Iii) Ntp - Eci Telecom ONT B-FOCuS O-4F2PW Hardware Installation Manual

iii) NTP

NTP management is used to setup the ONU time to be synchronized with network time server
Below is the description for the parameters:
Parameter
Enable NTP Server
Current Time
First Server Address
Second Server Address
Interval Time
Time Zone
After the configurations are done, click "Save" button to save it. Restart the device to make the modification to take
effects.
02-Oct-2011
Rev 0.1
B-FOCuS O-4F2PW/O-4G2PW Hardware Installation Manual
Description
Enable or Disable network time synchronization service
Display current system time
Select first NTP server address. When select "Customer Setting",
user should enter his own time server address.
Select second NTP server address. When select "Customer
Setting", user should enter his own time server address.
Input the timing synchronization cycle interval
Select the time zone the user is located in
ECI Telecom Ltd. Proprietary 30
