Summary of Contents for Kichler Lighting Botella

  • Page 1 By Ted Collmar at 8:37 am, Nov 23, 2010...
  • Page 2 1. SAFETY RULES 1. To reduce the risk of electric shock, insure 10. Do not use water or detergents when electricity has been turned off at the circuit cleaning the fan or fan blades. A dry dust breaker or fuse box before beginning. cloth or lightly dampened cloth will be suitable for most cleaning.

  • Page 3: Tools And Materials Required

    Botella 2. TOOLS AND MATERIALS REQUIRED Philips screw driver Blade screw driver 11 mm wrench Step ladder Wire cutters 3. PACKAGE CONTENTS Unpack your fan and check the contents. You should have the following items: Fan blades (5) Blade support plates (5) Canopy &...
  • Page 4 4. MOUNTING OPTIONS If there isn't an existing ETL listed mounting box, then read the following instructions. Disconnect the power by removing fuses or turning off circuit breakers. Secure the outlet box directly to the building structure. Use appropriate fasteners and Outlet box building materials.

  • Page 5: Hanging The Fan

    Botella 5. HANGING THE FAN RMEMEBER to turn off the power before you begin installation. This is necessary for your Ceiling mounting safety and also the proper programing of the bracket control system. Canopy To properly install your ceiling fan, follow the steps below.
  • Page 6 Step 7. Loosen the two set screws and Supply wires remove the hitch pin and retaining clip from Coupling the coupling on top of the motor assembly. Downrod (Fig. 9) Set screws Set screws Step 8. Carefully feed the electrical lead wires Hitch pin Retaining clip from the fan up through the downrod.

  • Page 7: Installation Of Safety Support

    Botella 6. INSTALLATION OF SAFETY SUPPORT (required for Canadian installation ONLY) A safety support cable is provided to help prevent the ceiling fan from falling, please Ceiling mounting install it as follows. Attach bracket safety cable Step 1. Attach the provided wood screw and...
  • Page 8 8. FINISHING THE INSTALLATION Step 1. Tuck all the connections neatly into the ceiling outlet box. Step 2. Slide the canopy up to the mounting Outlet box bracket and place one of the key hole slots over the mounting screw on the mounting Ceiling bracket.

  • Page 9: Installing The Light Plate

    Botella 10. INSTALLING THE LIGHT PLATE Step 1. Loosen the two screws on the mounting ring attached to the motor shaft and "remove" and save the third screw. (Fig. 16) Step 2. Place the key hole slots on the light plate over the two screws previously loosened on the mounting ring.
  • Page 10 12. INSTALLING THE LAMP AND GLASS SHADE Step 1. Install the 100 Watt DE - Type J halogen lamp (provided). (Fig. 18) Step 2. Raise the glass shade against the mounting plate and turn clockwise until snug, DO NOT OVERTIGHTEN. (Fig. 18) Mounting plate Lamp Glass shade...
  • Page 11 Botella 13. REMOVING THE DECORATIVE WIRE HOUSING COVER FOR CLEANING Once your ceiling fan is installed, you can remove the "Decorative Wire Housing Cover" for cleaning at any future date. Screws Step 1. Remove the screws holding the Decorative wire...

  • Page 12: Control System Set-Up

    14. CONTROL SYSTEM SET-UP Make sure the power is completely disconnected before you begin this procedure. SPECIAL NOTE: ® Your new Kichler Ceiling Fan is State of the Art and employs a High Efficiency DC (direct current) Motor with an advanced CoolTouch™ Remote Control System.
  • Page 13 Botella 2. Insert both batteries and make sure they are seated correctly in each recess with the Blue Light Positive + sign facing up. Replace the battery cover. (Figure 21) 3. Test the transmitter by pushing and releasing ANY button briefly. A Blue Light should illuminate under the 3-4 buttons.
  • Page 14 Speed Buttons 15. OPERATING INSTRUCTIONS: Figure 25 1. Buttons 1, 2, 3, 4, 5 and 6 are used to set the blade speed as follows: 1 = Low Speed 2 = Medium Low Speed 3 = Medium Speed 4 = Medium High Speed 5 = High Speed 6 = Extra High Speed Figure 26...
  • Page 15 Botella NOTE: Please remember you control system is an RF (Radio Frequency) control system. You may occasionally experience control problems because of other radio frequency interference, i.e. fan turns off, light turns off or won't turn on, speed changes, etc. If this should happen, just change the “Control...

  • Page 16: Installing The Cooltouch Control System Wall Plate

    ™ 16. INSTALLING THE COOLTOUCH Outlet box CONTROL SYSTEM WALL PLATE Switch Select a location to install your CoolTouch™ Control System Transmitter. You can replace Wall plate an existing wall switch, or install the transmitter on ANY flat surface. Option 1: Install the control system using an existing wall switch outlet box.

  • Page 17: Troubleshooting

    Botella 18. TROUBLESHOOTING Problem Solution Fan will not start. 1. Check circuit fuses or breakers. 2. Check all electrical connections to insure proper contact. CAUTION: Make sure the main power is OFF when checking any electrical connection. 3. Make sure the transmitter batteries are installed properly. Positive (+) side facing out.
