Installing and Wiring the Thermostat
Table 6
Table 6 Sensor Connectors
Sensor
S1+
S1-
S2+
S2-
S3+
S3-

Configuring Auxiliary Relay Jumpers

The Auxiliary Relays are powered from RC when the jumpers are installed.
shows how to configure the Auxiliary Relay jumpers. Auxiliary Relay 1 and 2 can be
configured independently from each other.
Figure 5 Auxiliary Relays with Jumpers
When the jumpers are removed (see
use an external power source.
Figure 6 Auxiliary Relays without Jumpers
10
Beta Draft Confidential
describes the sensor connectors.
Description
Port 1 Remote Sensor Positive
Port 1 Remote Sensor Negative
Port 2 Remote Sensor Positive
Port 2 Remote Sensor Negative
Port 3 Remote Sensor Positive
Port 3 Remote Sensor Negative
Proliphix Internet Managed Thermostat (IMT) Installation Guide, Release 1.0
Figure 6), the Auxiliary Relays are configured to
Part No. 600-03100-000, Rev. 2
Figure 5
