prologic Button until you see the display with following information Prologic Button SAVING PRESETS SAVING PRESETS The Pre-2dsp allows you to customize up to 5 settings. This function allows you to program, save and load Your favorite configurations at any time you want. Preset settings Preset settings... -
Page 22: Tape Monitor
EQUALIZATION 5-Band Equalization 5-Band Equalization The Pre-2dsp features an on board 5-band equalizer which allows you to fine tune the sound of your favorite movie/music. Press EQ SETUP Button on the remote to activate it. Repeatedly pressing EQ SETUP Button EQ SETUP Button will circle among 5 bands. -
Page 23: Troubleshooting
"HALF" means the audio signal is partially compressed, this function is useful if Pre-2dsp is connected to an external amplifier. "FULL" means the audio signal is completely compressed, this function is useful if Pre-2dsp is connected to an external amplifier. -
Page 24: Recommendations
Note: Design and specifications are subject to change without notice for improvements. RECOMMENDATIONS Do not place Pre-2DSP on a glass shelf. If you really must, use "Altuglass" on the shelf. We do highly recommend placement on wood or granite. For best sonic results, correct orientation of the AC plug is important. The prong with the red dot should be connected to the "hot"...
