Dismounting the info display

Procedure Follow this procedure to dismount the info display:
Step Action
1. Remove the button module.
2. Disconnect the electrical connections to the info display.
Remove 4 screws (1), then remove the LCD module with the info
3.
display.
Remove 4 screws (2) in the LCD module frame (3), then remove the
4.
info display (4).
9
3
4
1
2
