4.7 Application

In "Application" Page there are 3 second level selections. They are "Port Forwarding", "DDNS" and "NTP".
i)

Port Forwarding

In Port Forwarding page, one can do port forwarding configuration.
Port forwarding makes the server running on ONU LAN side with private addresses (like Web server, FTP server) can
be accessed by external users from WAN port.
Below is the description for the parameters:
Parameter
WAN Port
LAN port
LAN IP address
Enable port mapping
WAN Link List (Virtual Host)
Add Button
02-Oct-2011
Rev 0.1
B-FOCuS O-4F2PW/O-4G2PW Hardware Installation Manual
Description
Input WAN side port range used by port forwarding
Input LAN port used by port forwarding
Input LAN side IP address
Enable or Disable mapping between WAN port and LAN
port
Select which WAN link to use port forwarding setup
Create a new mapping rule using above port forwarding
setup
ECI Telecom Ltd. Proprietary 28
