Wittenborg FB 5100 Service Manual page 79

List of items
Parts
1. Colour panel
2. Info display cover
Card slot and card return button
3.
4. Blank panel
Preselector button row
5.
6. Info display: in the vending mode it shows all data concerning sales and
malfunctions, in the service mode it shows all programming and setting
data
7. Direct selector button rows 1-4
Direct selector button extension row
8.
9. Multibrew / Key
10. Emergency stop button
11. Blank panel
12. Wittenborg Logo / Optical interface
SPC circuit board
13.
14. Insulation foil for SPC
Reinforcement plate, SPC circuit board
15.
16. Door frame
17. Card reader
18. Door cover
19. Cover plate for cash box
3
