Machine Overview

WL3 FIREWALL
The WL3 Firewall is available
in the following options:
a) Cold, Hot & Sparkling (Full Option)
b) Cold, Hot & Ambient
c) Cold & Ambient
d) Cold, Ambient & Sparkling
When reading this manual, note the differences
between the options and focus on the particular
sections that concern the unit installed.
COLD TANK
The cold tank is manufactured from 304 Stainless Steel which is noncorrosive
and inert. The temperature of the Cold Tank is controlled by a electro-mechanical
thermostat and is set to 5°C, this being ideal temperature for a cold drink. The
capacity of the cold tank is 4 liters and 2 liters depending on the model.
WL3 Technical Manual - Version 1, July 2014
4
SPARKLING COLD TANK
The sparkling tank is manufactured from 304 Stainless Steel which is noncorrosive.
The temperature of the sparkling tank is set to 5°C. The capacity of the tank is 1.8
liters.
HOT TANK
The hot water temperature is controlled by a Microprocessor and is set to 87°C for
standard and 93°C for extra hot.(Extra hot is only available on selected models) A
thermal cut out is fitted to the Hot Tank to prevent overheating. The tank is fed water
via a polyphosphate filter to increase the tank life and to reduce the risk of scale
build up. Setting the hot water temperature at 87°C also helps stop scale forming in
the hot tank, prolonging the 800Watt element and the Hot Tank. Please note that
the extra hot feature is not available on machines with sparkling water.
FILTERS
The filtration systems on the WL3 are designed to reduce dirt and sediment
particles from the water. Furthermore, the Activated Carbon process will remove a
whole range of contaminants e.g. chlorine and pesticides. It is important for the UV
sterilization system to be supplied with clean water in order to achieve maximum
efficiency. There are many kinds of different filter combinations available from
Waterlogic to suit local water conditions.
FIREWALL CHAMBER
The Firewall chamber incorporates the in-Faucet UV and is made of aluminium and
is highly reflective. The Chamber houses the UV lamp and quarts spiral as well as
the faucet.
WL3 Technical Manual - Version 1, July 2014
5 5
