USE THIS SERVICE MANUAL WHEN SERVICING
Model PLA-50V1

Advertisement

Table of Contents
loading

Related Manuals for NEC PlasmaSync 50MP1

Summary of Contents for NEC PlasmaSync 50MP1

  • Page 1 USE THIS SERVICE MANUAL WHEN SERVICING Model PLA-50V1...

  • Page 2: Table Of Contents

    CONTENTS SAFETY PRECAUTIONS ..........................2-1 USERS MANUAL ............................... 3-1 TROUBLESHOOTING ............................4-1 METHOD OF ADJUSTMENTS .......................... 5-1 CIRCUIT DESCRIPTION ........................... 6-1 METHOD OF DISASSEMBLY ........................... 7-1 PACKAGING ..............................8-1 PARTS LIST ............................... 9-1 CONNECTION DIAGRAMS ..........................10-1 BLOCK DIAGRAMS ............................11-1 SCHEMATIC DIAGRAMS ..........................

  • Page 3: Safety Precautions

    SAFETY PRECAUTIONS CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT OPEN REAR COVER. NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This symbol warns the user that unin- This symbol alerts the user that important sulated voltage within the unit may have literature concerning the operation and...
  • Page 4 SAFETY PRECAUTIONS 1. Before returning an instrument to the customer, al- AC Leakage Test ways make a safety check of the entire instrument, in- cluding, but not limited to, the following items. (READING SHOULD NOT BE ABOVE 3.5 mA) a. Be sure that no built-in protective devices are LEAKAGE DEVICE CURRENT...
  • Page 5 SAFETY PRECAUTIONS 5. Observe original lead dress. Take extra care to assure correct lead dress in the following areas: a. near sharp edges, b. near thermally hot parts— be sure that leads and components do not touch thermally hot parts, c. the AC supply, d. high volt- age, and e.
  • Page 6 PRECAUTIONS DE SECURITE 1. Avant de remettre un appareil à un client, faire courant ne doit dépasser 3.5 milliamp. Inverser la toujours d'abord un examen de sécurité de fiche de courant de l'appareil dans la prise et l'appareil en entier comprenant, mais ne s'y limitant répéter le test.
  • Page 7 PRECAUTIONS DE SECURITE b. Certains châssis de moniteur ont habituellement 6. Les composants, parts (pièces) et/ou fils qui ont été 85V (RMS) entre le châssis et la prise de terre, en trouvés surchauffés devraient être remplacés avec fonction de la polarité de la prise de courant. Ces les composants, pièces et fils s'y reliant avec d'autre châssis peuvent ne comporter aucun risque qui ont les mêmes spécifications que les originales.
  • Page 8 SAFETY PRECAUTIONS 1 . Cautions for disassembly 2. The least minimum caut ions for product disas- (1) For the suspension-type set (No. of workers: 3 sembly to 5 including assistants) • Secure a working space, arranged as wide as pos- •...
  • Page 9 SAFETY PRECAUTIONS (Notes) The component by the name of “module” used in this product is defined as a section that is pro- vided with a digital circuit board (including high- voltage parts) used to emit light in the glass panel part, excluding the surface acrylic fiIter or the tem- pered glass fiIter.

  • Page 10: Users Manual

    PlasmaSync Plasma Monitor User’s Manual NEC Technologies...

  • Page 11: Important Information

    7. Do not attempt to service or repair the unit. NEC is not liable for any bodily harm or damage caused if unqualified persons attempt service or open the back cover. Refer...
  • Page 12 To protect supplied), and one end of the power cable (supplied). your investment in this NEC plasma monitor, please adhere Close the lid tightly until the clamps click. to the following guidelines and recommendations for Use the band to secure the ferrite core (supplied).
  • Page 13 OSM Controls ..........E-17 Menu Operations ..........E-17 Introduction ........... E-2 Picture Settings Menu ..........E-19 Introduction to the PlasmaSync 50MP1 Adjusting the picture ..........E-19 Plasma Monitor ............. E-2 Setting the picture mode according to the The features you’ll enjoy include: ......E-2 brightness of the room ...........

  • Page 14: How To Attach Options To The Plasma Monitor

    (Wall mount unit, Stand, etc.) * See page E-2. • For correct installation and mounting it is strongly recommended to use a trained, authorized NEC dealer. Failure to follow correct mounting procedures could result in damage to the Drawing B equipment or injury to the installer.

  • Page 15: Introduction

    NEC’s PlasmaSync is a seamless blend of cutting-edge Power cord visual technology and sophisticated design. At 50-inches, with a 16:9 aspect ratio, the PlasmaSync 50MP1 certainly RGB cable (Mini D-Sub 15-pin to Mini D-Sub 15- makes a big impression. However, at a mere 4.2 inches/ pin connector) 107 mm thin, the monitor’s sleek techno-art lines blend in...

  • Page 16: Part Names And Function

    Part Names and Function Front View POWER/STANDBY INPUT SELECT VOLUME POWER/STANDBY VOLUME INPUT SELECT PROCEED DOWN LEFT/– RIGHT/+ /EXIT q PROCEED t POWER/STANDBY indicator Sets the On-Screen Menu (OSM) mode and displays When the power is on ......Lights green. the main menu.

  • Page 17: Rear View/ Terminal Board

    Rear View/ Terminal Board VIDEO 1 VIDEO 2 VIDEO 3 L(MONO) VIDEO 1 VIDEO 2 VIDEO 3 L(MONO) CB/PB CR/PR L(MONO) CB/PB RGB 1 CR/PR R/CR/PR L(MONO) B/CB/PB L(MONO) RGB 1 RGB 3 (Digital RGB) SPEAKERS MUST HAVE MORE THAN CONTROL 7WATT RATING LOCK...

  • Page 18: Remote Control Unit

    Remote Control Unit w RGB/PC Press this button to select RGB/PC as the source. → RGB/PC1 → RGB/PC2 → RGB/PC3 RGB/PC can also be selected using the INPUT SELECT button on the monitor. The input switches as follows each time the button is pressed: →...

  • Page 19: Battery Installation And Replacement

    !3 DISPLAY Battery Installation and Replacement Displays the source settings on the screen. Insert the 2 “AAA” batteries, making sure to set them in with the proper polarity. !4 OFF TIMER Activates the off timer for the unit. 1.Press and open the cover. !5 MULTI Press this button to select a screen mode from among single mode, side by side, and picture in picture.

  • Page 20: Using The Wired Remote Control Mode

    Using the wired remote control mode Operating Range Connect the supplied remote cable to the remote control * Use the remote control unit within a distance of about 7 m/ unit’s remote jack and the “REMOTE CONTROL” 23ft. from the front of the monitor’s remote control sensor terminal on the monitor.

  • Page 21: Installation

    SCART output signal, which is RGB with composite sync. NEC can supply a special SCART cable, which will enable you to use the RGB with composite sync signal. To obtain the special cable as well as for further information, please contact NEC help desk 0181 752 3535.

  • Page 22: Connecting Your Pc Or Macintosh Computer

    Connecting Your PC or Macintosh Connecting Your Document Camera Computer You can connect your plasma monitor to a document camera. To do so, simply: Connecting your PC or Macintosh computer to your plasma monitor will enable you to display your computer’s screen 1.

  • Page 23: External Speaker Connections

    External Speaker Connections VIDEO 1 VIDEO 2 VIDEO 3 L(MONO) CB/PB CR/PR L(MONO) RGB 1 RIGHT LEFT R/CR/PR B/CB/PB L(MONO) RGB 3 (Digital RGB) SPEAKERS MUST HAVE MORE THAN CONTROL 7WATT RATING LOCK IMPEDANCE 5 OHM ON /OFF RIGHT LEFT REMOTE CONTROL EXTERNAL...

  • Page 24: Pin Assignments And Signal Levels For 15 Pin Rgb (Analog

    Pin Assignments and Signal Levels for 15 pin RGB (Analog) Pin No. Signal (Analog) 10 9 Green or sync-on-green 15 14 13 12 11 Blue No connection Ground Red ground Green ground Blue ground No connection Sync signal ground No connection Bi-directional DATA (SDA) Horizontal sync or Composite sync Vertical sync...

  • Page 25: Basic Operations

    Basic Operations POWER DIGITAL ZOOM To turn the unit ON and OFF: Digital zoom specifies the picture position and enlarges the picture. 1. Plug the power cord into an active AC power outlet. 1. Press the POINTER button to display the pointer. ( 2.

  • Page 26: Off Timer

    OFF TIMER To cancel the off timer: To set the off timer: 1. Press the OFF TIMER button twice in a row. The off timer can be set to turn the power off after 30, 60, 2. The off timer is canceled. 90 or 120 minutes.

  • Page 27: Wide Operations

    WIDE Operations Watching with a wide screen STADIUM size screen (manual) With this function, you can select one of four screen sizes. When watching videos or digital video discs 1. Press the WIDE button on the remote control unit. 2. Within 3 seconds ... Press the WIDE button again.

  • Page 28: Watching Computer Images With A Wide Screen

    Watching computer images with a FULL size screen wide screen Switch to the wide screen mode to expand the 4 : 3 image to fill the entire screen. 1. Press the WIDE button on the remote control unit. 2. Within 3 seconds ... Press the WIDE button again.

  • Page 29: Multi Screen Operations

    MULTI SCREEN Operations Showing a couple of pictures on the VIDEO1 RGB/PC1 screen at the same time * An RGB-input picture may not be displayed in these modes, depending on the input signal specifications. 1. Press the MULTI button to select a screen mode from among single mode, side by side, and picture in picture.

  • Page 30: Menu Operations

    Controls (On Screen Menu) Menu Operations 5. The change is stored until you adjust it again. 6. Repeat steps 2 – 5 to adjust an additional item, or press The OSM window is displayed with respect to the the EXIT button on the remote control unit to return to screen as shown on the diagram.
  • Page 31 Main menu Sub menu Functions Default Reset PICTURE CONTRAST Adjusts the contrast. Center BRIGHTNESS Adjusts the brightness. Center SHARPNESS Adjusts the sharpness. Center COLOR Adjusts the color. Center TINT Adjusts the tint. Center PICTURE MODE Sets the picture mode according to the VIDEO environment and MEMORY image software.

  • Page 32: Picture Settings Menu

    Picture Settings Menu 4. Once the adjustment is completed ... Press the EXIT button to return to the main menu. Adjusting the picture To delete the main menu, press the EXIT button once The contrast, brightness, sharpness, color and tint can be more.

  • Page 33: Setting The Picture Mode According To The Brightness Of The Room

    Setting the picture mode according to the 4. Once the adjustment is completed ... brightness of the room Press the EXIT button to return to the main menu. To There are four picture modes that can be used effectively delete the main menu, press the EXIT button once more. according to the environment in which you are viewing the display.

  • Page 34: Setting The Color Temperature

    Setting the color temperature 4. Once the setting is completed... Use this procedure to set color tone produced by the plasma Press the EXIT button to return to the main menu. display. To delete the main menu, press the EXIT button once more.

  • Page 35: Adjusting The Color To The Desired Quality

    Adjusting the color to the desired quality 4. Press the PROCEED button. Use this procedure to adjust the white balance for bright The “WHITE BALANCE” screen appears. pictures and dark pictures to achieve the desired color 5. Use the L and M buttons to select “RED-GAIN”. quality.

  • Page 36: Reducting Noise In The Picture

    Reducing noise in the picture 4. Once the setting is completed ... Use these settings if the picture has noise due to poor Press the EXIT button to return to the main menu. reception or when playing video tapes on which the picture To delete the main menu, press the EXIT button once quality is poor.

  • Page 37: Sound Settings Menu

    Sound Settings Menu To continue adjusting the sound ... Repeat from step 2. Adjusting the treble, bass and left/right 4. Once the adjustment is completed ... balance Press the EXIT button to return to the main menu. To The treble, bass and left/right balance can be adjusted to delete the main menu, press the EXIT button once more.

  • Page 38: Screen Settings Menu

    Screen Settings Menu 3. Adjust using the buttons. Adjusting the Position, Size, Fine Picture, Picture Adj The position of the image can be adjusted and flickering of the image can be corrected. Example: Adjusting the vertical position in the normal mode Press the PROCEED button on the remote control unit to display the MAIN MENU on the screen, then...

  • Page 39: Picture Adj

    Function Settings Menu Information Setting the on-screen display Adjusting the Auto Picture When using the monitor for presentations, etc., the monitor ON ....The Picture ADJ and Fine Picture can be set so that the input source, screen mode, etc., do adjustments are made automatically.

  • Page 40: Adjusting The Position Of The Menu Display

    Adjusting the position of the menu display 3. To adjust the position... Use these operations to adjust the position of the menus Adjust using the buttons. that appear on the screen. F U N C T I O N Example: Adjusting the position of the menu display OSM ADJ.

  • Page 41: Setting The Power Management For Computer Images

    Setting the power management for computer images Information This energy-saving (power management) function Power management function automatically reduces the monitor’s power consumption if no operation is performed for a certain amount of time. * The power management function automatically reduces the monitor’s power consumption if the computer’s Example: Turning the power management function on keyboard or mouse is not operated for a certain amount...

  • Page 42: Power/Standby Indicator

    POWER/STANDBY indicator Power management POWER/STANDBY Power management Description Turning the picture back on mode indicator operating status Horizontal and vertical synchronizing Picture already on. Green Not activated. signals are present from the computer. No horizontal synchronizing signals Operate the keyboard or mouse. The Standby Orange Activated.

  • Page 43: Setting The Gray Level For The Sides Of The Screen

    Setting the picture to suit the movie Setting the gray level for the sides of the screen Use this procedure to set the gray level for the parts on the The film image is automatically discriminated and screen on which nothing is displayed when the screen is projected in an image mode suited to the picture.

  • Page 44: Setting Rgb3 Adj

    Setting RGB3 ADJ. Reducing burn-in of the screen When the picture input from the RGB3 input terminal is The brightness of the screen, the position of the picture, distorted, select the most appropriate setting from among and positive/negative mode are adjusted to reduce burn- “1”, “2”, and “3”.

  • Page 45: Resetting To The Default Values

    Resetting to the default values Information Use these operations to restore all the picture adjustments, audio settings, to the factory default values. Refer to page E-18 for items to be reset. AUTO ....The brightness of the screen is adjusted automatically to suit the Press the PROCEED button on the remote control unit to picture quality.

  • Page 46: Option Settings Menu

    Option Settings Menu Setting the BNC connectors Select whether to set the input of the 5 BNC connectors to RGB or component. Setting the allocation of the audio connectors Setting the AUDIO 1, 2, and 3 connectors to the desired Example: Set the BNC SELECT mode to “COMP.”...

  • Page 47: Setting A Computer Image To The Correct Rgb

    Setting a computer image to the correct RGB Information select screen BNC SELECT With the computer image, select the RGB Select mode for a moving image such as (video) mode, wide mode or RGB ....Uses the 5BNC terminal for RGB digital broadcast.

  • Page 48: Setting High Definition Images To The Suitable Screen Size

    Setting high definition images to the suitable Information screen size RGB SELECT modes Use this procedure to set whether the number of vertical lines of the input high definition image is 1035 or 1080. One of these 6 modes must be selected in order to display the following signals correctly.

  • Page 49: Setting The Picture Size For Rgb Input Signals

    Setting the picture size for RGB input signals Information Menu Use this procedure to switch the setting to “ON” or “OFF”. Checking the frequencies, polarities of input Example: Setting the “ON” mode to “OFF” signals, and resolution Use this function to check the frequencies and polarities Press the PROCEED button on the remote control unit to of the signals currently being input from a computer, etc.

  • Page 50: Setting The Language For The Menus

    Setting the language for the menus Setting the video signal format The menu display can be set to one of seven languages: Use these operations to set the video signal format. Japanese, English, German, French, Swedish, Italian or Spanish. Example: Setting the video signal format to “3.58 NTSC”...
  • Page 51 4. Once the setting is completed ... Press the EXIT button to return to the main menu. To delete the main menu, press the EXIT button once more. The color system is set to “3.58 NTSC”. Information Video signal formats Different countries use different formats for video signals.

  • Page 52: External Control

    External Control Application Communication Parameters (1) Communication system Asynchronous These specifications cover the communications control of the plasma monitor by external equipment. (2) Interface RS-232C (3) Baud rate 9600 bps Connections (4) Data length 8 bits (5) Parity Connections are made as described below. (6) Stop bit 1 bit External equipment...

  • Page 53: Communication Format

    Communication Format Check Sum Example Command 1 Unit ID 1 Unit ID 2 Command 2 Data Length Data Check Sum 8 bit 8 bit 8 bit 8 bit 8 bit 8 bit 8 bit 8 bit Command 1 Total 208H Unit ID 1 Unit ID 2 2) Error Processing...

  • Page 54: Command Reference List

    Command Reference List 03. Input Switch Change Function The external control equipment switches the input of the plasma monitor. CMD1 CMD2 LEN Transmission Data 01. Power ON DFH 80H DATA00 02. Power OFF 03. Input Switch Change DATA00 : Input Select 01H: Video1 04.

  • Page 55: Audio Mute On

    06. AUDIO Mute On 09. COLOR Gain Data Function Function The external control equipment switches on AUDIO Mute of the plasma monitor. The external control equipment changes the COLOR gain data of the plasma monitor. Transmission Data Transmission Data DFH 80H DATA00 DATA01 DATA02 CKS DATA00: USER PICTURE Gain Flag DATA01: COLOR Gain Flag...

  • Page 56: Sharpness Gain Data

    11. SHARPNESS Gain Data Function DATA00 DATA01 CKS The external control equipment changes the SHARPNESS gain data of the DATA00: USER PICTURE Gain Flag plasma monitor. DATA01: BRIGHT Gain Flag Transmission Data DFH 80H DATA00 DATA01 DATA02 CKS 14. Input MODE Request Function DATA00: USER PICTURE Gain Flag The display returns the current input information by the external control...

  • Page 57: Red Gain Data

    17. RED Gain Data 19. BLUE Gain Data Function Function The external control equipment changes the RED Gain Data of the plasma The external control equipment changes the BLUE Gain Data of the plasma monitor. monitor. Transmission Data Transmission Data DFH 80H DATA00 to DATA03 DFH 80H...

  • Page 58: Video Adj Request

    20. VIDEO ADJ Request DATA05: SHARPNESS Gain F0H: -16 Function FFH: -01 The display returns the video adjustments information by the external control equipment’ s request. 00H: 0 01H: +01 Transmission Data 10H: +16 0CH DATA00 to DATA0B CKS DATA06: CONTRAST Gain CCH: -52 DATA00: RED Gain(Bias) D8H: -40...

  • Page 59: Audio Select Set

    21. Audio Select Set 23. LONG LIFE Set Function Function The external control equipment sets combinations of audio and video inputs The external control equipment sets the PLE, ORBITER, and INVERSE (inverse for the plasma monitor. of image brightness) of the plasma monitor. Transmission Data Transmission Data DFH 80H...

  • Page 60: Table Of Signals Supported

    Table of Signals Supported Supported resolution • When the screen mode is NORMAL, each signal is converted to a 1024 dots 768 lines signal. (Except for * 2, 3, 4 • When the screen mode is TRUE, the picture is displayed in the original resolution. •...
  • Page 61 *1 Only when using a graphic accelerator board that is capable of displaying 852 480. *2 This signal is converted to a 1228 dots 768 lines signal. *3 The picture is displayed in the original resolution. *4 The aspect ratio is 5:4. This signal is converted to a 960 dot 768 line signal. *5 Normally the RGB select mode suite for the input signals is set automatically.

  • Page 62: Troubleshooting

    60 minutes. If the problem persists, contact your NEC dealer for service. *2 In the following case, power off the monitor immediately and contact your dealer or authorized NEC Center. The monitor turns off 5 seconds after powering on and then the POWER/STANDBY indicator blinks. It indicates that the power supply circuit or, one or more fans have been damaged.

  • Page 63: Specifications

    Specifications Product Name PlasmaSync 50MP1 Plasma Monitor Product Code PX- 50XM1G 1.89" 4.21" Screen Size 48.8" (1240) 43.5"(H) 24.5"(V) inches (48) (107) 1106(H) 622(V) mm diagonal 50" Aspect Ratio 43.5" (1106) 16 : 9 Resolution 1365(H) 768(V) pixels Pixel Pitch 0.032"(H) 0.032"(V) inches...
  • Page 64 TROUBLESHOOTING...
  • Page 65 TROUBLESHOOTING 1. Failure in the power supply In the case of any abnormality in the power supply like no power available, go to “1. No power available” (P. 2). 2. Video error (1) In the case of a video input error in VIDEO 1, 2, 3 (S-VIDEO), go to 2-1. “No video input signals available at VIDEO 1, 2, 3 (S-VIDEO)”...
  • Page 66 1. No power available Is the POWER LED Is the power cord plugged to Make correct connections lit normally? the wall outlet correctly? with the wall outlet. Is 100V AC on the output The POWER unit is out of fuses F1 and F2? order.
  • Page 67 (1) Flashing in green (Fan error detected) Does the fan run when the Is the power supply (7 to 12V) IC9802 or IC9802 and pe- main power circuit is turned available at Pin 1 of P0F1, ripheral circuits are out of P0F2? order.
  • Page 68 (2) Flashing in red (Temperature error detected) Is the potential 0V at Pin 10 Is 5V available at Pins 13 to IC9806 or IC9806 and of IC9806 (MAIN PWB)? 15 of IC9806? peripheral circuits are out of order. Are TH1 in the POWER unit Is 5V available at Pin PN3? Failure in the POWER unit and its peripheral circuits out...
  • Page 69 (4) Lit in green Can you hear the sound of Is the potential maintained at IC9501 and peripheral AC relay ON when the main the [H] level at Pin 79 of circuits are out of order. power circuit is turned ON? IC9501 (MAIN PWB)? Is the potential maintained at Pull out the PM connector...
  • Page 70 2. Video error 2-1. No video input signals available at VIDEO 1, 2, 3 (S-VIDEO) Are the RGB signals available Are the horizontal sync signals Failure in the MAIN PWB. at Pins 1, 3, and 5 of the P0YU available at Pins 7 and 5 of the Details described in Item connector? (See Figs.
  • Page 71 No pictures available only in the NTSC mode (ternary Y/C separation defective) Is a composite signal available Failure in Q5302 to Q5305. at Pin 88 of IC5313? (See Fig. 8.) Are the Y/C signals available Are the Y/C signals available Failure in IC5306 to IC5309.
  • Page 72 No pictures available only in PAL mode (3-line Y/C separation defective) Is a composite signal available Failure in Q5302 to Q5305. at Pin 3 of IC5303? (See Fig. 8.) Are the Y/C signals available Is 5V available at the power T5302 disconnected or fail- at TP5304/TP5305? pin of IC5303?
  • Page 73 2-2. No video input signals available at the RGB 1 and 2 input circuits Are the RGB signals available Are the RGB signals available Failure in IC5703, IC5705, at Pins 1, 3, and 5 of the POPC at TP5701 to TP5703? and IC5707.
  • Page 74 2-3. No video signals available at the DVD/HD input circuit Are the Y, Pb, and Pr signals Are the HV signals available Failure in the MAIN PWB. available at Pins 1, 3, and 5 of at Pins 7, 9, 10, and 12 of the Details described in Item the P0YU connector? P0YU connector?
  • Page 75 2-4. No video pictures available even with any input selection Apply an NTSC gray scale input to the VIDEO 1input circuit and select VIDEO Input1. Is the ON-screen display presented? Go to “Pictures and ON-screen display not available.” Are the signals of 3Vp-p applied to the signal input pins IC9403, IC9404, and peripheral circuits, (signal names: REV_LVDS, RODD_LVDS, etc.) of or the AD connectors are out of order.
  • Page 76 (1)-1 Is the video signal of 1Vp-p applied to The VCC+5V system, IC9501, and Pins 124, 133,and 139 of IC6501? peripheral circuits are out of order. 1Vp-p Is the video signal of 1Vp-p applied to The analog circuit of the MAIN PWB Pins 1, 2, and 3 of the YU connector? is out of order.
  • Page 77 2-5. No interlace motion pictures generated for VIDEO, DVD, HDTV, etc. Apply an NTSC gray scale input to the VIDEO 1 input circuit and select VIDEO Input 1. Are the signals of 3Vp-p applied to the signal input pins IC9403, IC9404, the AD connectors, and (signal names: REV_LVDS, RODD_LVDS, etc.) of peripheral circuits are out of order.
  • Page 78 2-6. No progressive motion pictures generated Apply a 525p gray scale input to the DVD1/HD1 input circuit and select DVD1/HD1. Are the signals of 3Vp-p applied to the signal input pins IC9403, IC9404, and peripheral circuits, (signal names: REV_LVDS, RODD_LVDS, etc.) of or the AD connectors are out of order.
  • Page 79 2-7. No still pictures of PC, etc. generated Apply an XGA 60Hz gray scale input to the PC1 input circuit and select PC1. Are the signals of 3Vp-p applied to the signal input pins IC9403, IC9404, and peripheral circuits, or (signal names: REV_LVDS, RODD_LVDS, etc.) of the AD connectors are out of order.

  • Page 80: Method Of Adjustments

    METHOD OF ADJUSTMENTS...
  • Page 81 METHOD OF ADJUSTMENTS Adjustments should be carried out in accordance with the procedures described below. 1. When the PDP module is replaced, adjust the sections according to the adjusting items 1 to 4 specified below. 2. When the power unit is replaced, adjust the sections according to the adjusting items 1 to 3 specified below. 3.
  • Page 82 2. Adjustment of +70V (1) Using any video signal of VIDEO input, DVD/HD input, or RGB input, and display a color bar signal. Turn on the power switch of the main unit. (2) Confirm that the voltage value between TP2 (+70V output) and TP4 (GND) of the power unit is maintained at “70 ±...
  • Page 83 4-2. Adjustment of the DVD/HD screen position Make correct adjustments of the display range with [MHPOS] and [MVPOS]. (1) Enter an input of HDTV monoscopic signal in the DVD/HD input terminal. According to the “convenient functional setting” in the [MENU] screen, press the cursor key [^] or [v] of the remote control to confirm that [HD SELECT] has been set at [1035i].
  • Page 84 <PWB Layout> 1. MAIN PWB (PPCB-5502) 100M LVDS LVDS SDRAM SCREEN SDRAM POST PANEL FLASH LINK AMDP2 3.3V 3.3V SDRAM (Y Pb Pr) (RGB) SELECTER SELECTER 9502 FILTER FILTER (FOR (FOR PC) HDTV) FILTER (FOR VIDEO) (FOR PC) (YPbPr)
  • Page 85 2. VIDEO PWB (PCB-5001)
  • Page 86 3. SUB PWB (PWC-4419) PWC-4419E SP PWB PWC-4419C PWR PWB...
  • Page 87 4. POWER unit layout D+170 D+170 D. GND D+70 D+5V D+70 D+5 ADJ < Signal Generator > Digital RGB and component signal generator • Equivalent to the Video Generator LT1615 (made by LEADER) • Equivalent to the Panel Adapter LT9217 (made by LEADER) •...
  • Page 88 <Signal Waveforms for Adjustments> 1. VIDEO input Input: Composite video input or S-terminal input for one system 2. DVD/HD/DTV input 2-1. HD: Y/Pb/Pr component input, tri-sync signal 100% color bar signal (mVp-p) 2-1. DVD: Y/B-Y/R-Y component input (HD/DVD in common) 700 (all white) color bar signal (mVp-p)
  • Page 89 3. RGB/PC input Horizontal sync period Video signal 0.7Vp-p Sync signal TTL level Positive/negative polarity (2) Vertical sync period Video signal 0.7Vp-p Sync signal TTL level Positive/negative polarity * The data a to j above are specified in the next page and thereafter, classified for various inspection signals.
  • Page 90 4. RGB/PC signal timing table PC mode Signal name VU-6010 VU-6010 PC98 PC98 NTSC PAL/SECAM 400@56Hz 400@70Hz 480@60HZ Definition 640*240 768*288 640*400 640*400 640*480 Dot clock frequency (MHz) 12.214 14.752 21.053 25.175 25.175 H frequency (kHz) 15.734 15.557 24.826 31.469 31.469 V frequency (Hz) 59.94...
  • Page 91 PC mode Signal name MAC@13” VESA VESA VESA XGA-2 480@72Hz 480@75Hz 480@85Hz 480@75HZ Definition 640*480 640*480 640*480 640*480 640*480 Dot clock frequency (MHz) 30.24 31.5 31.5 36.0 31.5 H frequency (kHz) 37.861 37.5 43.269 39.375 V frequency (Hz) 66.667 72.809 85.008 H total (uS) 28.571...
  • Page 92 PC mode Signal name VESA VESA VESA VESA VESA 600@56Hz 600@60Hz 600@72Hz 600@75Hz 600@85Hz Definition 800*600 800*600 800*600 800*600 800*600 Dot clock frequency (MHz) 49.5 56.25 H frequency (kHz) 35.156 37.879 48.077 46.875 53.674 V frequency (Hz) 56.25 60.317 72.188 85.061 H total (uS) 28.444...
  • Page 93 PC mode Signal name MAC@16” I/O dater CEREB VESA wide VESA wide wide wide 1 (NEC 1) (NEC 2) Definition 832*624 852*480 864*480 848*480 1024*576 Dot clock frequency (MHz) 57.2832 34.006 42.526 33.75 47.25 H frequency (kHz) 49.725 31.722 37.5 31.02...
  • Page 94 PC mode Signal name VESA wide VESA wide CEREB VESA VESA (NEC 3) (NEC 4) wide 2 768@60Hz 768@70Hz Definition 1280*720 1360*765 1024*600 1024*768 1024*768 Dot clock frequency (MHz) 76.5 85.5 51.2 H frequency (kHz) 45.106 47.712 37.879 48.363 56.476 V frequency (Hz) 60.142...
  • Page 95 PC mode Signal name VESA VESA MAC@19” VESA VESA 768@75Hz 768@85Hz 1024@60Hz 1024@75Hz Definition 1024*768 1024*768 1024*768 1280*1024 1280*1024 Dot clock frequency (MHz) 78.75 94.5 H frequency (kHz) 60.023 68.677 60.24 63.981 79.976 V frequency (Hz) 75.029 84.997 74.93 60.02 75.025 H total (uS) 16.66...
  • Page 96 PC mode Signal name IDC-3000G IDC-3000G HDTV-J DTV (480P) DTV (720P) PAL 625P NTSC 525P Definition 768*576 640*480 1920*1034 644*483 1280*720 Dot clock frequency (MHz) 29.687 24.39 74.25 24.37 74.25 H frequency (kHz) 31.389 31.47 33.75 31.469 45.000 V frequency (Hz) 59.9 60/60 59.94...
  • Page 97 PC mode Signal name HDTV-W SSPE JSPE MAC@12” Definition 1920*1080 1024*512 852*480 1152*870 Dot clock frequency (MHz) 74.25 H frequency (kHz) 33.75 33.727 15.75 68.681 V frequency (Hz) 60/60 60.012 59.94 75.062 H total (uS) 29.630 29.650 63.750 14.560 (dots) 2200 1186 1020...

  • Page 98: Circuit Description

    CIRCUIT DESCRIPTION...
  • Page 99 CIRCUIT DESCRIPTION (Note) In regard to the contents of the text, please refer also to the relevant circuit dia- grams. µ Power unit block [Including the power-related -COM (microcomputer) operation] • When a commercial power input is fed from an AC inlet, the power unit begins to generate an output of M+7V for the µ-COM system.
  • Page 100 VIDEO PWB Block 1. AUDIO block The AUDIO signal input entered from M1008 to M1010 is controlled and selected by I2C bus control of IC5001 (MM1311BD: SW). The selected AUDIO signal is output from the AB connector to the AUDIO AMP module via IC5002 (BA4558: buffer).
  • Page 101 4. VIDEO block The external VIDEO signal input is entered from M1001 to M1003, and selected at IC5001 (MM1311BD: SW). The composite signals of the IC5001 output are applied to the ternary Y/C separator circuit and the 3-line Y/C separator circuit. The Y/C signal input separated at each Y/C separator circuit is entered in IC5306 to 5309. At the same time, the composite signals are also entered in IC5306 to 5309 directly.
  • Page 102 C-VIDEO Signal Y FL5301 IC5313 FL5304 Q5320 Ternary Y/C 6MHz LPF 6MHz LPF ~5322 ; AMP separator circuit Q5302 ‘ Q5305 ; FL5305 Q5324 IC5312 6MHz LPF ~5326 ; AMP Memory Signal C (2) 3-line Y/C separation The VIDEO signal output of Q5018 is processed for band limitation at FL5301. It is then processed for the level and Characteristic F compensation at the AMP (Q5302 to Q5305) in the latter stage.
  • Page 103 (3) PAL/NTSC decoding After passing through the built-in delay line of IC5504, the Y signal is then output from Pin 4. This signal is applied to Pin 15 of IC5503 (CTI) and double-amplified there. The resultant output is then generated from Pin 2.
  • Page 104 (4) SECAM decoding When a color signal of SECAM is received, IC5510 (SECAM decoding) receives the control signal from Pin 3 of IC5504 (PAL/NTSC). Inside the IC5510 (SECAM decoding), the chroma signal input of Pin 24 is processed for band limitation at the bell filter and is then amplified at the limiter circuit.
  • Page 105 MAIN PWB Block 1. Video signal processor block In the MAIN PWB, each video signal selected at the VIDEO PWB is converted into a digital signal for the purpose of various signal processing such as enlargement, contraction, and so on. The processed signal output is sent to the plasma display module.
  • Page 106 (3) Flow of 480P, 720P (chrominance input), and 480P, 720P (RGB input) signals Converter 422→RGB "YU" 30MHz IC6501 IC7501 γ Process Parallel→ Change Size Select Enhance/NR On screen serial IC8502 IC9000 IC8003 IC9000 IC9403, 4 The chrominance (or RGB) signal input entered from the YU connector is converted into a digital signal at the AD converter, IC6501.
  • Page 107 When the RGB3 input is entered, the digital RGB signal input from the PL1 connector is of the serial data and it is converted into the parallel data at the panel link receiver, IC7002. (Processing of RGB x 8 bits x 2 phases = 48 lines) IC7501 sends out an output signal of IC7002 to IC8502.
  • Page 108 (8) AD converter (IC6501, IC6701) block IC6501 and IC6701 are the ICs intended for the conversion of analog RGB signals into 8-bit digital signals. (However, there are 48 output lines in total, each RGB color 8 bits x 2.) In addition to the functions of AD converter, this type of IC is also provided with the various functions of analog amplifier and PLL/VCO.
  • Page 109 (12) Definition conversion processing block (IC8502) Using the SDRAM (consisting of IC8503 and IC8504), IC8502 performs the conversion of the XGA signal to a level equivalent to VGA, the modification of the screen size for normal, full, etc., zoom operation, and the movement of the screen position.
  • Page 110 (3) Gate array block (Pre G/A IC7501) IC7501 is used as a timing controller intended to generate a variety of timing pulses based on the clock and horizontal sync signals from IC6701 (AD converter) and the vertical sync signal input entered from the YU connector and the PC connector (Pin 12).
  • Page 111 (2) Auto-picture function In IC7501, the screen position data are computed according to the input video signal when the auto-picture feature is turned ON for the RGB input. During the entry of RGB3 input, the screen position data are computed based on the DE signal sent from IC7002. The microcomputer picks up the screen position data from IC7501, and sets up the screen position in IC7501 and IC8502 based on the obtained data.
  • Page 112 (7) Control lock block When S2001 is turned on (pressed condition) inside the 232C PWB, Pin 19 of the microcomputer IC9501 is turned “H” and all keys other than the POWER key of the set main body are disabled. (8) PDP module control block With the PDP module, information about the screen position and input signals is controlled by the micro- computer through the bus SDATA, SCK, and LE.

  • Page 113: Method Of Disassembly

    METHOD OF DISASSEMBLY...
  • Page 114 ASSENBLY/DISASSEMBLY Disassembly shall be carried out in the reverse order of the assembly procedures described below. 1. Put the front panel M01 on an air cap or the like, with its rear side facing the front and with its top side facing downwards. In this case, the top side shall be positioned to face this side.
  • Page 115 6. Mount one each of the bracket filters M38 and M39 on the front panel M01, using the five screws SRW01 for each. SRW01 x 5 x 2 Mount the two bracket filters M40 on the right and left of the front panel, using the three screws SRW01 for each.
  • Page 116 11. Using the screws SRW38, tighten the bracket M25 and the round terminal CN [an earth wire used to connect the PDP module and the terminal panel VIDEO M59 (See P.14)] together on the PDP module P01. 12. Set the clamper M04 in the bracket hole and insert the round terminal in the clamper. 13.
  • Page 117 17. Put the frames M27 and M28 on the PDP module P01, and put the brackets M32 and M33 and the frames M34, M35, and M45 on them. Mount them, using 8, 9, 2, 4, and 2 screws SRW04, 05, 06, SRW07 x 4 07, and 08, respectively.
  • Page 118 19. Mount the bracket fans M36 and M37 by means of the four screws SRW11 and SRW12, respectively. SRW30 x 4 x 2 SRW29 x 2 x 2 20. Mount the two fans E01 by means of the two screws SRW29 each.
  • Page 119 21. Stick one each of the insulation seats M68 to the parts mounting sides of the SENS PWB A04 and the SENT PWB A05, respec- tively. A04,05 22. Stick two insulation seats to each of the two plates M48. Apply Hole A of the SENS PWB and also that of the SENT PWB to Hole A of the plate, and tighten them together by the use of the one screw SRW39, respectively.
  • Page 120 24. Mount the two bracket powers M41, using the three screws SRW10 on the right and the two on the left. 25. Mount the power unit A14 on the bracket power by the use of the six screws SRW09. SRW10 x 2 SRW10 x 3 M41 x 2 SRW09 x 6...
  • Page 121 26. Insert the PW cable CN-PW in the PWR PWB A10 and mount the button M07. 27. Put the cover M26 on the PWR PWB and fasten them together to the main body, using the two screws SRW28. CN-PW SRW28 x 2 28.
  • Page 122 29. Mount the audio AMP module A13 by means of the three screws SRW21 and the two screws SRW22. 30. Mount the mesh M47, using the four screws SRW37. SRW21 x 3 SRW22 x 2 SRW37 x 4...
  • Page 123 31. Stick the filament tape C (15 x 10mm) [P/N 92203967] to Corner B of the inlet mount- ing part A, just like the tape covers this portion. 32. Put the barrier M09 on the inlet ASSY E02, and mount it by means of the two screws SRW25.
  • Page 124 33. Mount the inlet cover M63 on the inlet ASSY, using the two screws SRW27. 34. Stick the gasket M20 to the inlet cover. SRW26 FL30,31 FL30,31 SRW27 x 2 FL32,34 FL32,34 SRW2 35. * For PX-50XM1 Attach one each of the ferrite cores FL30 and FL31 to the blue and brown cables of the inlet ASSY.
  • Page 125 37. Insert the LM cable CN-LM and the RM cable CN-RM in the SP PWB A12. CN-RM CN-LM 38. Using the two screws SRW23, mount the SP PWB on the terminal panel SP M61, with the lever A of the SP terminal facing upwards. In addition, mount the terminal panel SP on the main body by means of the two screws SRW24, and stick the two gaskets M21 to the terminal panel SP.
  • Page 126 41. Using the five screws SRW17, mount the VIDEO PWB A02 on the termi- nal panel VIDEO M59. In addition, use the two screws SRW202 and fasten the D-SUB terminal block of the VIDEO PWB located on the side surface of the terminal SRW16 x 6 SRW17 x 5 panel VIDEO.
  • Page 127 48. Mount the terminal panel VIDEO M59 assembly by means of the six screws SRW03 and the two screws SRW10. (Caution) Tighten the round terminal CN (an earth wire used to SRW16 connect the PDP module and the terminal panel VIDEO) SRW10 x 2 by means of the screws SRW03.
  • Page 128 53. Insert various connectors in the locations specified below • CN-AD • CN-SW Module → MAIN PWB (AD) CTL PWB (SW) → MAIN PWB (SW) • Left fan cable • CN-LD Fan → MAIN PWB (F2) LED PWB (LD) → MAIN PWB (LD) •...
  • Page 129 54. Wire the connectors, mount the two types of ferrite cores, and bundle the wires by means T1 and T2 fixed to M05 PD and PH fixed FAN, PD, and T2 fixed of clampers, etc. PD and PH passed (Caution) T2 passed through FL36 Fan and PH fixed Fan and PD fixed to M05...
  • Page 130 55. Mount the shield cover M43 by the use of the eight screws SRW33. SRW33 x 8 SRW34 x 2 56. Mount the bracket option M42 by the use of the two screws SRW34. 57. Mount the two cover bottoms M29, using one each of the screws SRW30 on the right and left in two positions.
  • Page 131 59. Stick the four gaskets M13, five gaskets M14, one gasket M15, M14 L=200 M16 L=250 M13 L=50 four gaskets M16, and the one gasket M17 respectively to the back cover M58. M13 L=50 M14 L=200 M15 L=290 (Caution) L = Length, Unit = mm M14 L=200 M16 L=250 M14 L=200...
  • Page 132 60. Apply the terminal label B M57 to the screw hole A of the back SRW36 x 32 cover, and stick it. 61. Mount the back cover M58 on the main body, using the 32 screws SRW36. 62. Mount the stand A on the main body, using the six screws M69-1. (Caution) The stand A is an optional item.
  • Page 133 63. Stick the following labels to the back cover: (Caution) PX-50XM1 : 1 to 8 used. PX-50XM1A, G : 1 to 5 used, 6 to 8 not used. 1. Serial label M10 (Caution) Align the label to the edge of the ter- minal panel SP M61 and stick it with- out covering the screws.

  • Page 134: Packaging

    PACKAGING...

  • Page 147: Part List

    PART LIST...

  • Page 148: Parts List

    PARTS LIST Notes: 1. Parts orders must contain model name, parts number and parts name. 2. When you place an order for spare parts, please refer to the respective service manual and mention the right parts number on your P.O. sheets 3.
  • Page 149 MISCELLANEOUS ELECTRICAL PARTS *** CN-T1 CN 4P(T1) 300W,2468-26 7SB4W001 MAIN-SENS CN-T2 CN 4P(T2) 600,2468-26 73B424T2 SENS-SENT CN-YU CN 12P(YU) 150W,MIX 7SBBW001 MAIN-VIDEO FL11 FERRITE CORE ZCAT2032-930 61605059 FL12 FERRITE CORE ZCAT2032-930 61605059 FL20 FERRITE CORE 61605095 PD/PH FL21 FERRITE CORE 61605095 PD/PH FL22...
  • Page 150 *** MECHANISM PARTS *** SRW34 TP-M4*8*3KF 24N04591 BRACKET OPTION SRW35 PL-CPIMS*3*6*3KF 910E3036 BACK COVER SRW36 PL-CPIMS*4*12*15KF 910E4033 BACK COVER SRW37 TP-M4*8*3KF 24N04591 MESH SRW38 TP-M3*6*3KF 24N04581 BRACKET AD SRW39 TP-M4*8*3KF 24N04591 SENSOR PWB SRW40 TP-M4*8*3KF 24N04591 PLATE FRONT PANEL ASSY 29DS0082 CLAMPER,WIRE 12281301...
  • Page 151 *** MECHANISM PARTS *** BARRIER(VIDEO) 29J00211 SPACER(FILTER) 29J00241 FILTER 29KS0031 NAME PLATE(50XM1A) 29L00381 SPEAKER LABEL 29L00481 AC IN LABEL 29L00491 TERMINAL LABEL A – TO M59 29PS0131 TERMINAL LABEL B 29L00512 BACK COVER 29PS0122 TERMINAL PANEL(VIDEO) 29PS0132 TERMINAL PANEL(232C) 29PS0142 TERMINAL PANEL(SP) 29PS0201 SUPPLEMENT SHEET US(PDP)
  • Page 152 *** PRINTED & PACKING MATERIALS *** FL40 FERRITE CORE ZCAT2032-930 61605059 FL41 FERRITE CORE ZCAT2032-930 61605059 FL42 FERRITE CORE 61605095 FL43 UNUSED POWER CORD 70810782 PK01 STOPPER 24282431 PK02 BAG,POLYETHYLENE(150*370) 24813191 PK03 SILICA GEL 24C04621 PK04 JOINT 24CS0551 PK05 PROTECTION SHEET 24M14821 PK06 CUSHION OUT-T...
  • Page 153 PARTS LIST Notes: 1. Parts orders must contain model name, parts number and parts name. 2. When you place an order for spare parts, please refer to the respective service manual and mention the right parts number on your P.O. sheets 3.
  • Page 154 MISCELLANEOUS ELECTRICAL PARTS *** CN-T1 CN 4P(T1) 300W,2468-26 7SB4W001 MAIN-SENS CN-T2 CN 4P(T2) 600,2468-26 73B424T2 SENS-SENT CN-YU CN 12P(YU) 150W,MIX 7SBBW001 MAIN-VIDEO FL11 FERRITE CORE ZCAT2032-930 61605059 FL12 FERRITE CORE ZCAT2032-930 61605059 FL20 FERRITE CORE 61605095 PD/PH FL21 FERRITE CORE 61605095 PD/PH FL22...
  • Page 155 *** MECHANISM PARTS *** SRW34 TP-M4*8*3KF 24N04591 BRACKET OPTION SRW35 PL-CPIMS*3*6*3KF 910E3036 BACK COVER SRW36 PL-CPIMS*4*12*15KF 910E4033 BACK COVER SRW37 TP-M4*8*3KF 24N04591 MESH SRW38 TP-M3*6*3KF 24N04581 BRACKET AD SRW39 TP-M4*8*3KF 24N04591 SENSOR PWB SRW40 TP-M4*8*3KF 24N04591 PLATE FRONT PANEL ASSY 29DS0082 CLAMPER,WIRE 12281301...
  • Page 156 *** MECHANISM PARTS *** BARRIER(VIDEO) 29J00211 SPACER(FILTER) 29J00241 FILTER 29KS0031 NAME PLATE(50XM1A) 29L00391 SPEAKER LABEL 29L00481 AC IN LABEL 29L00491 TERMINAL LABEL A – TO M59 29PS0131 TERMINAL LABEL B 29L00512 BACK COVER 29PS0122 TERMINAL PANEL(VIDEO) 29PS0132 TERMINAL PANEL(232C) 29PS0142 TERMINAL PANEL(SP) 29PS0201 SUPPLEMENT SHEET US(PDP)
  • Page 157 *** PRINTED & PACKING MATERIALS *** FL40 FERRITE CORE ZCAT2032-930 61605059 FL41 FERRITE CORE ZCAT2032-930 61605059 FL42 FERRITE CORE 61605095 FL43 UNUSED POWER CORD 70800089 PK01 STOPPER 24282431 PK02 BAG,POLYETHYLENE(150*370) 24813191 PK03 SILICA GEL 24C04621 PK04 JOINT 24CS0551 PK05 PROTECTION SHEET 24M14821 PK06 CUSHION OUT-T...

  • Page 158: Connection Diagrams

    CONNECTION DIAGRAMS 10-1...

  • Page 159: Connection Diagram

    CONNECTION DIAGRAM HDSTP VSTP SENS SENT (PCB-5001D) (PCB-5001C) PC3HD SHIELD WIRE PDP MODULE 1 2 3 ... 39 40 41 PC3VD SHIELD WIRE 1 2 3 ... 39 40 41 SCL5 1 GND 22 GND SDA5 SCL4 2 RA- 23 RG- M+7V PC3HD A+5V...

  • Page 160: Block Diagrams

    BLOCK DIAGRAMS 11-1...

  • Page 161: Block Diagram

    BLOCK DIAGRAM VIDEO PWB VIDEO DECODER BLOCK VIDEO 3.58NTSC Y/C SEP FL5002 BUFFE BUFFE 6MHZ SYNC SEP UPD64082 VIDEO1 IN /AMP TA1229N TA8772AN TA8814 3DIMENSION Y/C BUFFER SECAM DEMO 1H DELAY SEPARATE VIDEO2 IN FL5003 (3.58NTSC) BUFFE BUFFE GAIN 6MHZ DL5001 R/AMP Y/C IN...
  • Page 162 MAIN PWB SDA/SCL System Controller CPU I/O expand IC9501 PWR PWB M62320 M+5V FAN*2 REG*2 CTL PWB CTL1/2 OUTPUT LEVEL LED PWB ON/OFF power supply LEDCTL1/2 To ADC SDA/SCL REMIN To/from To/from VIDEO PWB POWER I/O expand PSS/ALARM M62320 232C PWB E2P-ROM from MODULE REMIN2...

  • Page 163: Schematic Diagrams

    SCHEMATIC DIAGRAMS 12-1...

Table of Contents
