Icom IC-F15 Instruction Manual page 30

5
BATTERY CHARGING
D Rapid charging with the BC-119N+AD-106
The optional BC-119N provides rapid charging of the Li-Ion battery
pack. Charging period: Approx. 3 hours (with BP-232N)
The following items are additionally required:
• An AD-106
• An AC adapter (may be supplied with BC-119N depending on version)
or the DC power cable (OPC-515L/CP-17L).
AC adapter
(Not supplied with
some versions.)
Optional OPC-515L
(for 13.8 V power
source) or CP-17L
(for 12 V cigarette
lighter socket) can
be used instead of
the AC adapter.
26
CHARGER ADAPTER
Battery pack
IMPORTANT!:
Ensure the guide
lobs on the battery
pack are correctly
aligned
guide rails inside
the charger adapter.
Transceiver
with the
Guide rails
Turn power OFF
AD-106 charger
adapter is instal-
led in BC-119N.
Lobs
