August 2015©
Jacobsen HR9016 ROPS Cab
** Shown with optional equipment
Caution
** Please read installation instructions and follow all safety statements before attempting operating
this ROPS product.
** A copy of this operator manual should be kept with the machine operating manuals.
** If this manual is lost, please contact your local Jacobsen dealer for a replacement.
Jacobsen HR9016 ROPS Cab Operator Manual
Jacobsen HR9016 ROPS Cab
This ROPS cab is designed and built
to fit the Jacobsen HR9016.
Designed and Built by:
Tektite Manufacturing Inc:
24157 Hwy 3
P.O. Box 639
Winkler, MB
R6W 4A8
Canada
PH: 204-331-3463
Fax: 204-331-4159
sales@tektite.ca
One year standard product
warranty provided by Tektite.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HR9016 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Jacobsen HR9016

Summary of Contents for Jacobsen HR9016

  • Page 1 ** Please read installation instructions and follow all safety statements before attempting operating this ROPS product. ** A copy of this operator manual should be kept with the machine operating manuals. ** If this manual is lost, please contact your local Jacobsen dealer for a replacement.
  • Page 2 August 2015© Jacobsen HR9016 ROPS Cab Operator Manual Tektite Manufacturing Incorporated thanks you for purchasing a Jacobsen HR9016 ROPS cab! Tektite has worked very hard to design and build this ROPS product and we hope that it provides you with many years of ROPS protection.

  • Page 3: Safety Precautions

    August 2015© Jacobsen HR9016 ROPS Cab Operator Manual Safety Precautions Safety First Read these instructions carefully. It is essential that you read the instructions and safety regulations before you attempt to assemble or use the features that are on this cab/ROPS.

  • Page 4: General Safety

    August 2015© Jacobsen HR9016 ROPS Cab Operator Manual General Safety 1. Never let an unqualified or untrained driver operate the mower. 2. Keep a fire extinguisher, with ABC rating securely fastened in the ROPS. Maintain it and be familiar with its use.

  • Page 5: Maintenance Safety

    August 2015© Jacobsen HR9016 ROPS Cab Operator Manual Safe Operation on Rough Terrain 1. Drive the mower slowly on hillsides and curves to eliminate the danger of tipping. Avoid slopes which are too steep for safe operation. Avoid sharp uphill turns.
  • Page 6 August 2015© Jacobsen HR9016 ROPS Cab Operator Manual 9. Use your turn signals, checking for traffic well in advance of turning. If the mower is not equipped with turn signals and law requires them, install them prior to operating on or near public roads.
  • Page 7 August 2015© Jacobsen HR9016 ROPS Cab Operator Manual Operating Instructions Important The following section locates, identifies and briefly describes the functions of all cab controls. All operators should familiarize themselves with control location and function prior to operating the mower. Failure to do so may result in unsafe operation of the mower and possible injury or death to operators and bystanders.
  • Page 8 August 2015© Jacobsen HR9016 ROPS Cab Operator Manual Note: indicator light activates when wiper is on. 3. Front Work Light Rocker Switch (optional) Low position: Off High position: On Note: indicator light activates when work lights are on. 4. Rear Work Light Rocker Switch (optional)
  • Page 9 August 2015© Jacobsen HR9016 ROPS Cab Operator Manual 4. Fan Rotary Switch (optional) Indicator mark above switch indicates whether fan is operational or not. 5. Temperature Control Rotary Switch (optional) Indicator mark at lower left corner indicates current temperature setting. Rotate to increase heat output or to decrease heat output of heating system.
  • Page 10 August 2015© Jacobsen HR9016 ROPS Cab Operator Manual After your ROPS Cab has been installed: Before starting a mower equipped with a Tektite ROPS cab: 1. Clear the operator platform of all tools. Tools left in or around the ROPS and mower can cause operator interference which could lead to bodily injury and/or damage the machine.
  • Page 11 Index Service Part # File Name Description A00-0013 TEKT-0009 5MM Bushing A00-0019 STEP-BOLT1-4X1 Step Bolt, 1/4" x 1", MB A00-0021 FLANGE-NUT-1-4 Flange Nut, 1/4", YD A00-0044 TEKT-ASM-002 Side Window Hinge Weldment A00-0057 TEKT-0020MIR Side Window Latch, L60776 A00-0058 CARRIAGE_BOLT-5-16X1 Bolt, Carriage, 5/16"x 1", YD A00-0059 FLANGE-NUT-5-16 Flange Nut, 5/16", YD...
  • Page 12 Index Service Part # File Name Description A00-0013 TEKT-0009 5MM Bushing A00-0019 STEP-BOLT1-4X1 Step Bolt, 1/4" x 1", MB A00-0021 FLANGE-NUT-1-4 Flange Nut, 1/4", YD A00-0046 TEKT-ASM-002R Side Window Hinge Right A00-0056 TEKT-0020 Side Window Latch, L60775 A00-0058 CARRIAGE_BOLT-5-16X1 Bolt, Carriage, 5/16"x 1", YD A00-0059 FLANGE-NUT-5-16 Flange Nut, 5/16", YD...
  • Page 13 Index Service Part # File Name Description A00-0001 DLP-HANDLE Outside Push Button Handle A00-0002 LEFT-LATCH Suicide Door Left Latch A00-0013 TEKT-0009 5MM Bushing A00-0018 STEP-BOLT1-4X1-1-2 Step Bolt, 1/4" x 1 1/2", MB A00-0020 STEP-BOLT1-4X1-1-4 Step Bolt, 1/4" x 1 1/4", MB A00-0021 FLANGE-NUT-1-4 Flange Nut, 1/4", YD...
  • Page 14 Index Service Part # File Name Description A00-0001 DLP-HANDLE Outside Push Button Handle A00-0003 RIGHT-LATCH Suicide Door Right Latch A00-0013 TEKT-0009 5MM Bushing A00-0018 STEP-BOLT1-4X1-1-2 Step Bolt, 1/4" x 1 1/2", MB A00-0020 STEP-BOLT1-4X1-1-4 Step Bolt, 1/4" x 1 1/4", MB A00-0021 FLANGE-NUT-1-4 Flange Nut, 1/4", YD...

  • Page 15: Windshield Assembly

    Index Service Part # File Name Description A00-0013 TEKT-0009 5MM Bushing A00-0014 TEKT-0092 Thick Bushing A00-0020 STEP-BOLT1-4X1-1-4 Step Bolt, 1/4" x 1 1/4", MB A00-0021 FLANGE-NUT-1-4 Flange Nut, 1/4", YD Ja5-0001 JA9016-043 Windshield Glass Ja5-0018 JA9016-156- Front Window Seal SCALE 0.200 Tektite Manufacturing Inc.
  • Page 16 Index Service Part # File Name Description A00-0013 TEKT-0009 5MM Bushing A00-0014 TEKT-0092 Thick Bushing A00-0019 STEP-BOLT1-4X1 Step Bolt, 1/4" x 1", MB A00-0020 STEP-BOLT1-4X1-1-4 Step Bolt, 1/4" x 1 1/4", MB A00-0021 FLANGE-NUT-1-4 Flange Nut, 1/4", YD A00-0033 315-080 Rear Wiper Shaft Grommet A00-0043 WWF-MOTOR...
  • Page 17 Index Service Part # File Name Description A00-0095 TEKT-0057 ROPS Isolator A00-0353 TEKT-0143 New Condensor Assembly, Kalori A00-0359 FLANGE-NUT-10-32 Flange Nut, 10-32 A00-0360 SCREW-10-32X1-2 Screw, 10-32 x 1/2" Ja5-0006 JA9016-ASM-13 Rear Bracket Weldment Ja5-0020 JA9016-116 Rear Bracket Seal, Bottom Ja5-0020 JA9016-117 Rear Bracket Seal Vertical Ja5-0020...
  • Page 18 Index Service Part # File Name Description A00-0006 TEKT-0074 Cabin Air Filter A00-0016 TEKT-0075 Domelight LED A00-0017 305-1002 Panto Mount Plate A00-0025 BALL-LOUVER 2 1/2" Ball Louver A00-0026 OSCILLATING-FAN Oscillating Fan A00-0038 TEKT-0076 3" Plug A00-0055 TEKT-0019 Fir Tree Fastener A00-0070 REID-KBP-262-KBP-265 Knob, Knurled, 1/4"...
  • Page 19 Index Service Part # File Name Description A00-0006 TEKT-0074 Cabin Air Filter A00-0070 REID-KBP-262-KBP-265 Knob, Knurled, 1/4" A00-0073 FILTER-COVER Filter Cover A00-0076 TEKT-0026 1/4" Panel Nut Ja5-0009 JA9016-149 Rear Seal Roof Cap Ja5-0010 JA9016-150 Front Seal Roof Cap Ja5-0011 JA9016-151- Roof Cap Edging Ja5-0012 JA9016-152-...

  • Page 20: Accessories Assembly

    Index Service Part # File Name Description JA9016-ASM-22-RADIO A00-0021 FLANGE-NUT-1-4 Flange Nut, 1/4", YD A00-0059 FLANGE-NUT-5-16 Flange Nut, 5/16", YD A00-0084 TEKT-0070 Gas Shock A00-0085 TEKT-0069 Gas Shock Stud A00-0134 WASHER-BOTTLE Washer Tank A00-0136 RED_TAIL_FLASH Red Tail Light A00-0141 ROUND_MIRROR_6_INCH External 6"...
