1. Product Description

1.1 Introduction

Optical Network Terminal (ONT) model B-FOCuS O-4F2PW/O-4G2PW is an ITU-T G.984 compliant
device that receives voice, data, and video traffic in the form of optical signal from the service
provider's passive optical network (PON) and transmitted it to the desired format at residential or
business premises.
Upstream traffic is likewise transmitted to the PON network via the fiber optic cable. A single optical
fiber carries both upstream and downstream traffic.

1.2 Services

ONT B-FOCuS O-4F2PW/O-4G2PW is equipped with ITU-T G.984 compliant 2.5G Downstream and
1.25G Upstream GPON UPLINK interface, and the following service ports
Four 10/100 Base-T Ethernet ports for high speed internet access and IPTV/VOD services
Two POTS (VoIP) service ports for voice services
Integrated 802.11b/g/n wireless
ONT B-FOCuS O-4F2PW/O-4G2PW has built-in capability for remote management like supervision,
monitoring, and maintenance.

1.3 Features

The ONT incorporates the following features:
Single fiber GPON interface with 1244Mbit/s upstream and 2488Mbit/s downstream data rates
Advanced data features such as VLAN tag manipulation, classification, and filtering.
Traffic classification and QoS capability
5 REN per line
Multiple voice Codec
Rich set of LED indications for alarming and maintenance
Easy home network storage service

1.4 Specifications

ONT physical, electrical, optical, and environmental specifications and compliance information are
listed in the following tables.
1
Some customized models may only provide a subset of service interfaces mentioned in this manual, for example, only four 10/100
Base-T Ethernet ports are provided.
