4.9.18 - BRODCAST menu
NAME FORMAT
ccnbroad 0/1/2
oatbusnm 0 to 239
oatlocad 0 to 239
dayl_sel Disable/Enable
Summer time
startmon 1 to 12
startdow 1 to 7
startwom 1 to 5
Winter time
stopmon 1 to 12
stoptdow 1 to 7
stopwom 1 to 5
4.9.19 - GENCONF menu
NAME FORMAT
lead_cir 0/1/2
seq_typ No/Yes
ramp_sel No/Yes
off_on_d 1 to 15
nh_limit 0 to 100
nh_start 00:00 to 24:00
nh_end 00:00 to 24:00
bas_menu 0 to 3
synoptic No/Yes
4.9.20 - PUMPCONF menu
NAME FORMAT
clpmpseq No/Yes
clpmpper No/Yes
clpmpsby No/Yes
clpmploc No/Yes
cdpmpseq No/Yes
cdpmpper No/Yes
cdpmpsby No/Yes
cdpmploc No/Yes
ol_pump No/Yes
4.9.21 - HCCONFIG menu
NAME FORMAT
auto_sel No/Yes
cr_sel 0 to 2
hr_sel 0 to 2
heat_th -20 to 0
boil_sel No/Yes
boil_th -15 to 15
ehs_sel 0 to 4
ehs_th -5 to 21.2
both_sel No/Yes
ehs_back No/Yes
ehs_pull 0 to 60
ehs_defr No/Yes
4.9.22 - HDC_CONF menu
NAME FORMAT
adpmpper Yes/No
summ_oat 15.0 to 30.0
Summer
summ_on 0 to 12
summ_off 0 to 12
shc_min 0 to 720
shc_max -1 to 720 *
dhw_min 0 to 720
dhw_max -1 to 720 *
* -1 means that the maximum value is ignored
DEFAULT UNIT
2 -
0 -
0 -
Disable -
3 -
7 -
5 -
10 -
7 -
5 -
DEFAULT UNIT
0 -
No -
No -
1 min
100 %
00:00 -
00:00 -
0 -
No -
DEFAULT UNIT
No -
No -
No -
Yes -
No -
No -
No -
Yes -
No
DEFAULT UNIT
No -
0 -
0 -
-15 °C
No -
-10 °C
0 -
5 °C
No -
No -
0 minutes
No -
DEFAULT UNIT
Yes -
20.0 °C
5 hours
5 hours
30 minutes
180 minutes
30 minutes
180 minutes
DESCRIPTION
Activates the broadcast
0 = deactivated, 1= broadast during holidays at the network, 2 =
broadcast during holidays, machine only
Broadcast of the outside temperature
Bus number of the machine with the outside temperature
Element number of the machine with the outside temperature
Activation summer time, winter time
Month
Day of the week (1 = Monday)
Week of the month
Month
Day of the week (1 = Monday)
Week of the month
DESCRIPTION
Circuit loading sequence
0 = auto, 1 = A first, 2 = B first
Loading sequence by circuit
Ramp loading sequence
Start-up delay
Capacity limitation in night mode
Night mode start hour
Night mode stop hour
Basic menu configuration
0 = total access
1 = access to the alarm menu by password
2 = access to the setpoint menu by password
3 = combination of 1 and 2
Synoptic diagram displayed
DESCRIPTION
Evaporator pump selection
Evaporator pump seizure protection
Pump shutdown when the unit is in standby
Flow rate verification when the pump has shut down
Condenser pump selection
Condenser pump seizure protection
Pump shutdown when the unit is in standby
Flow rate verification when the pump has shut down
Open-loop pump control selection
DESCRIPTION
Automatic changeover selection
Cooling reset selection
Heating reset selection
1 = outside temp., 0 = none, 2 = delta T
Outside temperature threshold cooling mode
Boiler control selection
Outside temperature threshold for the boiler
Selection, number of electric heater stages
Outside temperature threshold for electric heater stages
Heating or cooling command selection for HSM
1 backup electric heater stage
Delay before start-up of the first electric heater stage
Quick electric heat stages for defrost
DESCRIPTION
Additional pump anti-stick function
Outside air temperature threshold for the mode
Time before changeover to summer mode
Time before changeover to winter moder
Minimum duration in heating mode
Maximum duration in heating mode
Minimum duration in DHW mode
Maximum duration in DHW mode
