5.8.10.1 Standard TIG torch (5-pole)

Standard torch with one torch trigger:
Diagram
Functions
Welding current On/Off
Secondary current (Latched mode)
Standard torch with two torch triggers:
Diagram
Functions
Welding current On/Off
Secondary current
Secondary current (tapping mode) / (latched mode)
Welding current On/Off
Secondary current (tapping mode) / (latched mode)
Up function
Down function
099-000135-EW501
10.07.2014
Operating Explanation of symbols
elements
BRT1
Operating Explanation of symbols
elements
BRT1
BRT2
Design and function
= Torch trigger 1 (welding current on/off;
secondary current via tapping function)
mode
1
(factory-set)
= torch trigger 1
= torch trigger 2
mode
1
(factory-set)
3
TIG welding
Operating
elements
Operating
elements
55
