Ironton 46694 Owner's Manual

Ironton 46694 Owner's Manual

Dual temp 9-piece heat gun kit
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
DUAL TEMP 9-PIECE HEAT GUN KIT
OWNER'S MANUAL
WARNING:
Read carefully and understand all ASSEMBLY AND OPERATION
INSTRUCTIONS before operating. Failure to follow the safety rules and other
basic safety precautions may result in serious personal injury.
Item#: 46694

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 46694 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ironton 46694

Summary of Contents for Ironton 46694

  • Page 1 DUAL TEMP 9-PIECE HEAT GUN KIT OWNER’S MANUAL WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item#: 46694...

  • Page 2: Intended Use

    Thank you very much for choosing an IRONTON product! For future reference, please complete the owner’s record below: Model: _______________ Purchase Date: _______________ Save the receipt, warranty and these instructions. It is important that you read the entire manual to become familiar with this product before you begin using it.

  • Page 3: Electrical Safety

    ELECTRICAL SAFETY Double insulated tools are equipped with a polarized plug (one blade is wider than the other). This plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician to install a polarized outlet.

  • Page 4: Tool Use And Care

    TOOL USE AND CARE Use clamps or other practical way to secure and support the workpiece to a stable platform. Holding the work by hand or against your body is unstable and may lead to loss of control. Do not force the tool. Use correct tool for your application. The correct tool will do the job better and safer at the rate for which it is designed.
  • Page 5 Inspect and know your work area. Check your work area for hidden spaces before applying heat (behind walls, ceilings, floors, soffits and other panels) that may contain flammable materials which may ignite when using the heat gun. It may not be readily apparent if these materials ignite and could result in serious personal injury and property damage.
  • Page 6 applied to homes prior to 1950 is likely to contain lead. Once deposited on surfaces, hand to mouth contact can result in the ingestion of lead. Exposure to even low levels of lead can cause irreversible brain and nervous system damage; young and unborn children are particularly vulnerable.

  • Page 7: Operation

    Properly dispose of paint scrapings. Following each work session put the paint chips, scrapings, and debris in a double plastic bag. Close it with tape or twist ties and dispose of properly. Remove protective clothing and work shoes in the work area to avoid transferring dust to other parts of the building.

  • Page 8: Typical Applications

    Plug the heat gun into a properly rated outlet. If using an accessory nozzle tip, install the desired accessory nozzle tip by sliding it onto the nose of the heat gun. Depress completely the upper or lower portion of the rocker switch to obtain the desired heat range.
  • Page 9 the heat gun. Use a scraper that best matches the work surface shape and width of the paint loosened by the heat gun’s path. Preheating the scraper as you are heating the painted surface will increase the speed of paint stripping. Do not burn or heat the paint for too long since this will make the paint more difficult to remove.
  • Page 10 trapped air to escape. Move the heat gun back and forth across the package until the shrink wrap has evenly shrunk. Loosening nuts and bolts Point the hot air flow onto the nut or bolt you want to loosen. The heat will cause metal to expand and the amount of heat exposure required to loosen the part will vary due to the type of metal and its thickness.
  • Page 11 CAUTION : Water pipes are often difficult to distinguish from gas pipes! Before attempting to defrost metal pipe with a heat gun, confirm the pipe is a water line and not a gas pipe. CAUTION : Copper pipes are joined with solder containing tin which melts at about 392°F. Exercise extreme caution when defrosting near pipe fittings that you don’t exceed solder’s melting point or a leak may result, possibly causing property damage.
  • Page 12 KNOWING YOUR HEAT GUN 1. Air Nozzle 2. Motor Housing 3. Trigger Switch 4. Hanger Wire Page of 14...
  • Page 13 DIAGRAM AND PARTS LIST Description Description Part # Part # 1，2，3，6，24 Screw Hanger Vibration-proof piece Plastic tube Plastic input ventilator Steel tube Capacitor Outlet ventilator Terminal block Six layer micanite Cord grip Heating element Power cord guard Inductance Power cord Single-phase rectifier Switch D.C.
  • Page 14 Two-Year Warranty This product is warranted free from defects in material and workmanship for 2 years after date of purchase. This limited warranty does not cover normal wear and tear or damage from neglect or accident. The original purchaser is covered by this warranty and it is not transferable.
