Machine description – quick overview
Description 0
7-pole connection socket (digital)
For connecting digital accessory components
PC interface, serial (D-Sub connection socket, 9-pole)
19-pole mechanised welding interface (analogue)
(See chapter entitled "Design and function > interfaces".)
Ignition type changeover switch
= Liftarc (contact ignition)
= HF ignition
Securing elements for shielding gas cylinder (strap/chain)
Mains connection cable
Cooling air outlet
G¼" connecting nipple
Shielding gas connection on the pressure regulator.
Quick connect coupling (red)
coolant return
Quick connect coupling (blue)
coolant supply
Bracket for shielding gas cylinder
Wheels, fixed castors
Tetrix 351 AC/DC
