Summary of Contents for Ironton 46127
- Page 1 18V LI-ION 1/2IN. IMPACT WRENCH OWNER’S MANUAL WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item# 46127...
-
Page 2: Intended Use
Thank you very much for choosing an Ironton product! For future reference, please complete the owner’s record below: Model: _______________ Purchase Date: _______________ Save the receipt, warranty and these instructions. It is important that you read the entire manual to become familiar with this product before you begin using it. -
Page 3: Important Safety Considerations
IMPORTANT SAFETY CONSIDERATIONS WARNING: Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool. - Page 4 e. Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations. f. Dress properly. Do not wear loose clothing or jewelry. Keep your hair, clothing and gloves away from moving parts.
- Page 5 8. Do not disassemble charger. Take it to an electrician or power tool repairer when service or repair is required. Incorrect reassembly may result in a risk of electric shock, electrocution or fire. 9. To reduce risk of electric shock, unplug the charger from the outlet before attempting any cleaning.
-
Page 6: Operation
OPERATION Battery Charging 1. Plug charging jack into charging cradle. Both 2. Slide cradle onto the battery. Only the red lights will illuminate when connected. light will be illuminated when properly connected and charging. Note: Once fully charged, both the red and green lights will illuminate. Installing and Removing Slide the battery into the impact wrench base Hold down the battery release buttons and slide... - Page 7 2. Observe which lights illuminate for a reading on your battery’s charge. Full Charge 50% Charge Low Charge INSTALLING A SOCKET CAUTION ! ALWAYS BE SURE THAT THE TOOL IS SWITCHED OFF BEFORE ATTACHING OR REMOVING A SOCKET. ALWAYS TAKE CARE TO USE THE CORRECT SIZE SOCKET FOR BOLTS AND NUTS.
-
Page 8: Variable Speed
TIGHTENING A NUT 1 Start the nut by hand, ensuring it is not cross threaded, then with the appropriate socket installed on the wrench, place it on the nut. 2. With the FORWARD/NEUTRAL/REVERSE switch-bar in the clockwise (FORWARD) running position, and holding the wrench firmly in BOTH HANDS, pull the trigger. 3. - Page 9 been activated. This can happen when the tool has been used for extended periods or worked hard with large drill bits or accessories. Place the battery on the charging cradle for 3-5 hours. It will need this time to cool down and for the protection circuits to be reset.
- Page 10 Part Name cross plate tapping screw head housing O-ring shaft sleeve gasket output shaft wrench assembly left housing left decorative cover transparent lampshade positive and negative push rod variable speed urgent stop switch insert frame 18V Li-ion battery right housing right decorative cover cross plate tapping screw cross plate tapping screw...
- Page 11 WARNING Some dust created by power sanding, sawing, grinding, drilling, and other construction activities contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are: • lead from lead-based paints, •...
