JAI SP-5000M-CXP2 User Manual

Spark series 5m digital progressive scan monochrome and color camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Spark Series
User Manual
SP-5000M-CXP2
SP-5000C-CXP2
5M Digital Progressive Scan
Monochrome and Color Camera
Document Version: Ver.1.7
SP-5000-CXP2_Ver.1.7_Oct2014
1044E-1304

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SP-5000M-CXP2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for JAI SP-5000M-CXP2

Summary of Contents for JAI SP-5000M-CXP2

  • Page 1 Spark Series User Manual SP-5000M-CXP2 SP-5000C-CXP2 5M Digital Progressive Scan Monochrome and Color Camera Document Version: Ver.1.7 SP-5000-CXP2_Ver.1.7_Oct2014 1044E-1304...
  • Page 2 JAI Ltd., Japan and may only be used by the purchasers of the product. JAI Ltd., Japan makes no warranty for the use of its product and assumes no responsibility for any errors which may appear or for damages resulting from the use of the information contained herein.
  • Page 3 SP-5000M-CXP2 Supplement The following statement is related to the regulation on “ Measures for the Administration of the control of Pollution by Electronic Information Products “ , known as “ China RoHS “. The table shows contained Hazardous Substances in this camera.
  • Page 4 SP-5000C-CXP2 Supplement The following statement is related to the regulation on “ Measures for the Administration of the control of Pollution by Electronic Information Products “ , known as “ China RoHS “. The table shows contained Hazardous Substances in this camera. mark shows that the environment-friendly use period of contained Hazardous Substances is 15 years.

  • Page 5: Table Of Contents

    SP-5000M-CXP2 / SP-5000C-CXP2 - Contents - Introduction ..................- 6 - 1. General ..................- 7 - Camera composition ..............- 7 - Main features ................- 8 - Locations and functions ............... - 9 - Locations and functions ................- 9 - Rear panel ....................- 10 -...
  • Page 6 SP-5000M-CXP2 / SP-5000C-CXP2 Output timing ..................- 29 - 6.3.1 Horizontal timing ................- 29 - 6.3.1.1 Vertical Binning OFF ..............- 29 - 6.3.1.2 Vertical Binning ON ..............- 29 - 6.3.2 Vertical timing ................. - 30 - 6.3.2.1 Vertical Binning OFF ..............
  • Page 7 8.8.4 Associated GenICam register ..............- 62 - ALC ....................- 63 - 8.10 HDR (High Dynamic Range) (SP-5000M-CXP2 only) ...........- 65 - Camera setting ................. - 67 - Camera Control Tool ................- 67 - Camera Default settings ................- 67 - External appearance and dimensions .......... - 68 - Specifications ................

  • Page 8: Introduction

    In order to learn more about EMVA 1288, please visit http://www.emva.org Interface The SP-5000M-CXP2 and SP-5000C-CXP2 employ CoaXPress as an interface system. In order to connect the camera to a PC, it requires the use of a Frame Graber board and the appropriate coaxial cable(s).

  • Page 9: General

    As a common Spark Series feature, a new connector for lens control is employed. SP-5000M-CXP2 and SP-5000C-CXP2 support P-iris and motor-driven lenses as standard lens control capabilities.

  • Page 10: Main Features

     Various readout modes, including horizontal and vertical binning (SP-5000M-CXP2 only) and ROI (Region Of Interest) for faster frame rates  0 dB to +24 dB gain control for both SP-5000M-CXP2 and SP-5000C-CXP2  10 μs (1/100,000) to 8 seconds exposure control in 1 μs step ...

  • Page 11: Locations And Functions

    SP-5000M-CXP2 / SP-5000C-CXP2 Locations and functions Locations and functions  Lens mount C-mount (Note *1)  10-pin connector AUX Connector for lens control (Standard)  LED Indication for power and trigger input  12-pin connector DC and trigger input  LINK 1 LINK Status indication for CXP#1 ...

  • Page 12: Rear Panel

    SP-5000M-CXP2 / SP-5000C-CXP2 Rear panel The rear panel mounted LEDs provide the following information: POWER/TRIG Amber: Power connected – initiating  This light goes OFF after initiating. Steady green: Camera is operating in Continuous mode  Flashing green: The camera is receiving external triggering ...

  • Page 13: Input And Output

    CXP-6 6.250 (up to 68 m) In the SP-5000M-CXP2 and SP-5000C-CXP2, the maximum bit rate is 6.25 Gbps per one cable and the power supply is available on the CXP#1 connector only. For the details of the specifications, please refer to “JIIA-NTF-001-2010” published by Japan Industrial Imaging Association, http://www.jiia.org.
  • Page 14 Sensor 12bit ○ ○ ○ JAI recommends the following settings depending on applications. If the objective is to maximize the frame rate:  The sensor pixel format should be set to a smaller value. If picture quality is the first priority: ...

  • Page 15: The Relationship Between Sensor Bit, Pixel Clock And Output Format

    SP-5000M-CXP2 / SP-5000C-CXP2 5.1.3 The relationship between sensor bit, pixel clock and output format. In the SP-5000-CXP2, there are three sensor bit depths available as well as three pixel clocks,72MHz, 57.6 MHz and 48 MHz. The combination of these settings is directly related to which Link Configuration can be used.

  • Page 16: Connectors And Pin Assignment

    SP-5000M-CXP2 / SP-5000C-CXP2 Connectors and pin assignment 5.2.1 Digital Video Output (75Ω 1.0・2.3 DIN Receptacle) Type: CoaXPress Connector (ACX1785-ND Amphenol Connector or equivalent) CXP#1 PoCXP compliant CXP#2 Maximum Bit Rate per one coax: 6.25 Gbps Maximum Bit Rate per two coax: 12.5 Gbps Note: If one coaxial cable is used, CXP#1 must be used.

  • Page 17: Aux Standard Hirose 10-Pin Connector

    SP-5000M-CXP2 / SP-5000C-CXP2 5.2.3 AUX Standard Hirose 10-Pin connector 5.2.3.1 Figure and pin configuration Type : HIROSE 10-Pin Connector 3260-10S3(55) Fig.5 Hirose 10-pin connector Table – 5 Hirose 10P pin assignment (Standard) Name Note DRIVE IRIS+ Motorized Lens DRIVE FOCUS+...

  • Page 18: Aux Type 3 Hirose 10-Pin Connector (Factory Option)

    LVDS_IN1+ Line11 LVDS_IN1- Digital IN/OUT interface In the SP-5000M-CXP2 and SP-5000C-CXP2, the digital IN/OUT capability in the software control tool can assign the necessary signals needed for the system. 5.3.1 Line Selector In the Line Selector, the following input and output signals can be assigned.

  • Page 19: Line Source

    SP-5000M-CXP2 / SP-5000C-CXP2 5.3.2 Line Source Line source signal can be selected from the following table to connect it to the line item which is selected in the line selector. Table - 9 Line Source Line Source item Description Connect Low Level signal to line item selected in Line Selector, Default setting...

  • Page 20: Basic Block Diagram

    SP-5000M-CXP2 / SP-5000C-CXP2 5.3.7.1 Basic block diagram Sel Bit (5,0) Sel Bit (7) Soft Trigger Trigger 0 (Acquisition Start) LVAL IN Trigger 1 (Acquisition Stop) FVAL IN Trigger 2 (Frame Start) Exposure Active Trigger 3 (Transfer Start) Acquisition Trigger Wait...

  • Page 21: In And Out Matrix Table

    SP-5000M-CXP2 / SP-5000C-CXP2 5.3.7.2 IN and OUT matrix table The following table shows the input and output matrix table. Table – 10 GPIO IN and OUT matrix table Selector (Cross Trigger Pulse Generator Line Selector point switch output) Selector Selector...

  • Page 22: Associated Genicam Register

    SP-5000M-CXP2 / SP-5000C-CXP2 5.3.8 Associated GenIcam register GenICam Access Values Category Name Line1 - TTL Out 1 Line8 – TTL Out 2(Option) Line Line9 - TTL Out 3(Option) Digital I/O Control Selector Nand Gate 0 In1 Nand Gate 0 In2...
  • Page 23 SP-5000M-CXP2 / SP-5000C-CXP2 Table - 11 Pulse Generator default settings Display Name Value Clock Pre-scaler Pulse Generator Length Start Repeat Clear Clear Clear Clear Pulse Generator Point Point Count Source Inverter Activation Sync Selector Mode True Async Mode Pulse Generator 0...

  • Page 24: Pulse Generator Length

    SP-5000M-CXP2 / SP-5000C-CXP2 Pulse generator Clear source IN (Clear activation = Rising edge Pulse generator repeat count = N Clear SYNC mode (Pulse generator length x N) = Async) Pulse generator Pulse generator Pulse generator length length length Pulse generator...
  • Page 25 SP-5000M-CXP2 / SP-5000C-CXP2 (Example 1) Clear Activation = Rising Edge, Clear Sync Mode = Async Mode, Clear Inverter = False Pulse Generator Clear Source In Pulse Generator Output Clear ↓ Fig.8 Counter clear in Async mode (Example 2) Clear Activation = Rising Edge, Clear Sync Mode = Sync Mode,...

  • Page 26: Pulse Generator Clear Source

    SP-5000M-CXP2 / SP-5000C-CXP2 5.4.9 Pulse Generator Clear Source The following clear source can be selected as the pulse generator clear signal. Table - 13 Pulse generator clear source Pulse Generator Clear Source Description item Connect Low level signal to Clear Source for the selected pulse generator.

  • Page 27: Pulse Generator Inverter

    SP-5000M-CXP2 / SP-5000C-CXP2 5.4.10 Pulse Generator Inverter Clear Source Signal can be have polarity inverted. 5.4.11 Pulse Generator Setting Parameters Table - 14 Pulse Generator setting parameters Display Name Value Clock Pre-scaler 1 to 4096 Pulse Generator Clock (MHz) [Pixel Clock:57.6 MHz or 48 MHz]÷[Clock Pre-scaler]...

  • Page 28: Associated Genicam Register

    SP-5000M-CXP2 / SP-5000C-CXP2 5.4.12 Associated GenICam register GenICam Name Access Values Category Pre-scaler 1 to 4096 Pulse Generators Pulse Generator Selector PG0 to PG3 Pulse Generators Pulse Generator Length 0 to 1048575 Pulse Generators Pulse Generator Start 0 to 1048575...

  • Page 29: Sensor Layout, Output Format And Timing

    SP-5000M-CXP2 / SP-5000C-CXP2 Sensor layout, output format and timing Sensor layout CMOS sensors used in the SP-5000M-CXP2 and SP-5000C-CXP2 have the following tap and pixel layout. 6.1.1 Monochrome sensor 2560 Pixels Fig.10 Monochrome sensor layout 6.1.2 Bayer color sensor 2560 Pixels Pixel (0,0) Fig.11...

  • Page 30: Camera Output Format

    SP-5000M-CXP2 / SP-5000C-CXP2 6.2. Camera output format The following table shows the relation between camera output and sensor readout system. Camera output format Sensor readout system Reference figure 1X–1Y 1-tap readout 6.2.1 Note: The description of camera output format is based on GenICam SFNC Ver.1.5.1.

  • Page 31: Output Timing

    SP-5000M-CXP2 / SP-5000C-CXP2 Output timing 6.3.1 Horizontal timing Output format: 1X – 1Y 1 Clock: 13.889ns 6.3.1.1 Vertical Binning OFF LVAL DVAL ③ ② Video Exposure Active ① Link Configuration 1L (µs) ①　(clk) ②　(clk) ③　(clk) Dual CXP6 12.5 Gbps 2.29 Single CXP6 6.25 Gbps...

  • Page 32: Vertical Timing

    SP-5000M-CXP2 / SP-5000C-CXP2 6.3.2 Vertical timing Output format: 1X – 1Y, CXP-6_2 Trigger Mode: N, Exposure Mode: Timed 1L: 165 clocks, 1 clock: 13.889 ns 6.3.2.1 Vertical Binning OFF FVAL 2048L 47 ～48L(Min) DVAL Exposure 9 ～10L Video Exposure Active...

  • Page 33: Roi (Region Of Interest) Setting

    However, in the horizontal direction, the horizontal frequency is not changed if the width is decreased. In the SP-5000M-CXP2, the minimum width is “64” and minimum height is “1”. In the SP- 5000C-CXP2, the minimum width is “64” and minimum height is “2”.

  • Page 34: Operating Modes

    Allowed values range from 36290 Hz to 0.125 Hz for SP-5000M-CXP2, however if the value entered is less than the time required for the default frame rate, the setting is ignored and the default frame rate is used. For example, the minimum frame period for the smallest possible ROI (1 line) requires 36290 Hz, so any entry more than 36290 will always be ignored.
  • Page 35 SP-5000M-CXP2 / SP-5000C-CXP2 Normal * (HEIGHT + K + EX ) + EX µs) READOUT ( WAIT EXP_F Frame rate(fps) = 1/Roundup (1000000.0 * T READOUT * (HEIGHT + K + EX ) + EX + 0.00005 µs) READOUT (...

  • Page 36: Exposure Setting

    SP-5000M-CXP2 / SP-5000C-CXP2 EXP_B SP-5000M_CXP2 SP-5000C-CXP2 Sensor Pixel Format Width>2112 Width>1984 Width<=1984 Width>2112 Width>1984 Width<=1984 8bit 10bit 12bit Associated GenICam register GenICam Name Access Values Category Acquisition Frame Rate 0.125 to 211 Acquisition Control Acquisition Frame Rate Raw 4785 to 8000000 Acquisition Control 7.2.

  • Page 37: Exposure Time

    SP-5000M-CXP2 / SP-5000C-CXP2 Table37. The combination of Exposure Mode, Trigger Option and Trigger Mode Trigger Mode Exposure Mode Trigger Option Operation (Frame Start) Self-running operation Exposure control by Exposure Time is not possible Self-running operation Exposure control by Exposure Time is not possible...

  • Page 38: Exposure Auto

    SP-5000M-CXP2 / SP-5000C-CXP2 7.2.3 Exposure Auto This is a function to control the exposure automatically. It is effective only for Timed. JAI ALC Reference controls the brightness. There are three modes, OFF, Once and Continuous. OFF: No exposure control Once:...

  • Page 39: Trigger Overlap

    SP-5000M-CXP2 / SP-5000C-CXP2 Table – 16 Trigger activation for each trigger mode RisingEdge FallingEdge LevelHigh LevelLow Timed ○ ○ × × TriggerWidth × × ○ ○ Timed - PIV ○ ○ × × Timed - RCT ○ ○ × ×...

  • Page 40: Normal Continuous Operation (Timed Exposure Mode/Trigger Mode Off)

    SP-5000M-CXP2 / SP-5000C-CXP2 7.4. Normal continuous operation (Timed Exposure Mode/Trigger Mode OFF) This is used for applications which do not require triggering. In this mode, the video signal for the auto-iris lens is available if AUX connector is configured with option Type 2.

  • Page 41: If The Overlap Setting Is "Readout

    SP-5000M-CXP2 / SP-5000C-CXP2 7.5.2 If the overlap setting is “Readout” Trigger CMOS Exposure Exposure Active Exposure Period FVAL 12.2 us 8L to 9L Fig.21 Readout - 39 -...

  • Page 42: Trigger Width Mode

    SP-5000M-CXP2 / SP-5000C-CXP2 7.6. Trigger width mode In this mode, the exposure time is equal to the trigger pulse width. Accordingly, longer exposure times are supported. Additional settings determine if the trigger pulse can be accepted during the exposure period.

  • Page 43: If The Overlap Setting Is "Readout

    SP-5000M-CXP2 / SP-5000C-CXP2 7.6.2 If the overlap setting is “Readout” Trigger CMOS Exposure Exposure Active Exposure Period FVAL 10 µs + 2.7 µs(Min) 12.2 µs 7.5L ～8.5L 8.8 µs Fig.23 Readout Note: In this mode, Exposure Active signal is -2.7µs against the external trigger signal. Therefore, the external trigger signal should be +2.7µs against the required Exposure Active signal.

  • Page 44: Rct Mode

    SP-5000M-CXP2 / SP-5000C-CXP2 7.7. RCT mode Until the trigger is input, the camera operates continuously and the video signal for the auto-iris lens is output provided the AUX connector has been ordered with a Type 2 configuration option. At this moment, the video signal, FVAL and LVAL are output but DVAL is not output. When the trigger is input, the fast dump is activated to read out the electronic charge very quickly, after which the accumulation and the readout are performed.

  • Page 45: Piv (Particle Image Velocimetry)

    SP-5000M-CXP2 / SP-5000C-CXP2 7.8. PIV (Particle Image Velocimetry) The Particle Image Velocimetry mode can be used in applications where 2 images need to be taken with a very short time interval. It can only be used with strobe flash as illumination.

  • Page 46: Sequence Mode

    SP-5000M-CXP2 / SP-5000C-CXP2 7.9. Sequence Mode This mode allows the user to define a preset sequence of up to 10 images, each with its own ROI, exposure time and gain values. In this mode, auto functions such as AGC, ASC, AIC and AWB are not available.
  • Page 47 SP-5000M-CXP2 / SP-5000C-CXP2 7.9.3 Sequence ROI setting parameters 7.9.3.1 Sequence index table (Default) The following table shows the default settings. Table – 17 Sequence Index table (Default) Sequence ROI Offset Gain Selector Binning Exposure Black Frame Next Width Height Gain...
  • Page 48 In Sequence ROI Gain Selector, the gain settings for each index are available. SP-5000C-CXP2: Gain (ALL), Red and Blue can be set. SP-5000M-CXP2: Only Gain is displayed and can be set. (7) Sequence ROI Black Level Black Level setting is available for each index.

  • Page 49: Video Send Mode

    SP-5000M-CXP2 / SP-5000C-CXP2 7.9.4 Associated GenICam register GenICam Name Access Values Category Normal Video Send Mode Trigger Sequence JAI-Custom Selector Command Sequence Multi ROI Sequence ROI Index 0 to 9 JAI-Custom Sequence Repetition 0 to 255 JAI-Custom Sequence Frame 0 to 255...

  • Page 50: Multi Roi Function

    SP-5000M-CXP2 / SP-5000C-CXP2 7.10 Multi ROI function This function divides one frame image into a maximum of 8 images vertically and reads out all areas in one frame. In this function, width is the same for all 8 images. The multi ROI function is enabled if [Video Sending Mode] is set to “Multi ROI”.
  • Page 51 SP-5000M-CXP2 / SP-5000C-CXP2 ROI setting explanation if Multi ROI Index Max is set to 4 Index 4 Offset X Index 2 Offset X Index 1 Offset X Index 3 Offset X Index 1 Offset Y Index 1 Height Index 2...

  • Page 52: Associated Genicam Register

    × ○ × × × × Timed (PIV) × × × × × × × Note 1. Only SP-5000M-CXP2 Note 2: Only SP-5000C-CXP2 Note 3: If the trigger interval is long, iris may exhibit a hunting phenomenon. - 50 -...

  • Page 53: Other Functions

    SP-5000M-CXP2 / SP-5000C-CXP2 Other functions Black level control This function adjusts the setup level. The adjusting level is -63 to +64LSB at 10-bit output. 8.1.1 Black Level Selector The following factors can be set. SP-5000M-CXP2: DigitalAll SP-5000C-CXP2: DigitalAll/DigitalRed/ DigitalBlue 8.1.2 Black Level The black level can be set in the following range.

  • Page 54: Gain Selector

    The gain raw can be adjusted in the following range. SP-5000M-CXP2: DigitalAll：100～1600 SP-5000C-CXP2: DigitalAll：100～1600 Digital Red All/Digital Blue All：-45～379 8.2.4 Gain Auto This function automatically controls the gain level. This is controlled by the command JAI ALC Reference. There are three modes. - 52 -...

  • Page 55: Balance White Auto

    SP-5000M-CXP2 / SP-5000C-CXP2 OFF: Adjust manually. Once: Operate only one time when this command is set Continuous: Operate the auto gain continuously The following detailed settings are also available. ALC Speed: The rate of adjustment of GainAuto can be set (Common with ExposureAuto).

  • Page 56: Lut

    SP-5000M-CXP2 / SP-5000C-CXP2 Balance White Channel Area JAI-Custom Middle Left Balance White Channel Area JAI-Custom Left Balance White Channel Area Middle JAI-Custom Low Right Balance White Channel Area Middle JAI-Custom Low Middle Right Balance White Channel Area Middle JAI-Custom Low Middle Left...

  • Page 57: Lut Index

    SP-5000M-CXP2 / SP-5000C-CXP2 8.3.2 LUT Index This represents the “starting” or “input” pixel value to be modified by the Lookup Table. The SP-5000-CXP2 has a 256-point Lookup Table, meaning the index points are treated like an 8-bit image with 0 representing a full black pixel and 255 representing a full white pixel. The index points are automatically scaled to fit the internal pixel format of the camera.

  • Page 58: Gamma

    SP-5000M-CXP2 / SP-5000C-CXP2 8.4. Gamma This command is used to set gamma between gamma 0.45 and gamma 1.0 (OFF) in 16 steps. The gamma value is an approximate value. Fig. 32 Gamma compensation 8.4.1 Linear and Dark Compression SP-5000-CXP2 has a dark compression circuit to improve the signal-to-noise ratio in the dark portion of the image.
  • Page 59 SP-5000M-CXP2 / SP-5000C-CXP2 Adjustable range Less 30% Fig. 33 Flat shading correction concept drawing Color shading correction (For SP-5000C-CXP2 only): In this case, R channel and B channel are adjusted to match with G channel characteristics. The block grid for compensation is 20 blocks (H) x 16 blocks (V). Each block contains 128 x 128 pixels and the complementary process is applied to produce the compensation data with less error.

  • Page 60: Blemish Compensation

    8.6. Blemish compensation The SP-5000M-CXP2 and SP-5000C-CXP2 have a blemish compensation circuit. This function compensates blemishes on the CMOS sensor (typically pixels with extremely high response or extremely low response). This applies to both monochrome and color versions. Pixels that fulfill the...

  • Page 61: Bayer Color Interpolation (Only For Sp-5000C-Cxp2)

    Fig.37 Color interpolation concept drawing Lens control The SP-5000M-CXP2 and SP-5000C-CXP2 can be used with 4 different types of auto iris lenses, in addition to standard lenses with manual iris control. If an auto iris function is to be utilized, the lens type used must be selected in Lens Select.

  • Page 62: About P-Iris

    8.8.1 About P-Iris New Spark Series SP-5000M-CXP2 and SP-5000C-CXP2 come equipped with P-Iris control as part of the standard lens control function. The P-Iris system is a newly developed lens control method designed to control the iris more precisely. Especially for video cameras in surveillance applications utilizing megapixel CCD or CMOS imagers, it becomes a very important factor to control an iris in order to achieve the maximum camera performance.

  • Page 63: Motorized Lenses

    SP-5000M-CXP2 / SP-5000C-CXP2 8.8.3 Motorized lenses The SP-5000C-CXP2 and SP-5000C-CXP2 can use the 3-axis motorized lens control for zoom, focus and iris. The following functions are available via the motorized lens commands. 8.7.3.1 Iris Open: While this command is supplied, the iris will continue to open.

  • Page 64: Associated Genicam Register

    SP-5000M-CXP2 / SP-5000C-CXP2 8.8.4 Associated GenICam register GenICam Access Values Category Name None Lens Select PIris Lens JAI-Custom Motor Lens PIris Step Max 0 to 255 JAI-Custom PIris Position 0 to 73 JAI-Custom PIris Lens Select LM16JC5MM JAI-Custom F_OPEN F_14...

  • Page 65: Alc

    SP-5000M-CXP2 / SP-5000C-CXP2 In the SP-5000M-CXP2 and SP-5000C-CXP2, auto gain, auto shutter and auto iris functions can be combined to provide a wide ranging automatic exposure control from dark to bright or vice versa. The functions are applied in the sequence shown below and if one function is disabled, the linkage between the other two is maintained.
  • Page 66 SP-5000M-CXP2 / SP-5000C-CXP2 Associated GenICam regsiter GenICam Name Access Values Category Exposure Auto Continuous Acquisition Control Once Gain Auto Continuous Analog Control Once ALC Speed 1 to 8 JAI-Custom ALC Reference 1 to 100 JAI-Custom Exposure Auto Max 101 to 1000000...

  • Page 67: Hdr (High Dynamic Range) (Sp-5000M-Cxp2 Only)

    SP-5000M-CXP2 / SP-5000C-CXP2 8.10 HDR (High Dynamic Range) (SP-5000M-CXP2 only) HDR sensing mode can be set when HDR Mode is set to ON while Exposure Mode is Timed. The parameters to configure dynamic range are HDR_SLOPE Level 1, Level 2, Level 3 and Level 4.
  • Page 68 SP-5000M-CXP2 / SP-5000C-CXP2 Associated GenICam register GenICam Access Values Category Name Disable JAI-Custom Enable Enable HDR Slope 200% HDR Slope 400% JAI-Custom Slope HDR Slope 800% HDR Slope 1600% - 66 -...

  • Page 69: Camera Setting

    Camera setting Camera Control Tool In the SP-5000M-CXP2 and SP-5000C-CXP2, control of all camera functions is done by the JAI SDK and Control Tool software. All controllable camera functions are stored in an XML file inside of the camera. The JAI SDK and Control Tool software can be downloaded from www.jai.com.

  • Page 70: External Appearance And Dimensions

    SP-5000M-CXP2 / SP-5000C-CXP2 External appearance and dimensions Dimensions tolerance: ± 0.3mm Unit: mm Fig. 40 Outside dimensions - 68 -...

  • Page 71: Specifications

    SP-5000M-CXP2 / SP-5000C-CXP2 Specifications 11.1 Spectral response Fig. 41 Spectral response (SP-5000M-CXP2) Fig.42 Spectral response (SP-5000C-CXP2) (With IR Cut Filter) - 69 -...

  • Page 72: Specifications Table

    SP-5000M-CXP2 / SP-5000C-CXP2 11.2 Specifications table Specifications SP-5000M-CXP2 SP-5000C-CXP2 Scanning system Progressive scan, 1-tap Synchronization Internal CoaXPress (JIIA NIF-001-2010 CoaXPress Standard First Edition) Interface 6.25 Gbps, 2 links, Compliant with PoCXP Image sensor 1 inch Monochrome CMOS 1 inch Bayer color CMOS...
  • Page 73 SP-5000M-CXP2 / SP-5000C-CXP2 OFF, Continuous, Timed (EPS), Timed (PIV), Trigger Width, Timed (RCT) Trigger mode （w/ALC） Trigger option Trigger Overlap ON/OFF, Long time exposure Line4 (TTL in), Line7 (Trigger packet), NAND0, NAND1, SW, Pulse Generator (4), Trigger Input Signal User Output (4)
  • Page 74 SP-5000M-CXP2 / SP-5000C-CXP2 Storage Temp. / Humidity -45C to +70C/20% to 80 % (no-condensing) Regulation CE (EN61000-6-2 and EN61000-6-3), FCC part 15 class B, RoHS, WEEE Housing Dimensions 62 x 62 x 55.5 mm (W x H x D) (excluding protrusion)

  • Page 75: Appendix

    SP-5000M-CXP2 / SP-5000C-CXP2 Appendix 1. Precautions Personnel not trained in dealing with similar electronic devices should not service this camera. The camera contains components sensitive to electrostatic discharge. The handling of these devices should follow the requirements of electrostatic sensitive components.

  • Page 76: Exportation

    5. Exportation When exporting this product, please follow the export regulation of your own country. 6. References 1. This manual can and datasheet for SP-5000M-CXP2 / SP-5000C-CXP2 can be downloaded from www.jai.com 2. Camera control software can be downloaded from www.jai.com...

  • Page 77: Manual Change History

    SP-5000M-CXP2 / SP-5000C-CXP2 Manual change history Date Revision Changes Nov. 2013 New release Nov. 2013 Correct figures for HBlanking_cycle, t and t in the exp_B exp_F section 7.1.2. Add RGB8 frame rate in the specification table. Nov. 2013 Add the caution for non- uniformity of sensor performance Correct TYPO.

  • Page 78: User's Record

    Company and product names mentioned in this manual are trademarks or registered trademarks of their respective owners. JAI A-S cannot be held responsible for any technical or typographical errors and reserves the right to make changes to products and documentation without prior notification.
