Wittenborg FB 5100 Service Manual page 81

List of items
Parts
1. Colour panel
2. Info display cover
Coin slot and coin return button
3.
4. Blank panel
Preselector button row
5.
6. Info display: in the vending mode it shows all data concerning sales and
malfunctions, in the service mode it shows all programming and setting
data
7. Direct selector button rows 1-4
Direct selector button extension row
8.
9. Multibrew / Key
10. Emergency stop button
11. Coin return cup
12. Wittenborg logo
SPC circuit board
13.
14. Insulation foil for SPC
Reinforcement plate, SPC circuit board
15.
16. Door frame
17. Coin return mechanism
18. Coin insert
19. Coin mechanism
Door cover
20.
21. Coin chute
Cash box
22.
