Camera Operation Manual
1. General
The EL-2800M-GE2 and EL-2800C-GE2 are new cameras in JAI's Elite Series. They provide high
picture quality, such as high sensitivity and low noise, suitable for machine vision applications. The
EL-2800M-GE2 is a monochrome progressive scan CCD camera and the EL-2800C-GE2 is the
equivalent Bayer mosaic progressive scan CCD camera. Both are equipped with a 2/3 inch CCD
sensor offering 2.83 million pixels resolution and a 4:3 aspect ratio. They provide 54.6 frames per
second for continuous scanning with 1920 x 1440 full pixel resolution for both monochrome and raw
Bayer output.
8-bit, 10-bit, or 12-bit output can be selected for both monochrome and Bayer outputs. The
EL-2800C-GE2 is also capable of performing in-camera color interpolation to produce 24-bit (8-bit
per color) RGB output at 27.7fps in 2-port LAG. The EL-2800C-GE2 also provides YUV411, YUV422
or YUV444. The new cameras feature a GigEVision ver. 2.0 interface which supports the use of a
2-port configuration for a faster transfer rate. A full pixel readout, partial scan readout, or binning
mode (monochrome only) can be selected depending on the application.
EL-2800M-GE2 and EL-2800C-GE2 have various comprehensive functions needed for automated
optical inspection applications, such as solid state device inspection or material surface inspection.
They incorporate video processing functions such as a look-up table, shading compensation, and
blemish compensation in addition to fundamental functions such as trigger, exposure setting and
video level control.
As a common Elite Series feature, a new connector for lens control is employed. EL-2800M-GE2 and
EL-2800C-GE2 support P-iris and motor-driven lenses as standard lens control capabilities. Factory
options are available to configure this connector to support DC iris systems as well as provide a
video iris output signal, or to provide additional TTL IN and OUT lines.
The latest version of this manual can be downloaded from: www.jai.com
The latest version of the Camera Control Tool for the EL-2800M-GE2 and EL-2800C-GE2 can be
downloaded from: www.jai.com
For camera revision history, please contact your local JAI distributor.
2.
Camera composition
The standard camera composition is as follows.
Camera body
Sensor protection cap
Dear Customer (sheet) 1
The following optional accessories are available.
Tripod base
Power supply unit
EL-2800M-GE2 / EL-2800C-GE2
1
1
MP-42
PD-12 series
- 9 -
