Map for configuring RF
numbers and virtual channels
The Cable TV Channels vs RF
Frequency (MHz) Map shows how
the RF channels are paired and
matched with RF frequency.
You will need to refer to this map
when configuring RF numbers and
virtual channels.
IMPORTANT NOTES
• RF numbers are applied in
pairs based on the frequency
map. For instance, if you
enter RF # "2," then RF #"3"
automatically populates.
• RF numbers "4" and "5" cannot
be paired together because of
a gap in the frequencies (MHz).
• The RF numbers are not always
paired in numerical sequence
(as with RF # 6, which pairs
with 95, and RF # 99 which
pairs with 14 and so on).
• ZV channels can be set directly
adjacent to any other well-
formed channel and will not
cause interference. No channel
spacing is required.

Cable TV Channels vs RF Frequency (MHz) Map

RF Ch. Band (MHz) RF Ch. Band (MHz)
2 54-60 27
3 60-66 28
4 66-72 29
5 76-82 30
6 82-88 31
95 90-96 32
96 96-102 33
97 102-108 34
98 108-114 35
99 114-120 36
14 120-126 37
15 126-132 38
16 132-138 39
17 138-144 40
18 144-150 41
19 150-156 42
20 156-162 43
21 162-168 44
22 168-174 45
7 174-180 46
8 180-186 47
9 186-192 48
10 192-198 49
11 198-204 50
12 204-210 51
13 210-216 52
23 216-222 53
24 222-228 54
25 228-234 55
26 234-240 56
The highlighted areas in the frequency map show the RF numbers that can be paired together but are not numerically sequential.
RF Ch. Band (MHz)
240-246 57 420-426
246-252 58 426-432
252-258 59 432-438
258-264 60 438-444
264-270 61 444-450
270-276 62 450-456
276-282 63 456-462
282-288 64 462-468
288-294 65 468-474
294-300 66 474-480
300-306 67 480-486
306-312 68 486-492
312-318 69 492-498
318-324 70 498-504
324-330 71 504-510
330-336 72 510-516
336-342 73 516-522
342-348 74 522-528
348-354 75 528-534
354-360 76 534-540
360-366 77 540-546
366-372 78 546-552
372-378 79 552-558
378-384 80 558-564
384-390 81 564-570
390-396 82 570-576
396-402 83 576-582
402-408 84 582-588
408-414 85 588-594
414-420 86 594-600
H D bri dg e 28 40 C on f ig urat i on G u id e
RF Ch. Band (MHz) RF Ch. Band (MHz)
87 600-606 122 780-786
88 606-612 123 786-792
89 612-618 124 792-798
90 618-624 125 798-804
91 624-630 126 804-810
92 630-636 127 810-816
93 636-642 128 816-822
94 642-648 129 822-828
100 648-654 130 828-834
101 654-660 131 834-840
102 660-666 132 840-846
103 666-672 133 846-852
104 672-678 134 852-858
105 678-684 135 858-864
106 684-690
HRC Frequencies =
107 690-696
Standard
108 696-702
Frequencies
109 702-708
minus 1.25 MHz
110 708-714
Except for:
111 714-720
Channel 5,
Video = 78.0 MHz
112 720-726
Channel 6,
113 726-732
Video = 84.0 MHz
114 732-738
IRC Frequencies =
115 738-744
Same as Standard
116 744-750
Frequencies
117 750-756
Except for:
118 756-762 Channel 5, Video =
79.25 MHz
119 762-768
Channel 6, Video =
120 768-774
85.25 MHz
121 774-780
|
