Fig. 11: The arrangement of terminals of output sockets of Rack Model Sinline battery module

FIRST START

WARNING! The UPS may only be connected to a ~230V mains
socket equipped with a grounding bolt. Electric installation of the
building to which the battery module is connected must be
protected against overloads and shorting.
After unpacking, place the device in the chosen location, connect it to the mains and
turn on the UPS with the switch on the front panel in order to charge the internal
batteries. Charging time of batteries can be found in the technical parameters table.
Afterwards, the user may continue with the installation procedure. Take the following
steps:
• Turn the UPS off (switch in the "0" position) – only if it was turned on,
• connect the devices that require buffer power supply (e.g. computer and
monitor) to the outlet sockets on the UPS,
• connect the UPS to the computer via the RS232 cable,
• turn on the UPS with the switch on the front panel (switch in the "1" position),
• turn on the devices connected to the UPS,
• install the monitoring software on the control computer (see chapter
"Installation and configuration of the PowerSoft software").
With all of the above steps complete the UPS is ready for operation.
WARNING! BACK-UP'S batteries reach their full capacity after
approximately a month of mains operation mode.
2010/01/26
SINLINE series UPS – Instruction Manual
L
PE
N
www.ever.eu
15
