Electric Chainsaw Sharpener
SHARPENER
Owner's Manual
WARNING:
Read carefully and understand all ASSEMBLY AND OPERATION
INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety
precautions may result in serious personal injury.
Item #53369
SAVE THESE INSTRUCTIONS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 53369 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ironton 53369

Summary of Contents for Ironton 53369

  • Page 1 Electric Chainsaw Sharpener SHARPENER Owner’s Manual WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item #53369 SAVE THESE INSTRUCTIONS...
  • Page 2 ® Thank you very much for choosing an Ironton product! For future reference, please complete the owner’s record below: Serial Number/Lot Date Code: ________________________________ Purchase Date: ____________________________________________ Save the receipt, warranty, and this manual. It is important that you read the entire manual to become familiar with this product before you begin using it.

  • Page 3: Table Of Contents

    Table of Contents Intended Use ............................4 Technical Specifications ........................4 Important Safety Information ....................... 4 Specific Operation Warnings ....................... 6 Extension Cords ............................ 6 Assembly Instructions .......................... 7 Operating Instructions .......................... 8 Maintenance ............................10 Parts Diagram ............................12 Parts List ..............................

  • Page 4: Intended Use

    This Ironton sharpener is easy to operate. Sharpen your chain in just minutes. It cuts left and right teeth at precisely the same depth. The chain vise adjusts to all chain designs and pitches.
  • Page 5  Inspect the work area before each use. Keep work area clean, dry, free of clutter, and well-lit. Cluttered, wet, or dark work areas can result in injury. Using the sharpener in confined work areas may put you dangerously close to other cutting tools and rotating parts. ...

  • Page 6: Specific Operation Warnings

    Specific Operation Warnings ⚠WARNING  To prevent personal injury or death, read and understand owner’s manual before use.  Wear ANSI Z87.1 compliant safety goggles, hearing protection, a NIOSH compliant dust mask, and work gloves when operating the machine.  Do not use grinding wheels that have a Max RPM less than the marked RPM Rating on the tool.

  • Page 7: Assembly Instructions

    Cord Length Nameplate AMPS 100' 150' 18 AWG 16 AWG 16 AWG 14 AWG 6-10 18 AWG 16 AWG 14 AWG 12 AWG 10-12 16 AWG 16 AWG 14 AWG 12 AWG 12-16 14 AWG 12 AWG NOT RECOMMENDED  When using more than one extension cord to make up the total length, make sure each cord contains at least the minimum wire size required.

  • Page 8: Operating Instructions

    5. Replace the Grinder Lock Cap (#9). 6. Replace the Grinding Wheel Cover (#11). 7. Release the Lock Stop (#6) and lower the Top Housing (#4). 8. Never operate tool without the Grinding Wheel Cover in place. Operating Instructions ⚠WARNING ...
  • Page 9 Refer to the parts diagram and the following figures. Note: Raise the Top Housing (#4) while adjusting the chain. 1. Clean the chain before sharpening it. Wash it with a non-flammable solvent. Do not use gasoline to dry the chain. 2.

  • Page 10: Maintenance

    9. lf the chain has been repeatedly sharpened, the chain depth limiting gauges may need to be taken down with a flat file (not included) See figures 8 and 9. File down each gauge so that they are at a lower level than the cutting teeth. Sharpening 1.
  • Page 11  Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to bind and are easier to control. Keep handles dry, clean, and free from oil and grease.  Use only soap and a damp cloth to clean your sharpener. Many household cleaners are harmful to plastics and other insulation.

  • Page 12: Parts Diagram

    Parts Diagram Page 12 of 16...

  • Page 13: Parts List

    Parts List Part# Description Qty. Part# Description Qty. Screw Tension Spring Motor Cover Retaining Ring Power Cord Lower Knob Top Housing Screw Switch Plate Bolt Lock Stop Chain Saw Frame Grinding Wheel Base Square Neck Screw Grinding Wheel Sliding Guide Grinder Lock Cap Screw Screw...

  • Page 14: Replacement Parts

    Replacement Parts  For replacement parts and technical questions, please call Customer Service at 1-800-222-5381.  Not all product components are available for replacement. The illustrations provided are a convenient reference to the location and position of parts in the assembly sequence. ...

  • Page 15: Limited Warranty

    Northern Tool and Equipment Company, Inc. ("We'' or '"Us'') warrants to the original purchaser only ("You'' or “Your”) that the Ironton product purchased will be free from material defects in both materials and workmanship, normal wear and tear excepted, for a period of one year from date of purchase.
  • Page 16 Distributed by: Northern Tool & Equipment Company, Inc. Burnsville, Minnesota 55306 www.northerntool.com Made in China Page 16 of 16...
