Dismounting the card reader
Procedure
Warning
Reference
Follow this procedure to dismount the card reader:
Step
Action
1.
Open the door and dismount door cover.
2.
Disconnect the electrical connection to the card reader.
Remove the screws and
3.
remove the card reader.
Never adjust the card reader or disconnect the connecting cable while
the machine is carrying voltage.
For more information concerning the card reader refer to the information
of the manufacturer.
Illustration
7
