I Optional battery chargers
D Rapid charging with the BC-160
The optional BC-160 provides rapid charging of the Li-Ion battery
pack. Charging period: Approx. 3 hours (with BP-232N)
The following items are additionally required:
• An AC adapter (may be supplied depending on version) or the DC
power cable (OPC-515L/CP-17L) is additionally required.
Optional OPC-515L
(for 13.8 V power
source) or CP-17L
(for 12 V cigarette
lighter socket) can
be used instead of
the AC adapter.
AC adapter
(Not supplied with
some versions.)
IMPORTANT!:
Ensure the guide lobs
on the battery pack are
correctly aligned with
the guide rails inside
the charger adapter.
BATTERY CHARGING
Transceiver
Battery pack
Guide rail
5
Turn power OFF
Lobs
