SurroundVideo® Omni

Camera Alignment

Alignment of the individual cameras is critical to setup. The individual cameras when placed on the
Tech
circumference of the track must be in a counterclockwise sequence to create proper alignment when viewing
Tip
the camera.
Sensor 3
Sensor 4
Page | 9
support@arecontvision.com
Arecont Vision SurroundVideo
Sensor 4
Sensor 2
Counterclockwise
Sensor 3
Counterclockwise
Sensor 1
®
Omni Installation Manual
Sensor 1
Sensor 2
