Danfoss BW10 020-090 Operation Instructions Manual page 10

4.9.5 - INPUTS menu
NAME FORMAT
ONOFF_SW Open/Close
HC_SW Open/Close
on_ctrl Off, On Cool, On Heat, On Auto
SETP_SW1 Open/Close
SETP_SW2 Open/Close
LIM_SW1 Open/Close
LIM_SW2 Open/Close
FLOW_SW Open/Close
DIFF_SW Open/Close
4.9.6 - OUTPUTS menu
NAME FORMAT
CP_A1 On/Off
CP_A2 On/Off
CP_A3 On/Off
FAN_A 0-8
exv_a 0-100
HD_POS_A 0-100
RV_A On/Off
LLS_A On/Off
CP_B1 On/Off
CP_B2 On/Off
FAN_B 0-8
exv_b 0-100
HD_POS_B 0-100
RV_B On/Off
LLS_B On/Off
FAN_DRY 0-8
VFAN_DRY 0-100
3wv 0-100
EHS_STEP 0-4
ALARM On/Off
RUNNING On/Off
4.9.7 - PUMPSTAT menu
NAME FORMAT
CL_PUMP On/Off
CL_WPIN ±nnn.n
CL_WPOUT ±nnn.n
CL_WPCAL Yes/No
CL_OFFST ±nnn.n
CL_FILTR nnn.n
CL_WPMIN nnn.n
CL_WFLOW ±nnn.n
CL_wdtsp nn.n
CL_wdpsp nn.n
CL_DvPos Nnn
CL_drvpwr ±nnn.n
CL_drvpI ±nnn.n
CL_drvvs xxxxxxxx
CL_dvTyp Xxxxxxxx
CD_PUMP On/Off
CD_WPIN ±nnn.n
CD_WPOUT ±nnn.n
CD_WPCAL Yes/No
CD_OFFST ±nnn.n
CD_FILTR nnn.n
CD_WPMIN nnn.n
CD_WFLOW ±nnn.n
CD_wdtspt nn.n
CD_wdpspt nn.n
CD_DvPos Nnn
CD_drvpwr +nnn.n
CD_drvpl +nnn.n
CD_drvvs xxxxxxxx
CD_dvTyp Xxxxxxxx
10
UNIT
-
-
-
-
-
-
-
-
-
UNIT DESCRIPTION
- Compressor output A1
- Compressor output A2
- Compressor output A3
- Fan outputs, condenser A
% EXV position circuit A
% Position variable speed controller fan A
- Four-way refrigerant valve
- Liquid line solenoid valve A
- Compressor output B1
- Compressor output B2
- Fan outputs, condenser B
% EXV position circuit B
% Position variable fan speed controller B
- Four-way refrigerant valve
- Liquid line solenoid valve B
- Drycooler fan outputs
% Position drycooler variable speed fan
% Three-way valve position
- Electric heater stages
- Alarm relay
- Unit on relay
UNIT DESCRIPTION
- Evaporator pump control
kPa Evaporator entering water pressure sensor
kPa Evaporator leaving water pressure sensor
- Evaporator water pressure sensor calibration?.Following a water pressure sensor error, CL_OFFST is
deconfigured (-99 kPa) to inform of the need to calibrate the water loop. This calibration must be made
while there is no water flow in the machine
kPa Water pressure sensor calibration value
kPa Evaporator filter pressure drop
kPa Minimum evaporator water pressure
G/s Evaporator water flow rate
^C Evaporator temperature difference setpoint
kPa Evaporator pressure difference setpoint
% Evaporator pump speed setpoint
kW Evaporator pump power
A Evaporator pump current
- Evaporator pump speed variable speed controller version
- Evaporator pump variable speed controller type
- Control condenser pump
kPa Condenser entering water pressure sensor
kPa Condenser leaving water pressure sensor
- Condenser water pressure sensor calibration? Following a water pressure sensor error, CD_OFFST is
deconfigured (-99 kPa) to inform of the need to calibrate the water loop. This calibration must be made
while there is no water flow in the machine
kPa Condenser water pressure sensor calibration value
kPa Condenser filter pressure drop
kPa Minimum condenser water pressure
g/s Condenser water flow rate
^C Condenser temperature difference setpoint
kPa Condenser pressure difference setpoint
% Condenser pump speed setpoint
kW Condenser pump power
A Condenser pump current
- Condenser pump speed variable speed controller version
- Evaporator pump variable speed controller type
DESCRIPTION
Remote start/stop contact
Remote heating/cooling contact
Current control
Remote setpoint contact 1
Remote setpoint contact 2
Remote demand limit contact 1
Remote demand limit contact 2
Water flow rate/customer safety loop contact
Water flow rate contact 2 (30WG)
