Installation Instructions

for Stacked Washers and Dryers
Inside.......................................
Dimensions........................................................................
Before You Start................................................................
Installation.........................................................................
Installer Checklist ...........................................
Date Purchased _____________________________
Model Number _____________________________
Serial Number _____________________________
Keep these instructions for future reference.
(If this machine changes ownership, this manual must accompany machine.)
www.speedqueen.com
3
4
4
Back Cover
Part No. 802714R4
March 2013

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 802714R4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Alliance Laundry Systems 802714R4

Summary of Contents for Alliance Laundry Systems 802714R4

  • Page 1: Installation Instructions

    Before You Start..............Installation................. Installer Checklist ........... Back Cover Date Purchased _____________________________ Model Number _____________________________ Serial Number _____________________________ Keep these instructions for future reference. (If this machine changes ownership, this manual must accompany machine.) Part No. 802714R4 March 2013 www.speedqueen.com...
  • Page 2 All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without the expressed written consent of the publisher. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802714R4...

  • Page 3: Electric Dryers

    (5.1 cm) (3.8 cm) GAS DRYERS SWD896N *With leveling legs turned into base. NOTE: Exhaust openings are 4 in. (10.2 cm) metal ducting. 3/8 in. NPT Gas Connection © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802714R4...

  • Page 4: Parts Included

    W299 reinforced, especially on a second floor or over a basement. Do not install the washer on carpeting, soft tile, a platform or other weakly supported structures. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802714R4...

  • Page 5: Step 2: Position And Level The Unit

    Place unit in position on a solid, sturdy and level floor. Installing the unit on any type of carpeting, soft tile, a platform or other weakly supported structures is not recommended. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802714R4...
  • Page 6 Legs and base could become damaged. Place rubber feet (supplied in accessories bag) on all four leveling legs. Refer to Figure 3. Verify that unit does not rock. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802714R4...

  • Page 7: Step 3: Connect Fill Hoses

    WARNING To prevent personal injury, avoid contact with inlet water temperatures higher than 125° Fahrenheit (51° Celsius) and hot surfaces. W748 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802714R4...
  • Page 8 W005I Water Supply Faucets WATER Risers (Air Cushions) MIXING VALVE Figure 7 SWD596N SWD596N Water Faucets Cold Water Connection Hot Water Connection Water Fill Hoses Figure 6 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802714R4...

  • Page 9: Step 4: Connect Drain Hose To Drain Receptacle

    NOTE: End of drain hose must not be below 24 in. receptacle during use. (61 cm). H023I Drain Hose Beaded Strap (tape if necessary) Fill Hoses Figure 9 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802714R4...

  • Page 10: Laundry Tub Installation

    For proper operation at altitudes above 3000 feet (915 m) the natural gas valve spud orifice size must be reduced to ensure complete combustion. Refer to Table 1. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802714R4...
  • Page 11 Shorter than 20 ft. (6.1 m) – Use 3/8 in. (9.5 mm) pipe Longer than 20 ft. (6.1 m) – Use 1/2 in. (12.7 mm) pipe 3/8 in. NPT Gas Connection Figure 11 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802714R4...

  • Page 12: Step 6: (Electric Dryer Only) Connect Electrical Plug

    • The power cord connection between wall receptacle and dryer terminal block IS NOT supplied with dryer. Type of power cord and gauge of wire must conform to local codes. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802714R4...

  • Page 13: Connecting Power Cord With Three-Wire Plug

    3. Use a strain relief and insert end of power cord through power supply hole. 2. Remove access cover from rear of dryer. D696I D695I Figure 14 Figure 13 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802714R4...

  • Page 14: Connecting Power Cord With Four-Wire Plug

    8. Reinstall access cover and screw. DRY2467N Figure 17 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802714R4...
  • Page 15 10. Reinstall access cover and screw. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802714R4...
  • Page 16 Blockage will decrease airflow through DON’T SWD449N the dryer, thus reducing the efficiency of the dryer. SWD449N Figure 21 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802714R4...

  • Page 17: Exhaust Direction

    NOTE: The maximum length of a 4 in. (10.2 cm) diameter flexible metal duct must not exceed 7.87 ft. (2.4 m), as required to meet UL2158, clause 7.3.2A. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802714R4...

  • Page 18: Step 8: Remove The Shock Sleeves And Shipping Brace

    For leveling purposes, the washer may be tilted a maximum of 6 inches (152.4 mm) in any direction. FLW2271N FLW2271N Figure 24 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802714R4...

  • Page 19: Step 9: Wipe Out Inside Of Washer Drum And Dryer Drum

    • Do not use an extension cord. • Do not operate both a washer and gas dryer on the same circuit. Use separately fused 15 amp circuits. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802714R4...
  • Page 20 Do not operate other appliances on the same circuit when this appliance is operating. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802714R4...
  • Page 21 W518 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802714R4...

  • Page 22: Step 12: Check Heat Source

    W213 IMPORTANT: If igniter does not light, make sure gas is turned on. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802714R4...
  • Page 23 4. Reinstall the lower front panel. D702I D702I Air Shutter Lockscrew Air Shutter Appliance Main Gas Valve 1/8 in. (3.1 mm) Pipe Plug (For checking manifold pressure) Figure 32 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802714R4...

  • Page 28: Installer Checklist

    • Check for Gas Leaks. • Recheck Steps 1-10. D434I CHECK CHECK Electric Only • Check • Connect Electrical Heat Source. Cords. D702I D702I CHECK CHECK D679IE0A D679IEOA © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
