4228362-GB-Rev.A Parts and Maintenance Manual ™ HR-9016 Turbo Rotary Mower 70538 – Kubota V3800DICR-T-E3B, 4WD ì 70539 – Kubota V3800DICR-T-E3B, 4WD with ROPS 70540 – Kubota V3800DICR-T-E3B, 4WD EC with ROPS 70541 – Kubota V3800DICR-T-E3B, 4WD EC ì ì - These units must have a certified ROPS/cab installed by the Dealer before the mower can be put into service and registered for warranty coverage.
Suggested Stocking Guide To Keep your Equipment fully operational and productive, Jacobsen suggests you maintain a stock of the more commonly used maintenance items. We have included part numbers for additional support materials and training aids. To order any of the following material: 3.
Only use accessories and attachments 20. Operate the machine up and down the face of slopes approved by Jacobsen. (vertically), not across the face (horizontally). Stay alert for holes in the terrain and other hidden 21.
Adjustments and maintenance should always be performed by a qualified technician. If additional information or service is needed, contact your Authorized Jacobsen Dealer who is kept informed of the latest methods to service this equipment and can provide prompt and efficient service.
Contact your area Jacobsen Dealer for a complete listing of accessories and attachments. CAUTION Use of other than Jacobsen authorized parts and accessories may cause personal injury or damage to the equipment. Orange Touch-up Paint (12 oz. spray) ....4184140 Work Light Kit (Requires 5003564)......78155...
Producentens firmanavn og fulde adresse Bedrijfsnaam en volledig adres van de fabrikant Tootja ärinimi ja täielik aadress Valmistajan toiminimi ja täydellinen osoite Nom commercial et adresse complète du fabricant Firmenname und vollständige Adresse des Herstellers Jacobsen, A Textron Company A gyártó üzleti neve és teljes címe Ragione sociale e indirizzo completo del fabbricante 11524 Wilmar Blvd.
Page 9
Místo a datum prohláení Sted og dato for erklæringen Plaats en datum van de verklaring Deklaratsiooni väljastamise koht ja kuupäev Vakuutuksen paikka ja päivämäärä Lieu et date de la déclaration Jacobsen, A Textron Company Ort und Datum der Erklärung A nyilatkozat kelte (hely és id ) Luogo e data della dichiarazione 11524 Wilmar Blvd.
ADJUSTMENTS ADJUSTMENTS GENERAL________________________________________________________________ adjustment cannot be made, contact an authorized Jacobsen Dealer. WARNING 2. Replace, adjust, worn damaged To prevent injury, lower implements to the ground, components. disengage all drives, engage parking brake, stop 3. Do not wear jewelry or loose fitting clothing when engine, and remove key from ignition switch before making any adjustments or performing maintenance.
ADJUSTMENTS SERVICING FRONT DECK___________________________________________________ The front deck can be raised and tilted up to improve arms. To prevent personal injury or damage to deck access to the cutting unit and blades for service and or lift arms, DO NOT allow deck to drop from service cleaning.
ADJUSTMENTS CUTTING HEIGHT _________________________________________________________ Cutting height for decks can be adjusted from 1 to 5-1/2 in. (25-125 mm) in 1/2 in. (13 mm) increments. Actual Mount No. of Spacers Mount Height Location Under Mount Middle cutting height may vary somewhat from the heights given 1 1/2 Lower Upper...
ADJUSTMENTS LIFT LIMIT SWITCHES _____________________________________________________ The rotation of the cutting blades is controlled by limit 3. Shut OFF engine and remove key. Support decks switches positioned on the mower frame near the lift using blocks. This will prevent them from accidently arms for each deck.
ADJUSTMENTS NEUTRAL ADJUSTMENT ___________________________________________________ Important: The neutral adjustment on the drive pump is 7. Connect traction pedal linkage, Section 3.11, and preset at the factory on all new mowers and replacement install and adjust switches, Sections 3.8 and 3.9. pumps. Further adjustment is required only if the pump Important: Always check operation of Interlock System has been disassembled for service or neutral lever after replacing or adjusting switch.
ADJUSTMENTS FORWARD SENSING SWITCH _______________________________________________ The forward sensing switch allows the mower to operate Switch open - Full reverse range of pedal. in four wheel drive only with the traction pedal in its 5. Connect switch to wiring harness and check forward position.
ADJUSTMENTS 3.11 PARKING BRAKE _________________________________________________________ 1. Check linkage and pivots to ensure they are operating smoothly. Inspect parking brake and CAUTION steering assist cables. DO NOT disengage the brakes with the engine off. 2. Park the mower on a 30% slope (16.7°) near the bottom of the hill, with the front of the mower facing 3.
ADJUSTMENTS 3.14 STEERING STOP BOLTS ____________________________________________________ 1. Steering toe-in must be set before adjusting stop bolts. If toe-in is changed, stop bolts must be re- adjusted. 2. Turn stop bolts (P and Q) out as far as possible without removing them. 3.
All torque values included in these charts are approximate and are for reference only. Use of these torque values is at your sole risk. Jacobsen is not responsible for any loss, claim, or damage arising from the use of these charts.
4. Use the illustrations in the Parts List as reference for adjustments cannot be made, contact an Authorized the disassembly and reassembly of components. Jacobsen Dealer. 5. Recycle or dispose of all hazardous materials 2. Inspect the equipment on a regular basis, establish...
MAINTENANCE SHARPENING BLADES_____________________________________________________ 1. Place a wooden block between the blade and mower housing to stop the blade from moving. To remove blade, turn screw holding blade counterclockwise Maximum WARNING 1/2” (13 mm) The mower blades can develop sharp edges. Use caution whenever servicing and handling.
Warm up the engine at approximately half throttle without load. Failure to properly warm up the engine During the break-in period, Jacobsen recommends the can shorten engine life. following: If the injection pump, injectors, or the fuel system require service, contact an authorized Jacobsen Dealer.
MAINTENANCE AIR FILTER_______________________________________________________________ Check the service indicator daily. Replace air cleaner 5. Check all hoses and air ducts. Tighten hose clamps. element immediately when red band becomes visible (A) Do not remove the element for inspection or cleaning. Unnecessary removal of the filter increases the risk of injecting dust and other impurities into the engine.
MAINTENANCE FUEL SYSTEM ____________________________________________________________ Refer to Section 5 for specific maintenance intervals. To change fuel filter: See Engine Manual for detailed procedures. 1. Close fuel valve on tank, then remove and discard the existing filter. Before replacing any filter, thoroughly clean the filter 2.
MAINTENANCE 4.12 CHARGING BATTERY _____________________________________________________ 2. Whenever possible, remove the battery from the mower before charging. If battery is not sealed, WARNING check that the electrolyte covers the plates in all the cells. Charge battery in a well ventilated area. Batteries generate explosive gases.
3. After oil has drained install drain plug and fill with Drain and replace the hydraulic oil if you notice the Jacobsen Hydraulic Oil. presence of water or foam in the oil, a rancid odor (indicating excessive heat), or after a major component 4.
If you have to add coolant more than once a month, or add more than one quart at a time, have a Jacobsen Dealer check the cooling system. Drain and refill annually. Remove the radiator cap and remove the lower radiator hose.
Note: Shut off engine prior to cleaning. Do not wash any Repair damaged metal surfaces and use Jacobsen touch-up portion of the equipment while it is hot. Do not use high paint. Wax the equipment for maximum paint protection.
Page 28
MAINTENANCE Always check Interlock System after servicing the electrical system! K15 K16 K17 LTS 4WD CRS Wire Harness Label MR MC ML NT3 NT2 NT1 BK2 BK1 KYS KYA KYI Schematic Code Relay Description Function KYA / K2 Key Switch “A” Provide power to alternator IG circuit when ignition switch is in the RUN position and operator is seated.
MAINTENANCE 4.20 EFI DIAGNOSTIC CHECK ___________________________________________________ The electrical system is equipped with an OBD-II and Refer to the HR-9016 Technical Repair Manual for code Diagmaster diagnostic connectors located near the descriptions. engine controller. Plug an OBD-II reader into the matching connector, turn ignition switch to the ON position (do not start engine), and refer to the instructions included with the reader to retrieve diagnostic codes.
3. Check and retorque all hardware. All replacement components used for the ROPS must be as Do not loosen or remove bolts, do not weld, drill, modify, specified in the Jacobsen Parts List. bend, or straighten a damaged structure. 4.23 STORAGE________________________________________________________________...
TROUBLESHOOTING TROUBLESHOOTING GENERAL ________________________________________________________________ The troubleshooting chart below lists basic problems that may occur during start-up and operation. For more detailed information regarding the hydraulic and electrical systems contact your area Jacobsen Dealer. Symptoms Possible Causes Action Engine will not Parking brake disengaged Check Interlock System and start-up procedure.
Manual grease gun with NLGI Grade 2 (Service Class LB) *** Clean as Required III Engine Oil - See Section 4.5 **** Check lug bolt torque daily for first 100 hours of operation Jacobsen Hydraulic Oil - VG ISO 68 en-32...
4. Order by the quantity desired, the part number, and description of the part as given in the parts list. 5. Send or bring the order to an authorized Jacobsen Distributor. 6. Inspect all shipments on receipt. If any parts are dam- aged or missing, file a claim with the carrier before accepting.
PARTS LIST PARTS CATALOG TABLE OF CONTENTS______________________________________ Body and Decals Hydraulics and Electrical 1.1 ..Decals-Mower..........36 33.1 ..Side Deck Valve Supply ......100 2.1 ..Hood ............38 34.1 ..Front Deck Valve Supply ......101 3.1 ..Cowlings and Skirts ........40 35.1 ..
HR-9016 Item Part No. Qty. Description Serial Numbers/Notes Frame 1002889 Cross Frame 1002895 Cylinder Mount, Right 1002896 Cylinder Mount, Left 400416 Screw, 1/2-13 x 2-1/2” Hex Head 446154 Lockwasher, 1/2 Heavy 443118 Nut, 1/2-13 Hex 4226721 Bracket, Right Radiator 4226720 Bracket, Left Radiator 400616 Screw, 5/8-11 x 2”...
HR-9016 Serial No. 70539 All 13.1 Frame With ROPS Serial No. 70540 All P/O 34 9016-02...
Page 61
HR-9016 Item Part No. Qty. Description Serial Numbers/Notes Frame 1002889 Cross Frame 1002895 Cylinder Mount, Right 1002896 Cylinder Mount, Left 400416 Screw, 1/2-13 x 2-1/2” Hex Head 446154 Lockwasher, 1/2 Heavy 443118 Nut, 1/2-13 Hex 4226721 Bracket, Right Radiator 4226720 Bracket, Left Radiator 400616 Screw, 5/8-11 x 2”...
HR-9016 Serial No. All Engine and Radiator 18.1 Radiator To Engine 9016-12...
Page 71
HR-9016 Item Part No. Qty. Description Serial Numbers/Notes 4228260 Firewall, Radiator 440120 Carriage Bolt, 3/8-16 x 1-1/4” 4226721 Bracket, Right Radiator See 12.1 or 13.1 4226720 Bracket, Left Radiator See 12.1 or 13.1 452008 Flat Washer, 3/8 446142 Lockwasher, 3/8 Heavy 443110 Nut, 3/8-16 Hex 4139109...
HR-9016 Serial No. All 20.1 Remote Engine Oil Filter...
Page 75
HR-9016 Item Part No. Qty. Description Serial Numbers/Notes 450190 Screw, M8-1.25 x 16 Hex Head 4136120 Adaptor, Oil Filter Part of Engine 4137099 Adaptor, 90°, 3/8 NPTF x -8 ORFS 339910 • O-Ring, -8 ORFS 4133342 O Ring Part of Engine 4133240 Plug, Oil Filter Part of Engine...
Page 79
HR-9016 Item Part No. Qty. Description Serial Numbers/Notes – Engine and Pump Assembly See 23.1 4261130 Mounting Hardware Part of Engine 3008821 Temperature Sender REFERENCE U6, See 66.1 4136286 Engine Mount, Right Hand 4136285 Engine Mount, Left Hand 4132013 Engine Mount, Rear 365979 Screw, M12-1.25 x 25mm Hex Head 446154...
HR-9016 Serial No. All 26.1 Fuel Routing Engine Rotated 180 Degrees For Clarity 23 24...
Page 87
HR-9016 Item Part No. Qty. Description Serial Numbers/Notes 3006265 Tank, Fuel See 25.1 361117 Bushing 2810702 Valve, Needle 4 48540-01 Clamp, Hose 554748 Fuel Line, Tank to Sedimentor 10 Ft. Roll, Cut to Length, 5/16” I.D. 4225760 Sedimentor Included with Engine 4251726 •...
HR-9016 Serial No. All Lift Arms and Deck Valves 28.1 Front Lift Arms and Cylinders...
Page 91
HR-9016 Item Part No. Qty. Description Serial Numbers/Notes 1002785 R.H. Front Lift Arm 1003900 L.H. Front Lift Arm 342033 • Bushing 471214 • Grease Fitting 3006490 Bracket, Front Deck Pivot 3007091 Angle, R.H. Valve Mount 3007092 Angle, L.H. Valve Mount 400412 Screw, 1/2-13 x 2”...
HR-9016 Serial No. All 29.1 Front Deck Latch 9016-05...
Page 93
HR-9016 Item Part No. Qty. Description Serial Numbers/Notes 1003483 Brace, Stand Up 365826 Spacer 400430 Screw, 1/2-13 x 5-1/2” Hex Head 1003277 Pin, Cylinder Rod End 446154 Lockwasher, 1/2 Heavy 443118 Nut, 1/2-13 Hex 1003484 Latch, Front Deck 352936 • Bushing 3008472 Spring, Torsion 441690...
HR-9016 Serial No. All 30.1 Side Lift Arms 21 / 22 23 / 24 1 / 2 13 / 14...
Page 95
HR-9016 Item Part No. Qty. Description Serial Numbers/Notes 1005016 Pivot, Left Side Arm 1005017 Pivot, Right Side Arm 304569 • Bushing 332351 • Bushing 471214 • Grease Fitting 3006294 Plate, Side Arm Pivot 3006295 Plate, Side Arm Pivot 400412 Screw, 1/2-13 x 2” Hex Head 446154 Lockwasher, 1/2 Heavy 444758...
HR-9016 Serial No. All Hydraulics and Electrical 33.1 Side Deck Valve Supply 1 11 Item Part No. Qty. Description Serial Numbers/Notes 400264 Screw, 3/8-16 x 1-1/4” Hex Head 446142 Lockwasher, 3/8 Heavy 443110 Nut, 3/8-16 Hex 4135253 Plate, Tube Mounting 4135262 Hose, Pump to left Side 4135408...
HR-9016 Serial No. All 34.1 Front Deck Valve Supply Item Part No. Qty. Description Serial Numbers/Notes 400264 Screw, 3/8-16 x 1-1/4” Hex Head 452008 Flat Washer, 3/8 446142 Lockwasher, 3/8 Heavy 443110 Nut, 3/8-16 Hex 1003607 Hose, Pump to Left Front Valve 4135589 Hose, Pump to Right Front Valve 339963...
HR-9016S Serial No. All 37.1 Traction Hydraulics To Bottom Port Right Rear Wheel Motor To Top Port Right Rear Wheel Motor To Port 1 4WD Valve To Port 3 4WD Valve To Port 2 To Bottom Port 4WD Valve Left Rear Wheel Motor To Top Port Left Rear Wheel Motor To Port 4...
Page 105
HR-9016 Item Part No. Qty. Description Serial Numbers/Notes 1002769 Wheel Motor, Front See 14.1 340074 Fitting, -12 ORFS x -12 ORB 90° 339912 • O-Ring, -12 ORFS 339900 • O-Ring, -12 ORB 4135556 4WD Valve with Oil Shuttle See 27.1 Pump Assembly See 27.1 339990...
HR-9016 Item Part No. Qty. Description Serial Numbers/Notes 1003891 Return Manifold See 36.1 1003988 Manifold, Cooler Inlet 339966 Locknut, -20 ORFS Bulkhead 339911 O-ring, SAE #10 1003862 Tube, Right Front Valve to Inlet 1003860 Tube, Right Side Valve to Inlet 1003861 Tube, Left Side Deck to Inlet 4227982...
HR-9016 Serial No. All 39.1 Return Hydraulics Right Wing Deck Motors Case Drain Right Rear Wheel Motor Case Drain Front Deck Motors Left Rear Wheel Motor Case Drain Case Drain Left Side 4WD Valve Right Front Wheel Motor Case Drain Left Wing Deck Motors Case Drain Left Front Wheel Motor...
Page 109
HR-9016 Item Part No. Qty. Description Serial Numbers/Notes 1003891 Return Manifold See 36.1 1003573 Hose, Pump to Return Manifold 1003575 Hose, 4WD Valve to Pump 339911 O-Ring, SAE #10 Face Seal 340065 Fitting, -8 ORFS x -6 ORB 90° 4WD Valve Port T 339910 •...
HR-9016 Serial No. All 42.1 Lift Valve Hydraulics To Fitting Hose Labled Destination Right Side Cylinder Base End Right Side Cylinder Rod End Left Side Cylinder Base End Left Side Cylinder Rod End Front Lift Cylinder Rod End Tee Steering Valve AUX Port Important: The hoses must be routed through the retaining clamp in the order shown to allow proper clearance of the heat shield.
Page 113
HR-9016 Item Part No. Qty. Description Serial Numbers/Notes 4244654 Hose, Right Side Cylinder Base End 1003600 Hose, Right Side Cylinder Rod End 1003601 Hose, Left Side Cylinder Base End 1003602 Hose, Left Side Cylinder Rod End 340167 Fitting, -6 ORFS 90° Bulkhead 339909 •...
HR-9016 Serial No. All 43.1 Power Steering Hoses Hose (8) Hose (6) From Pump To Return Manifold Hose (7) To Lift Valve Hose (5) To Steering Cylinder Hose (5) To Steering Cylinder To Lift Valve...
Page 115
HR-9016 Item Part No. Qty. Description Serial Numbers/Notes > 1003876 Tube, RT Hose to Rod End Hose 1003875 Tube, LT Hose to Base End Hose 339961 Locknut, Bulkhead 339909 O-Ring, -6 ORFS 1003606 Hose, Valve to Cylinder Tubes 1003593 Hose, Valve to Return Manifold 4238602 Hose, Steering Valve to Lift Valve See 42.1 for other end of hose.
HR-9016 Serial No. All Decks 46.1 Decals - Decks 4181863 Mount Number of Spacers Middle Height Location Under Mount Lower Upper 1-1/2 Lower Thrust Mount Lower Washer 2-1/2 Lower Leveling 2-1/2 Middle Washer Middle 3-1/2 Middle Lower Middle Spacers Under Upper Mount 4-1/2...
Page 121
HR-9016 Front Left Wing Right Wing Item Part No. Qty. Description Serial Numbers/Notes 3009317 Decal, Caster Cut Height 3009318 Decal, Gage Wheel Cut Height 4181863 Decal, Read Manual for Service 4164381 Decal, Danger 4257090 Decal, Crush Warning > Change from previous revision...
HR-9016 Serial No. All 48.1 Front Deck Center Section 9 / 10 18 16 Front Case Case Drain Drain Inlet Inlet Outlet Outlet Case Drain Outlet Motor Orientation...
Page 125
HR-9016 Item Part No. Qty. Description Serial Numbers/Notes 5003188 Deck, Front Assembly 352936 • Bushing 4256471 Motor, Spindle Assembly 5003763 • Seal Kit 2811954 • Bushing 4115706 • Valve, Check 557523 • Key, 1/4 x 1/4 x 1" Serial Plate, Front Deck 440124 Carriage Bolt, 3/8-16 x 1-3/4”...
HR-9016 Serial No. All 49.1 Front Deck Winglets (Right Winglet Shown) Front Inlet Outlet Case Case Drain Drain Motor Orientation Outlet Inlet Left Winglet Right Winglet 9016-55...
Page 127
HR-9016 Item Part No. Qty. Description Serial Numbers/Notes 5003186 Deck, RH Winglet 5003187 Deck, LH Winglet 4256471 Motor, Spindle Assembly 5003763 • Seal Kit 2811954 • Bushing 4115706 • Valve, Check 557523 • Key, 1/4 x 1/4 x 1" 366613 Shim 440124 Carriage Bolt, 3/8-16 x 1-3/4”...
HR-9016 Serial No. All 50.1 Front Deck Hydraulics Right Winglet Motor Center Motor E - To Return Manifold Right Center Motor Left Center Motor Left Winglet Motor...
HR-9016 Serial No. All 51.1 Wing Decks Right Wing Shown 20 / 21 1 / 2 25 23 Inlet Outlet Case Case Drain Drain Front Outlet Inlet Outlet Inlet Outlet Inlet Inlet Outlet Case Case Case Case Drain Drain Drain Drain Outlet Inlet...
Page 131
HR-9016 Item Part No. Qty. Description Serial Numbers/Notes 5003190 Deck, Right Wing 5003189 Deck, Left Wing 4256471 Motor, Spindle Assembly 5003763 • Seal Kit 2811954 • Bushing 4115706 • Valve, Check 557523 • Key, 1/4 x 1/4 x 1" Wing Deck Serial Plate 440124 Carriage Bolt, 3/8-16 x 1-3/4”...
HR-9016 Serial No. All 52.1 Wing Deck Hydraulics Right Outside Motor Right Center Right Inside Motor Motor Right Wing Deck Hydraulics 12 13 Left Inside Motor Left Center Motor Left Outside Motor Left Wing Deck Hydraulics...
HR-9016 Serial No. 54.1 Wheel and Tire Assemblies Part Numbers 4256572 and 4253030 Item Part No. Qty. Description Serial Numbers/Notes 4250772 Tire, 11 x 4-5 Smooth 4256572 Only 4253050 Tire, 13 x 6.5-6.5 Multi Rib 4253030 Only 4256573 Wheel, 5 x 3 4256572 Only 4253031 Wheel, 6 x 4.5...
HR-9016 Serial No. All 58.1 Rear Wheel Motor Serial No. All Part Number 4209060 19 20 Included In Rear Motor Seal Kit 4178564 Included In Front Shaft Seal Kit 4200921 Item Part No. Qty. Description Serial Numbers/Notes 558066 Screw, Torx Front Retainer 558063 Shaft and Bearing Kit...
HR-9016 59.1 Deck Return Canister Part Number 5003371 9016-47 Item Part No. Qty. Description Serial Numbers/Notes O-Ring Back Up Ring Loaded U-Cup Rod Wiper 471214 Grease Fitting 443132 Nut, 3/4-16 Hex 5003428 Collar Assembly 5003427 Seal Kit Gold Star Return Canisters 5003662 Seal Kit HDM Return Canisters...
HR-9016 Serial No. All 61.1 Front Lift Cylinder Part Number 4138587 Item Part No. Qty. Description Serial Numbers/Notes ● PSP Seal ● Back Up Ring ● O-Ring ● O-Ring ● Back Up Ring ● Internal Snap Ring ● External Snap Ring ●...
HR-9016 Serial No. All 62.1 Wing Lift Cylinders Part Number 4138521 1 2 3 Item Part No. Qty. Description Serial Numbers/Notes ● PSP Seal ● Back Up Ring ● O-Ring ● O-Ring ● Back Up Ring ● Internal Snap Ring ●...
HR-9016 Serial No. All 63.1 Deck Valve Part Number 4135582 4 / 5/ 6 Item Part No. Qty. Description Serial Numbers/Notes 5002911 Relief Valve 5003579 • Seal Kit 5002912 Relief Valve 5003554 • Seal Kit 3010199 Plug, SAE #6 Located opposite Diagnostic port 339897 •...
HR-9016 Serial No. All Schematics 65.1 Hydraulic Schematic Engine Valve 4387 psi 2.81 ci 2400 RPM Transport 1.28 ci 1.28 ci 1.28 ci .49 ci 4387 psi 2700 RPM Traction Pump 313 psi .98 ci Typ (11 Places) Right Wing Deck Valve Right Wing Motors...
Page 155
HR-9016 Reference Part Item Description Serial Numbers/Notes Illustration Number See 16.1 Battery See 16.1 Battery See 44.1 3000359 50 Amp Circuit Breaker - Main See 44.1 4237462 90 Amp Circuit Breaker - Engine See 6.1 555846 Interlock System Diode See 6.1 555846 Test Diode See 6.1...
Page 156
HR-9016 Reference Part Item Description Serial Numbers/Notes Illustration Number Not Shown 4251788 EGR Valve Not Shown 4251717 Suction Valve See 56.1 5003627 Seat Air Ride Compressor Not Shown 4251772 Heater, Intake Air Not Shown Resistor, 1kΩ SOL1 SOL2 See 63.1 4134530 Left Wing Mow Solenoid Coil Included in 1004337 Deck Valve...
Page 157
Reference Part Item Description Serial Numbers/Notes Illustration Number Not Shown 4251850 Cam Position Sensor Not Shown 4251738 Fuel Rail Pressure Sensor Included with Fuel Rial Not Shown 4251856 Boost Pressure Sensor Not Shown 4251858 Coolant Temperature Sensor Not Shown 4251855 External Air Temperature Sensor Not Shown 4251717...
See your local Jacobsen Dealer * Refer to the Parts & Maintenance manual for the correct hydraulic oil requirements for your machine. Jacobsen offers a High Usage Parts Catalog illustrating commonly used Parts through easy to read line Drawings. See your local Jacobsen...
