To wire the base plate terminals:
Use Table 2 on page 4
1
corresponding terminal letter on the Proliphix base plate.
Strip the wire insulation from the wire ends. Verify that the wire ends are straight. To
2
avoid damaging the labels, use caution when handling the wires and push any excess
wire back into the wall.
Using
3
to the terminal post with the corresponding letter on the IMT base plate. For example,
connect the wire labeled "W1" to the W1 terminal post.
Loosen the terminal post screw used to secure the wires. Insert the wire straight down
4
into the square hole and secure the corresponding screw to the wire.
To avoid damage to the Proliphix base plate, stop unscrewing the terminal post
screws when you feel a slight stop or resistance.
Caution
Verify that the wire is securely attached to the terminal post in the base plate by gently
5
tugging on the wire.

Configuring Remote Sensors

The Proliphix thermostats provide three remote (external) sensor ports. The IMT
supports Thermistor, 0-5v Analog, and 4-20mA Current Loop. (Go to
www.proliphix.com for a complete list of supported sensors.) You must configure the
two switches for each sensor to match the sensor category. See
on page
Figure 3
Figure 3 Remote Sensor Switch Settings - Base Plate Label
Proliphix Internet Managed Thermostat (IMT) Installation Guide, Release 1.0
Part No. 600-03100-000, Rev. 2
to match the letter of your existing thermostat wire to the
Figure 1 on page 5 or Figure 2 on page 6
8.
shows and example of the remote sensor switch settings.
Installing and Wiring the Thermostat
as a guide, connect the labeled wires
Figure 3 and Table 3
