Page 1: User Manual
Frame Series iSignager Frame Series User Manual IEI Technology Corp. MODEL: iSignager Frame Series 7”/8”/10.2”/15.6” Digital Signage Display with LAN, USB 2.0, VGA, Audio Output, IP 64 compliant Front Panel and Remote Control User Manual Page i Rev. 1.01 – 21 December, 2009... - Page 2 iSignager Frame Series Revision Date Version Changes 21 December, 2009 1.01 Modified power adapter information in Table 1-3. 20 October, 2009 1.00 Initial release Page ii...
- Page 3 iSignager Frame Series Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
-
Page 4: Table Of Contents
1.5.3 Rear View ......................5 1.6 P ....................6 HYSICAL IMENSIONS 1.6.1 General Physical Dimensions................6 1.6.2 iSignager-Frame-W07 Physical Dimensions............. 7 1.6.3 iSignager-Frame-08 Physical Dimensions ............8 1.6.4 iSignager-Frame-W10 Physical Dimensions............. 9 1.6.5 iSignager-Frame-W15 Physical Dimensions........... 10 ..............11 IGNAGER RAME... - Page 5 iSignager Frame Series A CHECK AND MODIFY THE PLAYER STATUS........... 28 A.1 C ..29 HECK AND ODIFY THE I IGNAGER RAME ERIES TATUS BY ERIAL A.1.1 Successful Message—LAN Connection ............36 A.1.2 Successful Message—Wifi Connection ............37 A.2 C ..................
- Page 6 Figure 1-1: iSignager Frame Series Front View................4 Figure 1-2: iSignager Frame Series Bottom Panel View.............5 Figure 1-3: iSignager-Frame-W10 Rear View ................5 Figure 1-4: iSignager-Frame-W07 Physical Dimensions (millimeters) ........7 Figure 1-5: iSignager-Frame-08 Physical Dimensions (millimeters).........8 Figure 1-6: iSignager-Frame-W10 Physical Dimensions (millimeters) ........9 Figure 1-7: iSignager-Frame-W15 Physical Dimensions (millimeters) ........10...
- Page 7 iSignager Frame Series List of Tables Table 1-1: iSignager Frame Series Model Variations..............3 Table 1-2: General Physical Dimensions ..................6 Table 1-3: iSignager Frame Series Specifications ..............11 Table 1-4: iSignager Frame Series Supported Formats ............13 Page vii...
-
Page 9: Introduction
iSignager Frame Series Chapter Introduction Page 1... -
Page 10: Important Notice
1.3 iSignager Frame Series Model Variations Eight IEI iSignager Frame Series models are available. The models are listed in Table 1-1. Model Resolution Network Second Display iSignager-Frame-W07 7” wide screen 800 x 480 iSignager-Frame-08 8” 800 x 600 iSignager-Frame-W10 10.2” wide screen... -
Page 11: Features
iSignager Frame Series iSignager-Frame-W07WL 7” wide screen 800 x 480 LAN + Wifi iSignager-Frame-08WL 8” 800 x 600 LAN + Wifi iSignager-Frame-W10WL 10.2” wide screen 1024 x 600 LAN + Wifi iSignager-Frame-W15WL 15.6” wide screen 1366 x 768 LAN + Wifi Table 1-1: iSignager Frame Series Model Variations 1.4 Features Some of the iSignager Frame Series features are listed below. -
Page 12: Bottom Panel
iSignager Frame Series Figure 1-1: iSignager Frame Series Front View 1.5.2 Bottom Panel All peripheral device connectors are located on the bottom panel of the iSignager Frame Series. The following is a list of the bottom panel peripheral device connectors used on the iSignager Frame Series. -
Page 13: Rear View
iSignager Frame Series VGA connector: Connects to VGA connector of the second display device. Figure 1-2 shows the bottom panel of the iSignager Frame Series digital signage display. Figure 1-2: iSignager Frame Series Bottom Panel View 1.5.3 Rear View The rear panel features fan ventilation holes and four retention screw holes that support a VESA FDMI (MIS-D 75 or MIS-D 100) wall-mounting bracket, a stand or an arm. -
Page 14: Physical Dimensions
The following sections describe the physical dimensions for the iSignager Frame Series. 1.6.1 General Physical Dimensions General physical dimensions for the iSignager Frame Series are shown in Table 1-2. Width Height Depth Model (mm) (mm) (mm) iSignager-Frame-W07 226.00 140.00 40.18 iSignager-Frame-08 234.00 177.00 43.00 iSignager-Frame-W10 279.79 185.39... -
Page 15: Isignager-Frame-W07 Physical Dimensions
Frame Series 1.6.2 iSignager-Frame-W07 Physical Dimensions The physical dimensions of the iSignager-Frame-W07 are shown in Figure 1-4. Figure 1-4: iSignager-Frame-W07 Physical Dimensions (millimeters) Page 7... -
Page 16: Isignager-Frame-08 Physical Dimensions
iSignager Frame Series 1.6.3 iSignager-Frame-08 Physical Dimensions The physical dimensions of the iSignager-Frame-08 are shown in Figure 1-5. Figure 1-5: iSignager-Frame-08 Physical Dimensions (millimeters) Page 8... -
Page 17: Isignager-Frame-W10 Physical Dimensions
iSignager Frame Series 1.6.4 iSignager-Frame-W10 Physical Dimensions The physical dimensions of the iSignager-Frame-W10 are shown in Figure 1-6. Figure 1-6: iSignager-Frame-W10 Physical Dimensions (millimeters) Page 9... -
Page 18: Isignager-Frame-W15 Physical Dimensions
iSignager Frame Series 1.6.5 iSignager-Frame-W15 Physical Dimensions The physical dimensions of the iSignager-Frame-W15 are shown in Figure 1-7. Figure 1-7: iSignager-Frame-W15 Physical Dimensions (millimeters) Page 10... -
Page 19: Isignager Frame Series Specifications
iSignager Frame Series 1.7 iSignager Frame Series Specifications Table 1-3 shows the iSignager Frame Series specifications. iSignager-Frame -W07 -W10 -W15 LCD Size 7" wide screen 8" 10.2" wide screen 15.6” wide screen Max. Resolution 800 x 480 800 x 600 1024 x 600 1366 x 768 Brightness (cd/m2) -
Page 20: Packing List
iSignager Frame Series 1.8 Packing List The iSignager Frame Series is shipped with the following components. Should there be any missing parts or defects in the package, please contact IEI immediately. Quantity Item Image iSignager Frame Series AC power adaptor Power cord 2GB SD card SD slot key... -
Page 21: Software - Isignager Adexpress For Frame
iSignager Frame Series 1.9 Software - iSignager AdExpress for Frame The iSignager AdExpress for Frame is the software the user can use to design display contents for the iSignager Frame Series. The iSignager AdExpress for Frame is come with the iSignager Frame Series. Please install the iSignager AdExpress for Frame in a PC. For more information please refer to iSignager AdExpress for Frame user manual. -
Page 22: Installation
iSignager Frame Series Chapter Installation Page 14... -
Page 23: Hardware Installation
iSignager Frame Series 2.1 Hardware Installation 2.1.1 iSignager Frame Series Set-Up To set up the iSignager Frame Series (the player), follow the steps below: Step 1: Connect the player to the power adapter and connect the power adapter to the power source. -
Page 24: Figure 2-2: Insert Sd Card
iSignager Frame Series Figure 2-2: Insert SD Card NOTE: To remove the SD card, just push the card in again. When the card pops up, remove it from the system. Step 4: Replace the SD slot cover and lock it with the key. Figure 2-3: Lock the SD Slot Cover Page 16... -
Page 25: Vga Connection For Dual Displays
iSignager Frame Series Step 5: To transfer player settings or sequences to the player via the network, connect the iSignager Frame Series to the same LAN of the PC via an Ethernet cable (optional step).Step 0: 2.1.2 VGA Connection for Dual Displays The iSignager Frame Series supports dual display via the VGA connector on the bottom panel. -
Page 26: Mounting The Isignager Frame Series
iSignager Frame Series 2.2 Mounting the iSignager Frame Series The iSignager Frame Series can be mounted on a wall, stand or arm. The mounting methods are described below. CAUTION: When mounting the iSignager Frame Series take care to tighten the retention screws or bolts until fully secure, but do not over tighten. -
Page 27: Figure 2-6: Hook Onto Wall Mounting Kit
iSignager Frame Series Step 2: Screw the mounting screws to the mounting holes on the rear of the iSignager Frame Series. Step 3: Hook the iSignager Frame Series into the mounting holes on the wall mounting kit. Figure 2-6: Hook Onto Wall Mounting Kit Page 19... -
Page 28: Stand Installation
iSignager Frame Series Step 4: Tighten the top screw on the wall mounting kit to securely hold the iSignager Frame Series in place. After this screw is tightened, the iSignager Frame Series should not be able to move. S t e p 0 : Figure 2-7: Tighten Retention Screw 2.2.2 Stand Installation The iSignager Frame Series has Video Electronics Standards Association (VESA) -
Page 29: Arm Mounting
iSignager Frame Series Step 2: Secure the iSignager Frame Series to the stand with the supplied retention screws.Step 0: 2.2.3 Arm Mounting The iSignager Frame Series is VESA (Video Electronics Standards Association) compliant and can be mounted on a VESA arm. To mount the iSignager Frame Series on an arm, please follow the steps below. -
Page 30: Panel Mounting
iSignager Frame Series Figure 2-8: Arm Mounting Retention Screw Holes Step 4: Secure the iSignager Frame Series to the interface pad by inserting four retention screws through the bottom of the mounting arm interface pad and into the iSignager Frame Series. Step 0: 2.2.4 Panel Mounting To mount the iSignager Frame Series into a panel, please follow the steps below. -
Page 31: Figure 2-9: Isignager-Frame-W07 Panel Opening
Frame Series Figure 2-9: iSignager-Frame-W07 Panel Opening Figure 2-10: iSignager-Frame-08 Panel Opening Figure 2-11: iSignager-Frame-W10 Panel Opening Page 23... -
Page 32: Figure 2-12: Isignager-Frame-W15 Panel Opening
Insert the panel mounting clamps into the pre-formed holes along the edges of the chassis, behind the aluminum frame. The number of panel mounting clamps fro each model are listed below: iSignager-Frame-W07: 4 clamps iSignager-Frame-08: 4 clamps iSignager-Frame-W10: 6 clamps... -
Page 33: Figure 2-13: Tighten The Panel Mounting Clamp Screws (Isignager-Frame-W10)
iSignager Frame Series Figure 2-13: Tighten the Panel Mounting Clamp Screws (iSignager-Frame-W10) Page 25... -
Page 34: Remote Control
iSignager Frame Series 2.3 Remote Control WARNING: To enable the remote control function, please press the OK button on the controller. Then, press other function keys within three seconds after pressing OK, otherwise, the system will lock the remote control function again. - Page 35 iSignager Frame Series OK. Press this button to enable the remote control function and to save the sleep time and wake-up time settings. Sleep Time. Press this button to set the sleep time of the system. Use the up and down buttons to adjust the time value. After setting the sleep time, please make sure to set the wake-up time.
-
Page 36: A Check And Modify The Player Status
iSignager Frame Series Appendix Check and Modify the Player Status Page 28... -
Page 37: Check And Modify The Isignager Frame Series Status By Serial Port
iSignager Frame Series A.1 Check and Modify the iSignager Frame Series Status by Serial Port Follow the following steps and command to check and modify the iSignager Frame Series status by RS-232 serial port. ® ® Step 1: In Windows XP/ Windows 2000 OS, create a HyperTerminal session and prepare a null modem cable to connect the PC and the iSignager Frame Series. - Page 38 iSignager Frame Series Step 3: Connect RS-232 cable to COM1 of the iSignager Frame Series: vick[/]# run vick[/]# cd /bin Step 4: Display Playerinfo function: vick[/bin]# ./playerinfo BINFMT_FLAT: Loading file: ./playerinfo Usage: ./playerinfo -i: To display all information ./playerinfo -sh hostname: To change PC host name ./playerinfo -ch hostname: To change client host name ./playerinfo -ddev <val>: To change device type ./playerinfo -si ip: To change PC IP...
- Page 39 iSignager Frame Series ./playerinfo -pstop: To stop playlist ./playerinfo -pstart: To start playlist ./playerinfo -cstart: To restart client ./playerinfo -time <val>: To change time : To display wireless info ./playerinfo -wal : To reboot system ./playerinfo -reboot Step 5: Examples: Example 1.1 Use command playerinfo-i and show the information of the player is connected via LAN: Glob1[/]# playerinfo -i...
- Page 40 iSignager Frame Series Dhcp : disable Display Device : VGA 1360x768 60 Apps Version : 200 WIFI : BINFMT_FLAT: Loading file: /new/part1/bin/playerinfo Client ra0 Ip : 192.168.10.3 Access Point : 00:13:46:87:EA:02 Encryption key : 132-3334-3536-3738-3930-6162-63 ESSID : "iei_sw2" vick[/]# Example 2. Set iDSServer hostname to client system vick[/bin]# ./playerinfo -sh RD-VICKWU-NB BINFMT_FLAT: Loading file: ./playerinfo Changing server hostname...
- Page 41 iSignager Frame Series Changing server IP Done Example 6. Set client IP to client system vick[/bin]# ./playerinfo -ci 10.10.10.74 BINFMT_FLAT: Loading file: ./playerinfo Changing client IP 10.10.10.74 eth0: link up, 100Mbps, full-duplex, lpa 0x45E1 vick[/bin]# interface < eth0 > is up and running ================================================== the systems IP address is :10.10.10.74 connecting to windows server....
- Page 42 iSignager Frame Series Example 7. Set DHCP action vick[/bin]# ./playerinfo -d 1 BINFMT_FLAT: Loading file: ./playerinfo Changing dhcp.txt Done Example 8. Stop playing vick[/bin]# ./playerinfo -pstop BINFMT_FLAT: Loading file: ./playerinfo killall: pictureplayer: no process killed killall: play0: no process killed killall: play1: no process killed killall: play2: no process killed munmap of non-mmaped memory by process 1811 (play_animate): 17e02000...
- Page 43 iSignager Frame Series /new/playlist5.txt***********************Fading: disabled Alpha0: 255 Alpha1: 255 Running check iEi WCODE 1 0x05 0x02 iEi RCODE 1 0x05 0x02 Example 10. Restart client connect vick[/bin]# ./playerinfo -cstart BINFMT_FLAT: Loading file: ./playerinfo vick[/bin]# interface < eth0 > is up and running ================================================== the systems ip address is :10.10.10.74 connecting to windows server....
-
Page 44: Successful Message-Lan Connection
iSignager Frame Series BINFMT_FLAT: Loading file: ./playerinfo Setting the date Sat Jul 22 11:14:00 MDT 2006 Example 12. Reboot the player vick[/bin]# ./playerinfo -reboot Step 6: Use the following command to modify LAN settings: ifconfig eth0 IP : set client IP value ifconfig eth0 netmask : set client mask e.g. -
Page 45: Successful Message-Wifi Connection
iSignager Frame Series interface < eth0 > is up and running ================================================== the systems ip address is :192.168.1.10 connecting to windows server....windows server ip address is : 192.168.1.5 windows server hostname is : RD-VICKWU-NB error status-w: Contact iEi code=0x05 failed connection = Y CONNECTED TO WINDOWS SERVER! ==================================================... - Page 46 iSignager Frame Series WiFi IP { 10.10.88.100 } WiFi Encryption Enable { Y } WiFi Key type { open } WiFi cipher type { WEP } WiFi key index { 1 } WiFi Key Length { 128 } WiFi Key { 1234567890abc } WiFi Essid { iei_sw2 }...
-
Page 47: Checking Connection
iSignager Frame Series A.2 Checking Connection There are several ways to check if the connection exists between the iSignager Frame Series and PC. A.2.1 Check the LED Check the LEDs on the top of the LAN port in the bottom panel of the iSignager Frame Series. -
Page 48: Isignager Frame Wl Series Network Behavior
iSignager Frame Series A.3 iSignager Frame WL Series Network Behavior The user can setup LAN and Wifi settings in the iSignager Frame WL Series at the same time. However, the iSignager Frame WL Series takes LAN as the first priority by default when booting up.
