\\MAINMENU\TEMP
EWT 12.0°C
LWT 7.0°C
OAT 35.0°C
CHWSTEMP -17.8°C
HTWSTEMP -17.8°C
Leaving Water Temperature
The Up and Down arrow keys position the cursor on the
current menu item. The Enter key activates the parameter
modification (if possible). Any non-pertinent modification
attempt is blocked by a refusal screen.

4.6 - Parameter modification

A configuration parameter can be modified by positioning the
cursor and then pressing the Enter key.
\\MAINMENU\SETPOINT
cps1 12.0°C
cps2 12.0°C
ice_sp 12.0°C
hps1 50.0°C
hps2 50.0°C
Cooling Setpoint 2
The following screen allows modification of a parameter.
Modify value
csp 2
12.0 °C
_ °C
Cooling Setpoint 2
The Up and Down arrow keys permit the selection of the first
digit. Pressing the Up key successively scrolls up to the
following symbols:
0, 1, 2, 3, 4, 5, 6, 7, 8, 9, ., -.
The Down key follows the reverse order of the Up key in
scrolling down the digit list above. Each digit is validated with
the Enter key.
The - sign is only accessible for the first selected character.
Modify value
csp 2
12.0 °C
11.5_ °C
Cooling Setpoint 2
The value is validated with the Enter key. At any time the
return key cancels the current modification.
Current path in the menu structure
List of items
Cursor position
Description of the item framed by the
selection cursor
Current path in the menu structure
List of items
Cursor position
Description of the item framed by the
selection cursor
Screen description
Current value
Cursor position
Item description
Description of the screen
Current value
New value before validation
Item description
ATTENTION: If the user exits from the current data screen, the
value is saved. A saving confirmation is displayed. The
Enter key validates the parameter modification(s). The
Return to the Previous Screen key cancels the current
modification(s).
\\MAINMENUSETPOINT
Save changes?

4.7 - Operating mode screen

The unit is in Local Off mode, pressing the on/off (0/1) key
once activates the display of the operating mode screen.
Select Machine Mode
Local On
Local Schedule
CCN
Remote
The Up and Down keys position the cursor on the selected
operating mode. Four modes are immediately displayed on the
screen. To access operating modes that are not visible, please
use the Up and Down keys.
When the operating mode has been selected, the new operating
mode can be validated with the Enter key.
Command accepted
When the unit is in an operating mode and the On/off key is
pressed, the unit will stop. A confirmation screen protects the
unit against inadvertent shutdowns.
PRESS ENTER
TO CONFIRM STOP
Current path in the menu structure
Confirmation that the modification is
saved
Description of the screen
List of the machine operating modes
Cursor
Operating mode validation screen
Machine shutdown confirmation
screen
