  • Page 1 OPERATOR MANUAL ES 7100 PLUS H0412EN00 10.2011...
  • Page 2 The symbol indicates that the machine may not be disposed of as ordinary waste; it must be disposed of in accordance with the provisions of the European directive 2002/96/CE (Waste Electrical and Electronics Equipments - WEEE) and of any resulting national laws, for preventing any possible adverse effects on the environment and on human health.

  • Page 3: Table Of Contents

    Filling the coffee bean canister............. 31 Preparing the brewer cleaning with cleaning tablet ..... 50 Cleaning the cup carrier ............... 32 Table of cleaning procedure for brewer with cleaning tablet ..52 Unlocking the drip tray..............33 10.2011 ES 7100 PLUS...
  • Page 4 - General instructions ..............74 Espresso brewer unit maintenance..........75 Removing the upper filter ............. 75 Removing the lower filter.............. 76 Cleaning brewer parts ..............77 Display messages and trouble shooting Display messages ................ 78 Trouble shooting ................80 ES 7100 PLUS 10.2011...

  • Page 5: Introduction

    The machine is delivered with direct selection buttons. All communication with the machine, such as drink selection, rinsing functions, data retrieval and settings, is carried out by using the direct selection buttons. 10.2011 ES 7100 PLUS...

  • Page 6: Safety

    • After the machine has been installed, the additionally carry out a functional test. power supply plug must be accessible. • The vending machine may not be installed outside. ES 7100 PLUS 10.2011...
  • Page 7 The light of LEDs may be noxious if you directly look at it without these If power is turned on, be careful not panels. to touch moving parts and electrical components. 10.2011 ES 7100 PLUS...

  • Page 8: Technical Data

    Connect the water network with the 3/4” gas union of the water inlet solenoid valve by means of a tube that can support the network pressure and of a type suitable for foodstuffs (min. inner diameter 6 mm.). ES 7100 PLUS 10.2011...
  • Page 9 Standard Instant ingredient canister: Approximately 2.6 l Further system require- Ambient temperature. Min. 4°C - max. 36°C (-2/+0) at 80% RH ments Acoustic emission: The A-weighted sound pressure level is below 70 dB. Subject to changes. 10.2011 ES 7100 PLUS...

  • Page 10: Product Presentation

    4 Coffee bean canister 5 Operating panel 6 Door lock 7 Cup carrier 8 Pot platform Operating panel (fig. 2): 1 Display 2 Payment panel 3 Selection panel 4 Pot panel/Discount key 5 Optical interface 6 Coin return cup ES 7100 PLUS 10.2011...

  • Page 11: Machine Cabinet

    24 Outlet spout 10 Coffee waste containers 25 Instant ingredient canister 11 Base tray 26 Coffee bean canister 12 Outlet hoses 27 Cabinet 13 Main switch 14 Ingredient waste shelf 15 Cash box (option) 16 Drip tray 10.2011 ES 7100 PLUS...

  • Page 12: Operation

    • If the machine is not set to free vend, Pressing again will increase the displayed insert a card with sufficient credit, or counter by one, up to the maximum value insert an amount of coins corresponding ES 7100 PLUS 10.2011...

  • Page 13: Discount Lock

    • Press the selection button of the desired pots. drink. • After dispensing, remove the cup. If you want one or more drinks at a dis- count: • • Press the multibrew button and insert the password needed to avoid free drink dispensing. 10.2011 ES 7100 PLUS...

  • Page 14: Navigation Buttons

    No. per group, res Turn. p. group,nres (See explanation on previous pages). Turn. p. group,res Card audit No. per drink, nres No. per drink, res Turn. p. drink,nres Turn. p. drink,res Continued on next page ES 7100 PLUS 10.2011...
  • Page 15 MB. number, res MB. turnover, res Discount key audit D.Key number ,nres D.Key turnov. ,nres D.Key number ,res D.Key turnov. ,res Time Discount audit T.Disc number ,nres T.Disc turnov.,nres T.Disc number ,res T.Disc turnov.,res Continued on next page 10.2011 ES 7100 PLUS...
  • Page 16 Reset tube contents Basic operations Change prices Global price Price per drink Step prices Change quantities Drink On/Off Change group Service information Event log book Reset log book Program versions Show menufile ver. Continued on next page ES 7100 PLUS 10.2011...

  • Page 17: Overview Of Operator And Technicians Functions

    Energy saving Save Energy On/Off Set Day(s) Set Time Set Temperature Set Doorlight Set counters on/off Selfcheck setting Gr. counters on/off 100% discount mode Use EVA-DTS events ES System Test Complete ES cycle Continued on next page 10.2011 ES 7100 PLUS...
  • Page 18 ES Precomp. Managm. ES Valve Type ES Pellet Squeezing Set Rinse Timeout Global dr. scaling Reset relationship Change Comm. route Closed door Serial XModem Serial EDDCMP IR XModem IR EDDCMP Back to terminal Continued on next page ES 7100 PLUS 10.2011...
  • Page 19 Zero vend mode Zero vend index Revalue Immediate change Currency code(auto) Currency code(man) Coin validator Decimal point pos. Freevend count.mode Delayed Paymentmode Set Cash Sale Sess. Complete Mode Autom Cashaudit Res Pricelist Start Nr. Continued on next page 10.2011 ES 7100 PLUS...
  • Page 20 Diagnostics/Test Overall functions Wittlink test Full dispense test Test vend Cup handling Sensor test User interface Button/Key test Display test Pre. sel. led test Door light toggle Test Init.text Coin return motor Continued on next page ES 7100 PLUS 10.2011...
  • Page 21 Test IN motor no.X Test all IN motors Change password GSM settings GSM On/Off PIN Code Pre-Alarms Set GSM Thresholds Reset Pre-Al. cnt Bank ID's Reset GSM relations DaylightSaving UP KEY Utility Setup files Statistics files 10.2011 ES 7100 PLUS...
  • Page 22 (See also diagram “Overview of Operator and ----SALES AUDIT---- *Total number Technicians functions” on page 10.) Total turnover • jump to the top of a row, e.g. from “Turnover per drink” to “Total turnover”. ES 7100 PLUS 10.2011...
  • Page 23 Reset cash audit Continue? resetting of counters. *Reset counters ‘Esc’ button Press this button to exit a function without activating Reset cash audit Continue? it, e.g. avoid resetting a *Reset counters counter. 10.2011 ES 7100 PLUS...

  • Page 24: Settings Buttons

    Press this button to continue to the next digit, Price: [Drink] e.g. in price setting *Set price: xx.xx functions. -> ‘OK’ button Press this button to save changes to settings in the Price: [Drink] *Set price: xx.xx system. -> ES 7100 PLUS 10.2011...

  • Page 25: Short Cuts

    • The machine can be set to enable selection of several drinks, one after the other, from only one payment action by coins or card. Single-vend • The machine can be set to return coins / release payment card after each drink selection. ES 7100 PLUS 10.2011...
  • Page 26 .. Perform a rinse function Step 5 Perform a test vend Step 7 Read the counters Step 8 Proceed to the menu functions Step 9 1. This short cut is not present in all machines. 10.2011 ES 7100 PLUS...
  • Page 27 Press “3” ----SALES AUDIT--- *Total number, nres Total turnover,nres and, if open, close the door to go directly to reading the counters. From here you can select one of the available counters. ES 7100 PLUS 10.2011...
  • Page 28 Operation Step Action Display Press “4” --MENU SELECTION-- *Operator Technician and, if open, close the door to go directly to the menu selections. From here you can select one of the menus 10.2011 ES 7100 PLUS...

  • Page 29: Cleaning And Maintenance

    Clean the inside and outside of the vending machine by using a clean damp cloth, and do not splash it. • Use only cleaning agents approved by the food industry, or the supplier of the vending machine. 10.2011 ES 7100 PLUS...

  • Page 30: Maintenance Routines

    Filling the instant ingredient canisters required Soft clean cloths or paper towels Filling the coffee bean canister Ingredients Cleaning the cup carrier Cleaning the drip tray Cleaning the machine interior and exterior Mounting the cleaned parts Rinsing machine Last check ES 7100 PLUS 10.2011...

  • Page 31: Schedule For Deep And Occasional Maintenance Routines

    80°C). Cleaning the instant waste tray below the instant ingredient mixing funnels. Cleaning the cup carrier and the drip tray. Cleaning inside and outside. Mounting cleaned parts. Rinsing machine. Last check. 10.2011 ES 7100 PLUS...
  • Page 32 Cleaning and maintenance Interval Type of work / Check Exchange kit (hygiene kit) Occasional Cleaning the instant ingredient canisters Once a month Cleaning the coffee bean canister. ES 7100 PLUS 10.2011...

  • Page 33: Regular Cleaning

    If power is turned on, be careful not to touch moving parts and electri- • Carefully wipe dry the sensors of the cal components! liquid waste container (fig. 11). • Leave the coffee waste containers outside of the machine. 10.2011 ES 7100 PLUS...

  • Page 34: Filling The Instant Ingredient Canisters

    Place canister on a plain, clean isters. surface. • Pull base tray forward (fig. 12). • Fill the canister with instant ingredient, press lid slightly down and push back canister in place. ES 7100 PLUS 10.2011...

  • Page 35: Filling The Coffee Bean Canister

    • Wipe clean the base tray and the area behind the waste containers. • Push base tray back in place. • Relocate the waste containers. 10.2011 ES 7100 PLUS...

  • Page 36: Cleaning The Cup Carrier

    (a) and tray (b) in hot water your left hand remove the corresponding with cleaning agent and dry parts. retaining pin, situated on the rear side of the cup station. (fig. 17). The complete cup carrier is dish- washer-proof. ES 7100 PLUS 10.2011...

  • Page 37: Unlocking The Drip Tray

    • Remove the lid and empty the tray. cup station. (fig. 20). • Clean drip grid, lid and tray in hot water with cleaning agent and wipe parts dry (fig. 21). Wipe sensor (fig. 21,a) in lid dry. 10.2011 ES 7100 PLUS...

  • Page 38: Cleaning Inside And Outside

    Cleaning inside and outside Mounting of cleaned parts • Clean the door and the housing inside • Re-insert and assemble all parts in and outside, and finally the bottom with a reverse order. clean, damp cloth (fig. 22). ES 7100 PLUS 10.2011...

  • Page 39: Rinsing Machine

    ES 7100 Rinsing machine • Have an empty pot (min.1,5 l) ready to place on the pot platform (fig. 23) • Turn to the display and follow the diagram to perform a machine rinse. 10.2011 ES 7100 PLUS...

  • Page 40: Last Check

    (see diagram above). In this case the drink will not be included in the Sales Audit counter (see “Calling and resetting counters” on page 53). There is a risk of scalding from hot water. ES 7100 PLUS 10.2011...

  • Page 41: Deep Cleaning

    - instant ingredient mixer unit with whipper ries 24V current. wheels - powder traps If power is turned on, be careful not - dispense head with hoses and coffee to touch moving parts and electri- outlet cal components! - cup carrier 10.2011 ES 7100 PLUS...

  • Page 42: Filling The Instant Ingredient Canisters

    • Pull forwards the base tray (fig. 26). outlet spout of the wanted canister one as described in regular cleaning (fig. 27). (fig. 28). • Leave the outlet spouts closed. • Remove the base tray from machine. ES 7100 PLUS 10.2011...

  • Page 43: Removing The Coffee Bean Canister

    • Lift the canister out of the machine and hole in dispense head and lift off the spout place the canister outside of the machine (fig. 31). on a plain clean surface. 10.2011 ES 7100 PLUS...

  • Page 44: Cleaning The Ingredient Waste Shelf Below Instant Ingredient Mixers

    • Lift off and wipe clean the ingredient • Remove the bracket for dispense head by forwards. (fig. 32). waste shelf with a moist cloth (fig. 33). loosening the securing bolt (fig. 34). • Clean the bracket and wipe it dry. ES 7100 PLUS 10.2011...

  • Page 45: Removing The Brewer

    • Relocate the ingredient waste tray. (fig. 35). (fig. 36). • Loosen the securing bolt retaining the Clean espresso brewer every time brewer to its bracket. coffee is refilled or at least once a week. • Remove the brewer. 10.2011 ES 7100 PLUS...

  • Page 46: Cleaning The Instant Ingredient Dispensing System Components

    (fig. 38). • Rinse parts in clean hot water, dry and relocate items in reverse order. ES 7100 PLUS 10.2011...

  • Page 47: Cleaning The Cup Carrier

    • Take out and clean the drip tray and its regular cleaning). (fig. 42). (see regular cleaning). parts (fig. 43). (see regular cleaning). • Clean the drip grid and tray (see regular Always wipe sensor in lid dry. cleaning). 10.2011 ES 7100 PLUS...

  • Page 48: Cleaning Inside And Outside

    (fig. 44). • Flush all parts which have been soaking thoroughly with clean and warm water. • Dry all parts with a dry cloth. ES 7100 PLUS 10.2011...

  • Page 49: Mounting Cleaned Parts

    • Pull out shutter (bean stop) to open that the crank arm of the coffee If properly seated, the hoses will be position, after canister is repositioned. motor is correctly engaged in its retained by the locking rings. seat. 10.2011 ES 7100 PLUS...

  • Page 50: Rinsing And Last Check

    • Clean outside of machine with a clean damp cloth (fig. 50). • Perform a test dispensing by pressing a selection button, e.g. coffee with milk and sugar or using the ‘Test’ option (see regular cleaning, “Last check” on page 36). ES 7100 PLUS 10.2011...

  • Page 51: Occasional Routines

    (fig. 51) until end stops in guiding rail. Lift the canister upwards and pull forwards over the end stops. The lid is automatically triggered open. • Remove the entire lid. 10.2011 ES 7100 PLUS...
  • Page 52 • Let components dry completely The canisters must always be re- • Reassemble instant ingredient canister in turned to their original position. reverse order. ES 7100 PLUS 10.2011...

  • Page 53: Cleaning The Coffee Bean Canister

    • Soak canister in hot water with cleaning • Lift off canister from the grinder. agent. • Rinse canister thoroughly in hot clean water. • Let canister dry completely. • Fill canister with coffee beans and re- insert canister in machine. 10.2011 ES 7100 PLUS...

  • Page 54: Cleaning The Brewer With Cleaning Tablet

    • Turn the door key clockwise in keyhole and lower filter. and open the door. • Turn the machine off with main switch (fig. 59) before disassembling parts in connection with the brewer parts. ES 7100 PLUS 10.2011...
  • Page 55 • Have an empty container (min. 2 l) ready to place on the pot platform. • Open the door. • Have a cleaning tablet ready to fill into the 1. Coffee funnel 2. Cleaning tablet brewing chamber. 3. Brewing chamber 10.2011 ES 7100 PLUS...

  • Page 56: Table Of Cleaning Procedure For Brewer With Cleaning Tablet

    If a cleaning cycle is interrupted, manually, due to power fail- ure, or on powering up the machine again, a rinsing cycle is required to remove any residue of the cleaning tablet. No espresso based selections can be made until this rinse cycle has been performed. ES 7100 PLUS 10.2011...

  • Page 57: Additional Routines

    Total: 00000.00 No. per drink, nres Coffee black Total: xxxxxx Coffee w sugar Total: 000.00 No. per drink, res Coffee black Total: xxxxxx Coffee w sugar Total: 000.00 Turn. p. drink,nres Cash audit Continued on next page 10.2011 ES 7100 PLUS...
  • Page 58 Total: xxxxxx MB per drink, nres Coffee black Coffee w sugar Total: 000.00 Total: xxxxxx MB per drink, res Coffee black Coffee w sugar Total: 000.00 No. per group, nres Cash audit Continued on next page ES 7100 PLUS 10.2011...
  • Page 59 Total: xxxxxx Group 2 Total: 000.00 Turn. p. group,nres Group 1 Total: xxxxxx Group 2 Total: 000.00 Turn. p. group,res Group 1 Total: xxxxxx Group 2 Total: 000.00 Card audit Cash audit Continued on next page 10.2011 ES 7100 PLUS...
  • Page 60 Coffee Total: 0000000 Coffee with milk Total: 0000000 Turn. p. drink,nres Coffee Total: 0000000.00 Coffee with milk Total: 0000000.00 Turn. p. drink,res Coffee Total: 0000000.00 Total: 000.00 Coffee with milk Cash audit Continued on next page ES 7100 PLUS 10.2011...
  • Page 61 Collected money Amount: 00000.00 Manually filled Amount: 00000.00 Manually delivered Amount: 00000.00 Value overpay Amount: 00000.00 Cashless audit Dispensed change Amount: 00000.00 * Applicable only to BDV and MDB/ ICP coin mechanisms. Continued on next page 10.2011 ES 7100 PLUS...
  • Page 62 No. per drink, nres Coffee black Total: xxxxxx Coffee w sugar Total: 000.00 No. per drink, res Coffee black Total: xxxxxx Coffee w sugar Total: 000.00 MB. discount audit No. per group, res Continued on next page ES 7100 PLUS 10.2011...
  • Page 63 Number: xxxxx MB. turnover, res Amount: 00000.00 Discount key audit D.Key number, nres Number: xxxxx D.Key turnover, nres Amount: 00000.00 D.Key number res Number: xxxxx D.Key turnover, res Amount: 00000.00 Time Discount audit Continued on next page 10.2011 ES 7100 PLUS...
  • Page 64 Additional routines Discount key audit Diagram continued Time Discount audit T.Disc number ,nres Number xxxxxxx T.Disc turnov., nres Number xxxxxxx T.Disc number ,res Number xxxxxxx T.Disc turnov., res Number xxxxxxx Step price audit Continued on next page ES 7100 PLUS 10.2011...
  • Page 65 Reset of sales Reset counters Reset sales audit Continue ? audit finished Reset of cash Reset cash audit Continue ? audit finished Reset of test Reset test audit Continue ? audit finished Printing Continued on next page 10.2011 ES 7100 PLUS...
  • Page 66 Please wait Printing audit Cash Audit Printing Continue? in progress Please wait Printing audit Printing Test Audit Continue? in progress Please wait Printing audit Group Counters Printing Continue? in progress Resettable Continued on next page ES 7100 PLUS 10.2011...
  • Page 67 Printing audit Errors Printing Continue? in progress Please wait Printing audit Printing Cash Audit Continue? in progress Please wait Printing audit Test Audit Printing Continue? in progress Please wait Printing audit Printing Group Counters Continue? in progress 10.2011 ES 7100 PLUS...

  • Page 68: Emptying The Cash Box

    • Pull out the cash box and empty it (fig. 62). • Turn to the display and follow the diagram to register the removed amount electronically. The amount is registered under “Collected money” (See “Calling and resetting counters” on page 53). ES 7100 PLUS 10.2011...

  • Page 69: Adding Change Manually

    “Manually filled”. (See “Calling and Cash action Cash collected resetting counters” on page 53). Dispense coins Press < OK> to Cash audit is Manual filling adjust audit now adjusted * Applicable only to BDV and MDB/ ICP coin mechanisms. 10.2011 ES 7100 PLUS...

  • Page 70: Changing Prices

    Set step price Preselection 1(+) Set step price(s) Select drink Value : 00.00 -> Preselection 1(-) Global price (+) Global stepprice(+) Set value : 00.00 -> Global price (-) Set value : 00.00 Global stepprice(-) -> ES 7100 PLUS 10.2011...

  • Page 71: Setting Of Free Vend And Key Discount

    • turn free vend on or off ES 7100 Cash action • set or change key discount rates. Basic operations Service information Machine settings Set freevend, global (Off = 0, On = 1):1 Key discount Set percentage: 000 10.2011 ES 7100 PLUS...

  • Page 72: Time Discount

    • A period cannot have a ‘start time’ later than the ‘end time’, see Non Example next page. • The same time period cannot include days from different weeks, i.e. a period cannot be set from Monday to Monday. ES 7100 PLUS 10.2011...
  • Page 73 Set end time 14:00 Period 2 Set start day Su=6 Set start time 10:00 Set end day Su=6 Set end time 14:00 Result: Time discount is given on Saturdays and Sundays between 10:00 a.m. and 2:00 p.m. 10.2011 ES 7100 PLUS...

  • Page 74: Setting Time Discount

    Set Time discount (0-100) :20 -> Set start day: Set end day: Set day(s) Period 1 (Mo=0, Su=6, All=7):7 (Mo=0, Su=6, All=7):7 Set start time: Set end time: Set time Period 1 Time: 22:00 Time: 23:59 -> ES 7100 PLUS 10.2011...

  • Page 75: Energy Saving Periods

    22:00 Set end day All=7 set end time 07:00 Result: The machine is not ‘shut down’ as the end time must not be earlier than the start time for the same day or the setting ‘ALL’. 10.2011 ES 7100 PLUS...
  • Page 76 When the selection buttons have been left untouched for more than 10 minutes after the last drinks dispensing, and an energy saving period is still in force, the machine returns to the energy saving mode. ES 7100 PLUS 10.2011...

  • Page 77: Setting Energy Saving Periods

    Set end day: (Mo=0, Su=6, All=7):1 Set start time: Set time Period 1 Time: 00:00 -> Set end time: Time: 00:00 Set temperature -> Set temperature Temp.: 000 -> Set doorlight Set doorlight 1=On / 0=Off:1 -> 10.2011 ES 7100 PLUS...

  • Page 78: Maintenance - General Instructions

    Important: of electrical safety and health regulations. Never touch the adjusting knob of the grinder. Always call a technician for adjust- ment / calibration of grinder! ES 7100 PLUS 10.2011...

  • Page 79: Espresso Brewer Unit Maintenance

    (b, fig. 63) from above, • Turn off the main switch. and remove piston (c, fig. 63). • Remove the dispense head, the bracket for dispense head and finally the brewer (see deep cleaning, page 39 and page 41). 10.2011 ES 7100 PLUS...

  • Page 80: Removing The Lower Filter

    • Remove the scraper (c, fig. 65) by sliding it off the tracks at top of the brewing chamber. • Remove the lower piston snap ring (d, fig. 65) (retaining ring). ES 7100 PLUS 10.2011...

  • Page 81: Cleaning Brewer Parts

    (fig. 67). approx. 20 minutes. • Thoroughly rinse and dry all parts. • Reinstall parts in reverse order of disassembly. 10.2011 ES 7100 PLUS...

  • Page 82: Display Messages And Trouble Shooting

    • Remove impurities from water supply connection. • Empty and clean base tray. Wipe it dry. Base tray full • Empty and clean drip tray. Wipe sensor dry. Drip tray full • Remove cup from cup carrier. Please remove cup ES 7100 PLUS 10.2011...
  • Page 83 • Check if water supply connection is blocked. If necessary remove impurities. • Check if water pressure from the water mains is very low. If necessary, call a plumber. • Refill coffee bean canister No coffee beans • Ensure that the shutter is open. 10.2011 ES 7100 PLUS...

  • Page 84: Trouble Shooting

    Ingredients are moist and become lumpy in canisters. cleaner from outside or take out fan and clean box from the inside of the machine. • Check for blockage around mixing funnels. Remove and install components as necessary. ES 7100 PLUS 10.2011...
  • Page 85 • Ensure that sensor for liquid waste container is not covered by coffee waste bag. • Check if sensors for drip tray or liquid waste container are soiled. Clean as necessary. • Check if mixing funnels are blocked, and clean as necessary. No drinks are delivered. 10.2011 ES 7100 PLUS...
